Pagina 1/2
GB IE NI Recyclable
GB IE NI Not dimmable
GB IE NI Alternating
current
˜
GB IE NI For internal use
GB IE NI Do not disperse the
product in the environment
GB IE NI Protection Class II
GB IE NI Degree of
Protection
IP20
0-14
GB IE NI
Luminaire not
adapted to children under
14, as powered at 220-
240 V ~
GB IE NI Luminaire
designed for self-shielded
lamps
GB IE NI This symbol
indicates that the lamp
cannot be used if the outer
shell is broken
GB IE NI Illuminated globe Ø 30
Intended use
Illuminated Geographical Globe 30 cm for educational use.
Suitable for indoor use only.
Contents of the box - Illuminated globe (bulb included) with meridian arc attached
and base, instructions leaet.
Technical specications
Globe Ø approx. 30 cm
Overall height approx. 41 cm
Scale 1:42,500,000
Cable lenght approx. 1,88 m
Bulb 220-240 V ~, 50/60 Hz max 18W E14
SAFETY INSTRUCTIONS
Please follow these warnings to avoid personal injury or damage!
• The illuminated globe is not a toy. Children should use it only under adult
supervision.
• The illuminated globe is an electrical appliance if placed on raised surfaces,
make sure it is stable to avoid slipping or falling.
• A damaged cable should only be replaced by the manufacturer or a qualied
electrician.
• If after unpacking and connecting, the light does not work, make sure the bulb
is screwed in tightly.
• Never remove the plug from the socket by pulling on the cord.
• Do not hang or drape anything on the globe.
• Keep these instructions for future reference.
Instructions for assembling the globe
• Screw in the lower part of the arc to the base (see picture A) by turning the base. (See
picture B).
• Plug in into the power outlet.
• Switch the light on/o.
Instructions for changing the bulb - CAUTION! Always use the correct bulb
size: LED type E14, max 18W, 220-240V ~ 50/60 Hz.
• Disconnect the illuminated globe from the electric supply and wait a few minutes for
the bulb to cool down.
• Carefully pull up the meridian arc until the axel comes out of the globe. (See picture 1).
• Hold the meridian arc up and push the globe forward. (See picture 2, arrow direction 2).
• Be careful not to scratch the globe with the axel.
• To change the bulb, please use a cloth.
• Now lift out the globe from the lamp base (see picture 2, arrow direction 3) and unscrew
or tighten the light bulb (see picture 3, arrow direction 4 or 5).
This product contains a light source of energy eciency class F.
Disposal of plug
- Applicable for globes equipped with UK plug only
If the non rewireable plug is to be cut o, the removed plug should be disposed of carefully
as there is a shock hazard should the plug be inserted into a live socket.
Replacing fuse - Applicable for globes equipped with UK plug only
This fuse. In the event of the fuse failing it should only be plug is tted with a 3A
replaced by a 3A fuse that complies with BS1362.
The wires in the main lead are coloured in accordance with the following code:
Blue = Neutral & Brown = Live.
The wires should be connected to the plug terminals as follows:
Blue – Neutral
Brown – Live
Do not connect either wire to the earth terminal.
Caring for your globe
• Firstly, unplug your globe and allow it to cool down.
• Clean the surfaces by using a damp cloth.
• Use water only, never use alcohol or other cleaning solvents which would permanently damage
the surfaces.
• Do not expose to direct sunlight.
DISPOSAL OF WASTE EQUIPMENT BY USERS IN PRIVATE HOUSEHOLDS
IN THE EUROPEAN UNION - This symbol on the product or on its packaging
indicates that this product must not be disposed of with your other household
waste. Instead, it is your responsibility to recycle this product by handing this
equipment to a designated collection point for the recycling of waste electrical and
electronic equipment. The separate recycling of the equipment at the time of its
disposal will help to conserve natural resources and ensure that it is recycled in a
manner that protects human health and the environment. For more information
about where you can drop o your waste equipment for recycling, please contact
your local council or the shop where you purchased the product.
WARRANTY
The product is under warranty for a period of 3 years from the date of purchase. Please
keep your receipt as proof of purchase. This warranty covers all substitutions or repairs
due to material or manufacturing defects at our discretion. This warranty does not cover
broken lamp bulbs. Once the warranty has expired, you can send your globe to the
address mentioned below for repairs at your own expense. Your legal rights shall not be
limited by our conditions of warranty. Please phone or email the customer service center
regarding the procedure to follow when your product needs substituting or mending.
1H00ISMUEN-LI 06/2021
5
Type GLOBUS LED
IAN
367074_2101
L= 51 mm
Ø= 23 mm
3000
instant full
of full light output
220-240 V
~
200 lm
200 lm
Aufwärmzeit für 60%
der Lichtleistung
Sofort volles
Licht
100.000
25.000 h
[ ]Kelvin
23 mm
51 mm
> 80
Energy eciency class
Energieezienzklasse
F
Manufacturer and Service Address:
Tecnodidattica S.p.A.
Via G. Garibaldi, 67 - 16040 San Colombano C. / Italy
Tel. +39 0185 358101 - Fax +39 0185 358592
info@tecnodidattica.it
