Pagina 1/8
Page 1
Part No 238066 - Printed in USA 06/16/08
This floor sander will afford you many
years of trouble-free operating satisfac-
tion, provided it is given proper care.All
parts have passed rigid quality control
standards prior to being assembled to
produce the finished product. Prior to
packaging, the vacuum was again
inspected for assurance of flawless
assembly.
Your floor sander is protectively
packed to prevent damage in ship-
ping. We recommend that upon deliv-
ery, unpack the sander and inspect it
for any possible damage. Only a visu-
al examination will reveal damage
that may have occurred.
If damage is discovered, immediately
notify the transportation company that
delivered your sander. As a shipper,we
are unable to report claims for con-
cealed damage. You must originate
any claims within 5 days.
This manual is for your protection and
information. PLEASE READ CAREFULLY
since failure to follow precautions
could result in discomfort or injury.
Treat this floor sander as you would
any other high grade precision made
product. Dropping, unreasonable
bumping across thresholds and other
misuses may result in a damaged unit
which is not be covered by warranty.
Read and Follow All Instructions,
Warnings & Cautions Before Using This Machine
Address: 777 South Street
P.O. Box 2310
Newburgh, NY 12550-0606
TEL:
(800) 835-7812 (845) 565-8850
FAX:
(800) 752-6883 (845) 565-9392
mastercraftusa.com
techsupport@mastercraftusa.com
MD17E-MAS-AR
S
AFETY, OPERATION
& MAINTENANCE
MANUAL
W/PARTS ISTL
This unit is intended for commercial use.
S
AVE THESE INSTRUCTIONS
RISK OF EXPLOSION
FLOOR SANDING CAN RESULT IN AN EXPLOSIVE MIXTURE OF FINE DUST AND
AIR. USE FLOOR SANDER MACHINE ONLY IN A WELL VENTILATED AREA.
To reduce risk of fire, electric shock or injury;
Read all instructions before using this floor sander.
WARNING:
1) DO NOT leave this floor sander
plugged in when not in use. Unplug
from outlet when not in use and/or
before servicing.
2) Electric shock could occur if
exposed to rain. Store indoors.
3) This is NOT a toy. Close attention is
necessary when used around or near
children.
4) Use only as described in this manu-
al. Use only manufacturer's recom-
mended attachments.
5) DO NOT use with damaged cord
plug. If the floor sander is not working
as it should because it has been
dropped, damaged, left outdoors, or
dropped into water,contact the manu-
facturer or authorized service center.
6) DO NOT handle the plug or operate
with wet hands.
9) DO NOT unplug by pulling on cord.
To unplug, grasp the plug, not the
power cord.
7) DO NOT pull or carry by cord, use
power cord as a handle, close a door
on cord, or pull cord around sharp
edges or corners. DO NOT run the floor
sander over the cord. Keep cord away
from heated surfaces.
8) DO NOT put any object into motor
openings.
10) Keep hair, loose clothing, fingers
and all parts of body away from mov-
ing parts.
11) DO NOT operate where oxygen or
anesthetics are used.
12) DO NOT use around flammable or
combustible liquids such as gasoline
or use in areas where they may be
present.
13) DO NOT use an extension cord
unless absolutely necessary. If an
extension cord is used, then wire size
must be #14 gauge or thicker and
should not exceed 50 feet in length.
Use only a three-wire grounded exten-
sion cord to ensure grounding protec-
tion.
14) Replace damaged or worn parts
immediately with genuine original
equipment parts to maintain safety
and to protect your limited warranty.
15) Floor sanding can result in an
explosive mixture of fine dust and air.
Use a floor sanding machine only in a
well ventilated area and with the vac-
uum cleaner hooked up and operat-
ing.
Page 2
When using this electric floor sander, basic precautions should always be followed, including the following:
Electrical equipment must be ground-
ed. If it should malfunction or break-
down, grounding provides a path of
least resistance for electrical current to
reduce the risk of electric shock. This
floor sander is equipped with a cord
having an equipment-grounding con-
ductor and grounding plug. The plug
must be inserted into an appropriate
outlet that is properly installed and
grounded in accordance with all local
codes and ordinances.
If repair or replacement of the cord or
plug is necessary, DO NOT connect
the grounded wire to either flat blade
terminal. The wire with insulation hav-
ing an outer surface that is green with
or without yellow stripes is the ground-
ing wire.
Improper use of the grounding plug can result in
a risk of electric shock.
D :ANGER
Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or service person if you are in doubt as to whether
the outlet is properly grounded.
DO NOT modify the plug provided with the equipment. If it will not fit the outlet,
have a proper outlet installed by a qualified electrician.
WARNING:
IMPORTANT
SAFETY
INSTRUCTIONS
GROUNDING
INSTRUCTIONS
Page 3
Disconnect wall plug before leaving floor sander unattended to prevent accidental startup.
DO NOT operate this sander without brush or pad driver and pad in place.Never attempt to lock
pad driver on floor sander by positioning running floor sander on unattached pad driver.(JUMPING)
DO NOT leave a plugged in floor sander unattended.
C :AUTION
This floor sander is designed to move
from side to side. Raise handle slightly
to guide right.As handle is raised high-
er, the faster it will move to the right.
Lower the handle to guide left.
Likewise, the more you lower handle,
the faster it will move to the left.
Plug in the power cable. With pad driv-
er in position, adjust handle and lock
into a comfortable operating position.
Place hands on handle grips and
squeeze trigger locks beneath grips.
This will activate the motor and start
pad driver operating.
Begin operating this floor sander at
the closet possible point to an electri-
cal outlet and work away from the out-
let. This will prevent running over the
electrical cord.
1) Unplug power cable and LOCK
handle in upright position.
2) Tilt the floor sander back until the
handle is laying on the floor and
underside of the machine is fully
exposed.
3) Holding the pad driver in both
hands straddling the motor with your
back to the handle, bend over and fit
the three slots of the clutch plate over
the three lugs of the drive plate.
4) Turn the pad driver counterclock-
wise as far as it will go.It is now seated
and ready for operation.
To Remove:
Disengage the clutch plate slots from
drive plate lugs by turning clockwise.
This electric equipment is for use on a
nominal 120 volt circuit, and has a
grounded plug that looks like the plug
illustrated in (Fig A).A temporary adap-
tor that looks like the adaptor illustrat-
ed in (Fig B & C) may be used to con-
nect this plug to a 2-pole receptacle as
shown in (Fig B) if a properly grounded
outlet is not available.
The temporary adaptor should be
used only until a properly grounded
outlet (Fig A) can be installed by a
qualified electrician.The green color
rigid ear, lug or the like extending from
the adaptor must be connected to a
permanent ground such as a properly
grounded outlet box cover. Whenever
the adaptor is used, it must be held in
place by a metal screw.
Note: In Canada, the use of a temporary adaptor is not permitted by the Canadian Electrical Code.
G
ROUNDING
METHODS
OPERATION
INSTRUCTIONS
PAD DRIVER
INSTALLATION
