PR-LOC2.2 & PR-LOC2.4

INSTALLATION INSTRUCTIONS

MetraOnline .com© COPYRIGHT 2022 METRA ELECTRONICS CORPORATION REV. 9/12/22 INSTPR-LOC2.2 & PR-LOC2.4

TABLE OF CONTENTS

Quick Start Guide

Things to Know .................................................2

Connections .......................................................2

Gain setup

Basic setup.........................................................3

Advanced Setup ................................................3

Feature Breakdowns ..............................................4

Quick Reference: PR-LOC2.2 ..................................5

Diagram: PR-LOC2.2 ...............................................6

Quick Reference: PR-LOC2.4 ..................................7

Diagram: PR-LOC2.4 ...............................................8

Specifications .........................................................9

Universal Premium LOCs

PR-LOC2.22 IN - 2 OUT with Max Input 20v

PR-LOC2.4 2 IN - 4 OUT With Max Input 20v

TOOLS RECOMMENDED

• Digital Multi-meter

• Test Tones

Universal Premium LOCs

The Proscenium PR-LOC2.2 & PR-LOC2.4 can be used to add amplifiers to an audio system that does not have RCA outputs or when replacing

an OEM radio and retaining the factory amplified system. Variable Gain Controls with Clipping Indicators, Selectable Ground Isolation Load and

Select features ensure a pure, noise-free signal for any type of audio system.

PR-LOC2.4

Line Out Converter (LOC)

KIT COMPONENTS

PR-LOC2.2

Line Out Converter (LOC)
