Manual

LS130MT modulare Multipurpose Telescope

Modular designed multipurpose telescope, both for observing the sun in the H-alpha wavelength, as well as

for night sky observations. Easy conversion between the different applications with a few simple steps.

ATTENTION: To be able to use the LS130MT telescope in the version with B3400 for observing and

photographing the night sky, the additionally available conversion kit LS130TBP&F is absolutely necessary

(item number 0551696). The conversion kit is not required for the versions with B1200 & B1800.

Included Contents:

- LS130MT telescope with 3-lens ED APO optics, FPL-51 glass

- H-alpha unit with Pressure-Tuner

- Focuser with 10:1 reduction

- Blocking-filter B1200, B1800 or B3400. At the version with B3400, the blocking filter is fix installed inside

the focuser.

- Tube-ring with handle and GP-level dovetail bar

- Sol-searcher integrated inside handle

- Knurled screws for easy conversion of the telescope

- Protection caps for the H-alpha unit

- Tube extension for use without H-alpha Etalon

- Transport case

Congratulations and thank you for purchasing the modular LS130MT telescope from Lunt Solar Systems!

Enjoy observations in different wavelengths with this high quality telescope. The 3-lens ED optics with FPL-

51 glass guaranteed an outstanding image in all applications.

Safety Information:

There are inherent dangers when looking at the Sun thru any instrument. Lunt Solar Systems has taken your

safety very seriously in the design of our systems. With safety being the highest priority we ask that you read

and understand the operation of your telescope or filter system prior to use. Never attempt to disassemble

the system in a other way as described in this manual! Do not use your system if it is in someway

compromised due to mishandling or damage. Please contact our customer service with any questions or

concerns regarding the safe use of your instrument.

Never look at the Sun with your naked eye or with a telescope that is not specifically designed to do

so. Permanent and irreversible eye damage may result!

Never leave the solar telescope unsupervised while pointed at the Sun. People who are not familiar

with the correct operating procedures of the system may inadvertently replace the diagonal or

remove the filter itself not being aware of the integrated safety features of each.

The Lunt Solar filter/telescopes are not interchangeable with competitor products.

A Lunt Solar Systems solar telescope houses many optical elements that are all pre-aligned and fixed at the

factory. There are no user serviceable parts inside the scope. The telescope should never be taken apart,

except for the modification as described in this manual! This will not only void your warranty leading to costly

repairs, it can only serve to further damage the instrument and compromise its safety.

Most Lunt Solar Systems filters and telescopes house a delicate optical element referred to as an Etalon.

These Etalons are suspended in the system housing in an effort to both protect it and isolate it from outside

influences, which could de-tune the Etalon filter. Extensive research has been done to assure the best

performance of what is essentially the "heart" of the system while protecting it from the day-to-day bumps,

jarring, and vibrations of normal use. However, the instrument should never be subjected to shock due to

being dropped. Mishandling of the filters system will cause the Etalon to de-contact (not covered under

warranty) and will render the instrument useless until repaired.

The instrument should be stored in its original case. As with any precision optical instrument it should be

kept in as low a humidity area as possible.

With proper handling and care the filter should last a lifetime.
