P/NO : MFL59506804
www.lge.com
INSTALLATION MANUAL
AIR CONDITIONER
• Please read this installation manual completely before installing the product.
• Installation work must be performed in accordance with the national wiring
standards by authorized personnel only.
• Please retain this installation manual for future reference after reading it
thoroughly.
TYPE : WALL MOUNTED (LSN/LSU-HSV2/HV2)
FRANÇAIS
ESPAÑOL
ENGLISH
2 Air Conditioner
Air Conditioner Installation Manual
CONTENTS
Safety Precautions............................4
Introduction........................................7
Symbols used in this Manual..........7
Installation ..........................................8
Installation Parts ..............................8
Installation Tools...............................8
Installation Map................................9
Select the best Location ..............10
Fixing Installation Plate .................11
Drill a Hole in the Wall...................11
Flaring Work...................................12
Connecting the Piping...................13
Connecting the Cables..................19
Checking the Drainage .................22
Forming the Piping ........................23
Air Purging .....................................24
Test Running..................................26
Installation guide at the seaside ...28
Piping Length and Elevation.........29
❏ Some pieces of type "A" screws
❏ Connecting cable
❏ Installation guide map
❏ Pipes: Gas side
Liquid side
❏ Insulation materials
❏ Additional drain pipe
(Outer diameter ..............15.5mm)
❏ Some pieces of type "B" screws
❏ Some pieces of type "C" screws
❏ Level gauge
❏ Screw driver
❏ Electric drill
❏ Hole core drill(ø70mm)
❏ Horizontal meter
❏ Flaring tool set
❏ Specified torque wrenches
1.8kg.m, 4.2kg.m, 5.5kg.m,
6.6kg.m
(different depending on model No.)
❏ Spanner ........................Half union
❏ A glass of water
❏ Hexagonal wrench(4mm)
❏ Gas-leak detector
❏ Vacuum pump
❏ Gauge manifold
❏ Owner's manual
❏ Thermometer
❏ Remote controller holder
Installation
Requirements
Required Parts Required Tools
