Atmel-8961A-CPLD-ATF15xx-DK3-U-Development-Kit-UserGuide_072015
Introduction
The Atmel
®
ATF15xx-DK3-U Complex Programmable Logic Device (CPLD) Development/Programmer Kit is a
complete development system and an In-System Programming (ISP) programmer for the Atmel ATF15xx
Family of industry standard pin compatible CPLDs with Logic Doubling
®
features. This kit provides designers a
very quick and easy way to develop prototypes and evaluate new designs with an ATF15xx ISP CPLD. The
ATF15xx Family of ISP CPLDs includes the Atmel ATF15xxAS, ATF15xxASL, ATF15xxASV, and
ATF15xxASVL CPLDs. With the availability of the different socket adapter boards to support most of the
package types
(1)
offered in the ATF15xx Family of ISP CPLDs, this kit can be used as an ISP programmer to
program the ATF15xx ISP CPLDs in most of the available package types
(1)
through the industry standard JTAG
interface (IEEE 1149.1).
Kit Contents
CPLD Development/Programmer Board (ATF15xx-DK3)
44-pin TQFP Socket Adapter Board (ATF15xxDK3-SAA44)
(2)
ATF15xx USB-based JTAG ISP Download Cable (ATDH1150USB or ATDH1150USB-K)
Two Atmel 44-pin TQFP Sample Devices
Device Support
The ATF15xx-DK3-U CPLD Development/Programmer Kit supports the following devices in all currently
available Atmel speed grades and packages (except the 100-PQFP):
ATF1502AS/ASL
ATF1504AS/ASL
ATF1508ASV/ASVL
ATF1502ASV
ATF1504ASV/ASVL
ATF1508AS/ASL
1.The socket adapter board is not offered for the 100-pin PQFP.
2.Only the 44-pin TQFP Socket Adapter Board is included in this kit. Other socket adapter boards are sold separately. See
“Hardware Description” section for more information on socket adapter board ordering codes.
ATF15xx-DK3-U
CPLD Development/Programmer Kit
USER GUIDE
