Copyright © 2017 Lorex Corporation

As our products are subject to continuous improvement, Lorex reserves the right to modify product

design, specifications and prices, without notice and without incurring any obligation. E&OEts

reserved.

LBV2561U_QSG_EN_R2

1080P MPX IR BULLET CAMERA

Quick Start Guide

English Version 2.0

LBV2561U SERIES

Contents

• IR Night Vision Camera*

• Mounting Kit*

• BNC / Power Extension Cable*

• Power Adapter**

Warning/Caution

• Read this guide carefully and keep it for future reference.

• Follow all instructions for safe use of the product and handle with care.

• Use the cameras within given temperature, humidity and voltage levels

noted in ‘Camera Specifications’.

• Do not disassemble the cameras.

• Do not point the cameras directly towards the sun or a source of intense

light.

• Use only the supplied regulated power supply. Use of a non-regulated,

non-conforming power supply can damage this product and voids the

warranty.

• Periodic cleaning may be required. Use a damp cloth only. Do not use

harsh cleaners or aerosol cleaners.

Installation Tips

• Point the cameras where there is the least amount of obstructions (i.e. tree

branches).

• Install the cameras where they are difficult for vandals to reach.

• Secure cabling so that it is not exposed or easily cut.

• Cameras rated for outdoor use. Installation in a sheltered location

recommended.

* Per camera in multi-camera packs.

**A Multi-Camera Power Adapter that provides power to multiple cameras or individual power

adapters may be provided, depending on product configuration.

Disclaimers:

* For a full list of compatible recorders, visit lorextechnology.com/compatibility

** Stated IR illumination range is based on ideal conditions in typical outdoor night time ambient

lighting and in total darkness. Actual range and image clarity depends on installation location,

viewing area and light reflection / absorption level of object.

*** Not intended for submersion in water. Installation in a sheltered location recommended.

7.8” /199 mm

2.8” / 71mm

Dimensions

Resources

Need Help?

Visit us online for up-to-date software and complete

instruction manuals

ATTENTION - A REGULATED power supply is REQUIRED for use with this

camera. Use of a non-regulated, non-conforming power supply can damage

this product and voids the warranty.

Vist www.lorextechnology.com

Search the model number of your product

Click on your product in the search results

1

2

3

4

Click the Downloads tab

2.8” / 71mm
