LUTRON

Control Unit

Quick Installation and

Operation Guide

Please Read

The GRAFIK Eye QS control unit allows for control of both

lights and shades, without interfaces, using a single control

unit. Features include pushbutton scene recall, info screen that

displays energy savings and status, IR receiver, astronomic

timeclock, contact closure input, and engravable backlit

buttons that are easy to find and operate.

Model Numbers: QSGRJ-3P, QSGRJ-4P, QSGRJ-6P

QSGR-3P, QSGR-4P, QSGR-6P

120 V~ 50/60 Hz220 – 240 V~ 50/60 Hz

Unit Capacity (watts)2000 W3000 W

MLV2000 VA /1600 W3000 VA /2400 W

Zone Capacity (watts)25 – 800 W40 – 1200 W

MLV25 – 800 VA /25 – 600 W40 – 1200 VA /40 – 960 W

See pages 6 and 7 for IEC PELV/NECR Class 2 ratings.

For California residents only:

The batteries in these devices contain Perchlorate Material;

special handling may apply. For more information visit

www.dtsc.ca.gov/hazardouswaste/perchlorate

Contents

Features and Functions of the GRAFIK Eye QS Control Unit. . . . . . . 2

Wiring the GRAFIK Eye QS Control Unit

Overview of Line Voltage/Mains Wiring . . . . . . . . . . . . . . . . . .3

Line Voltage Wiring Details . . . . . . . . . . . . . . . . . . . . . . . .4

Overview of IEC PELV/NECR Class 2 Wiring. . . . . . . . . . . . . . . . 6

QS Link Control Wiring Details. . . . . . . . . . . . . . . . . . . . . . . 7

Completing Installation of the GRAFIK Eye QS Control Unit. . . . . . . 8

Programming Mode

Entering and Exiting Programming Mode. . . . . . . . . . . . . . . . . 9

Navigating Menus in Programming Mode. . . . . . . . . . . . . . . . . 9

Wireless Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Zone Setup

Assigning Load Types. . . . . . . . . . . . . . . . . . . . . . . . . . 11

Assigning Non-Dim Load Types. . . . . . . . . . . . . . . . . . . . . 11

Setting Load Types. . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Scene Setup

Setting Zone Levels, Fade Rates, and Shade Group Actions. . . . . . 13

Occupancy Sensor Setup . . . . . . . . . . . . . . . . . . . . . . . . 14

Scene Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Configuring Occupancy Sensor Settings (optional) . . . . . . . . . . . 16

Pico Wireless Control Setup

Associating with a GRAFIK Eye QS Wireless Control Unit. . . . . . . . 17

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

For additional features and advanced functions, see the complete installation

and operation guide at www.lutron.com/qs
