For pressure sewer applications, verify a Redundant Check Valve Assembly (curb stop and check valve) is installed between the pump

discharge and the street main, as close to the public right-of-way as possible, on all installations to protect from system pressures.

IMPORTANT: All Liberty Pumps systems are supplied with their own separate

Installation/Operation/Maintenance manuals. Ensure receipt of these

manuals, and that they are read and understood prior to installation. For

questions, call Liberty Pumps customer service at 1-800-543-2550.

Installer: Manual must remain with owner or

system operator/maintainer.

Record information:

System:

Model(s):

Keep this manual handy for future reference.

For replacement manual, visit LibertyPumps.com,

or contact Liberty Pumps at 1-800-543-2550.

Retain dated sales receipt for warranty.

Serial(s):

7000 Apple Tree Avenue

Bergen, NY 14416

ph: 1-800-543-2550

fax: 1-585-494-1839

www.LibertyPumps.com

Control Panel:

Mfg Date:

Install Date:

Installation Manual

7353000L

Copyright © Liberty Pumps, Inc. 2024

All rights reserved.

Duplex Grinder Systems

D3648, D3660, D3672, D3684, D3696, and D36120-Series

•36” Diameter Fiberglass Basin

•Available in 48”, 60”, 72”, 84”, 96” and 120” Heights

Features

•LSG Grinder Pump (2hp, 208/230V)

•-or-

•LSGX Grinder Pump (2hp, 208–230V)

•Pre-mounted Float System

–QuickTree® Float System on heights to 84”

•GR20 Guide Rail System

•NEMA 4X Duplex Control Panel

•NEMA 4X Junction Box
