Stream Select – Integration of OIP-N60D and VS-KB21

Introduction

The VS-KB21 is a network camera controller, and the OIP-N60D is a streaming device that

connects network cameras and outputs video via HDMI to a monitor. The integration

feature allows the selected camera image to be automatically displayed on the monitor

when switching sources with the controller.

This guide explains how to switch between different camera sources on the OIP-N60D

using the VS-KB21 camera controller.

※Note：

The VS-KB21 does not support control or preview functions for NDI cameras. To control

or preview NDI cameras, please use the VS-KB21N.

Steps:

1. Connect camera sources to the OIP-N60D.

We will use the 2 cameras (VC-TR40N and VC-TR60) below as an example.

2. Connect Cameras to VS-KB21

Add the same cameras (VC-TR60 and VC-TR40N) to the VS-KB21 camera controller.

Assign any desired camera numbers to the VC-TR60 and VC-TR40N, respectively.

In the example below, the TR40N has been assigned to camera 14, and the TR60 has

been assigned to camera 15.
