User Guide

DS50003584A - 1

Introducon

The PD-9001GR Power over Ethernet (PoE) single-port Midspan oers a compact and cost-eective power

solution for IP phones, WLAN access points, network cameras, and other IP terminal installations.

Features

The PD-9001GR Midspan oers the following important features:

• Supports up to 10/100/1000 Mbps Pass Through Data Rates

• Can be Powered Through Universal AC Input

• Standards Compliant: IEEE

802.3at

Single-Port 802.3at Gigabit PoE Midspan User Guide

PD-9001GR

User Guide

DS50003584A - 2

Table of Contents

Introduction...........................................................................................................................................................................1

Features..........................................................................................................................................................................1

1. Standards and Safety Guidelines................................................................................................................................ 3

1.1. EMC Compliance................................................................................................................................................ 3

1.2. Safety Compliance............................................................................................................................................. 3

1.3. Safety Information............................................................................................................................................. 3

2. Installation......................................................................................................................................................................5

2.1. Preliminary Steps............................................................................................................................................... 5

2.2. Installing the Unit...............................................................................................................................................5

2.3. Indicators............................................................................................................................................................ 7

3. Specications................................................................................................................................................................. 8

3.1. Environmental Specications........................................................................................................................... 8

3.2. Electrical Specications..................................................................................................................................... 8

3.3. Ethernet Interface.............................................................................................................................................. 8

4. Troubleshooting............................................................................................................................................................ 9

4.1. Troubleshooting Steps.......................................................................................................................................9

5. Technical Support........................................................................................................................................................10

6. Recycling and Disposal .............................................................................................................................................. 11

7. Revision History...........................................................................................................................................................12

Microchip Information....................................................................................................................................................... 13

The Microchip Website............................................................................................................................................... 13

Product Change Notication Service........................................................................................................................ 13

Customer Support.......................................................................................................................................................13

Microchip Devices Code Protection Feature............................................................................................................ 13

Legal Notice..................................................................................................................................................................13

Trademarks.................................................................................................................................................................. 14

Quality Management System.....................................................................................................................................15

Worldwide Sales and Service..................................................................................................................................... 16
