Maestro® Occupancy/ Vacancy Sensor C•L® Dimmer
Additional Programming, Installation, and Troubleshooting Help
Application Note #480
Revision B
February 2015
1Technical Support — 800.523.9466
®
Maestro® Occupancy/ Vacancy Sensor C•L® Dimmer Models
MSCL-OP153M; MSCL-OP153MH; MSCL-VP153M; MSCL-VP153MH
Overview
This document serves as a supplement to the
Maestro® Occupancy/ Vacancy Sensor C•L® Dimmer
instruction sheet.
Maestro® Sensor Dimmer
Notes:
• To replace fixture bulb(s), power may be temporarily
disconnected at the light fixture by pulling the FASSTM OUT
on the dimmer.
• For any procedure other than routine bulb replacement,
power MUST be disconnected at the main electrical panel.
Glossary. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Sensor Coverage . . . . . . . . . . . . . . . . . . . . . . . 3
Sensor Features in Programming Mode. . . . . . . . . . . . 4
Dimming Features in Advanced Programming Mode . . . . . 6
Programming Mode . . . . . . . . . . . . . . . . . . . . . .7
Timeout . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . 8
Auto-ON . . . . . . . . . . . . . . . . . . . . . . . . . .8
Occupied Level. . . . . . . . . . . . . . . . . . . . . . . 8
Advanced Programming Mode . . . . . . . . . . . . . . . . 9
Preset Light Level . . . . . . . . . . . . . . . . . . . . 10
Manual Fade ON Time . . . . . . . . . . . . . . . . . . 12
Manual Fade OFF Time . . . . . . . . . . . . . . . . . 13
Delayed Fade to OFF. . . . . . . . . . . . . . . . . . . 14
Nightlight Mode . . . . . . . . . . . . . . . . . . . . . 15
Low-End Trim . . . . . . . . . . . . . . . . . . . . . . 16
Low-End Trim Shortcut . . . . . . . . . . . . . . . . 16
High-End Trim . . . . . . . . . . . . . . . . . . . . . . 17
Restoring Default Settings. . . . . . . . . . . . . . . . . . 18
Two-Location Applications Using an Existing Switch . . . . 19
Ambient Light Detection (ALD). . . . . . . . . . . . . . . . 21
How it Works. . . . . . . . . . . . . . . . . . . . . . . 21
FAQs. . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 22
Bulb Compatibility. . . . . . . . . . . . . . . . . . . . . . 24
7
6
5
4
3
2
1
Indicator Lights (IL) 1–7
FASSTM
Front Accessible Service Switch
FASSSensor LED
T
Tap Button
Raise Button
Lower Button
Lens
Product specificaties
| Merk: | Lutron |
| Categorie: | Dimmer |
| Model: | Maestro MSCL-OP153M |
| Soort bediening: | Buttons, Sensor |
| Kleur van het product: | Wit |
| Soort: | Dimmer & schakelaar |
| Kastontwerp: | Ingebouwd |
| AC-ingangsspanning: | 120 V |
