InstallationManual



Type：GeneralTypeDINrailwithSinglePhase

（Series：DR‐45,DR‐75,DR‐120,DRP‐240,DRP‐480,DRP‐480S）



DR‐45‐5INPUT:100‐240VAC1.5A50/60HzOUTPUT:5V5A

DR‐45‐12INPUT:100‐240VAC1.5A50/60HzOUTPUT:12V3.5A

DR‐45‐15INPUT:100‐240VAC1.5A50/60HzOUTPUT:15V2.8A

DR‐45‐24INPUT:100‐240VAC1.5A50/60HzOUTPUT:24V2A

DR‐75‐12INPUT:100‐240VAC2A50/60HzOUTPUT:12V6.3A

DR‐75‐24INPUT:100‐240VAC2A50/60HzOUTPUT:24V3.2A

DR‐75‐48INPUT:100‐240VAC2A50/60HzOUTPUT:48V1.6A

DR‐120‐12INPUT:100‐120/200‐240VAC3.3/2A50/60HzOUTPUT:12V10A

DR‐120‐24INPUT:100‐120/200‐240VAC3.3/2A50/60HzOUTPUT:24V5A

DR‐120‐48INPUT:100‐120/200‐240VAC3.3/2A50/60HzOUTPUT:48V2.5A

DRP‐240‐24INPUT:100‐240VAC3.5A50/60HzOUTPUT:24V10A

DRP‐240‐48INPUT:100‐240VAC3.5A50/60HzOUTPUT:48V5A

DRP‐480‐24INPUT:200‐240VAC4A50/60HzOUTPUT:24V20A

DRP‐480‐48INPUT:200‐240VAC4A50/60HzOUTPUT:48V10A

DRP‐480S‐24INPUT:100‐120/200‐240VAC11/4A50/60HzOUTPUT:24V20A

DRP‐480S‐48INPUT:100‐120/200‐240VAC11/4A50/60HzOUTPUT:48V10A



Introduction

TheDINrailpowersupplyisakindofexternalswitchingpowersupplyspecificallydesignedtofulfilthe

requirementsofDeutschesInstitutfürNormung(DIN),theGermanInstituteforStandardizationinEnglish.Asa

sortofDINrailpowersupplies,MeanWell’sDINrailpowersupplyseriescanbemountedon

aTS35StandardDIN

rail.

Installation

（1）Alwaysallowgoodventilationclearances,5mmleftandright,40mmaboveand20mmbelow,aroundtheunit

inusetopreventitfromoverheating.Alsoa10‐15cmclearancemustbekeptwhentheadjacentdeviceisa

heatsource.

（2）Theappropriatemountingorientationfortheunit

isvertical,theinputterminalsatthebottomandoutputon

thetopforDR‐75andDR‐120,theinputterminalsontherightandoutputontheleftforDR‐45,DRP‐240,

DRP‐480andDRP‐480S.Mountingorientationsotherthanthat,suchasupsidedown,horizontal,

ortable‐top

mounting,isnotallowed.




