2014 Microchip Technology Inc.DS20005311A-page 1
HV9921/HV9922/HV9923
Features
•Constant output current:
-HV9921 – 20mA
-HV9922 – 50mA
-HV9923 – 30mA
•Universal 85 - 264VAC operation
•Fixed off-time buck converter
•Internal 475V power MOSFET
Applications
•Decorative lighting
•Low power lighting fixtures
Description
HV9921/HV9922/HV9923 are pulse-width modulated
(PWM), high-efficiency, LED driver control ICs. They
allow efficient operation of LED strings from voltage
sources ranging up to 400VDC. HV9921/22/23 include
an internal high voltage switching MOSFET controlled
with fixed off-time (T
OFF
) of approximately 10μs. The
LED string is driven at constant current, thus providing
constant light output and enhanced reliability. The out-
put current is internally fixed at 20mA for HV9921,
50mA for HV992, and 30mA for HV9923. The peak cur-
rent control scheme provides good regulation of the
output current throughout the universal AC line voltage
range of 85 to 264VAC or DC input voltage of 20 to
400V.
3-Pin Switch-Mode LED Lamp Driver ICs
