Levenhuk Binoculars

User manual

Objective lens

Eyepieces

Focusing/diopter adjustment ring

Compass case

Compass light switch (7x50: not shown)

Battery compartment (8x30: not shown)

Tripod socket cover

Strap mount (7x50: not shown)

A

B

C

D

E

F

G

H

Caution! Never look directly at the Sun through this device, as this may cause permanent eye damage and even blindness.

General information

Marine, reliable and sturdy, Levenhuk Nelson binoculars produce a perfect at image and are a perfect choice for people who like to travel a lot,

especially on the water, and oen nd themselves in extreme situations and harsh conditions, where regular binoculars just would not do. The

rugged shell protects the intricate optical system inside from any sudden impacts or moisture, and withstands poor weather conditions, rain

and sea waves.

Features:

•High-quality Porro prisms made of fully multi-coated BaK-4 optical glass;

•Waterproof shells (IPX7), embossed for the perfect grip;

•Eyecups made of so rubber;

•Individual focusing and diopter adjustment mechanisms;

•Built-in compass with diode light for easy orienting in any light conditions;

•Rangender scale for convenient measuring of the observed object’s size or distance to the object;

•Adaptable to a tripod (purchased separately).

The kit includes: Levenhuk Nelson binoculars, dust caps for eyepieces and objective lenses, strap, pouch and optics cleaning wipe, batteries,

user manual and warranty.

Focusing and diopter adjustment

Your le eye vision might be dierent from that of your right eye and you might need to adjust the diopter settings and focus the image. The

focusing is individual, which is typical for marine binoculars. Each optical tube is focused independently.

Follow this procedure to adjust focus and diopter setting:

•Set right and le eyepiece to zero.

•Look through the binoculars at an object about 100 meters away.

•Close your right eye and rotate the le focusing wheel until the view is focused in the le eyepiece; then, do similarly for the le eye and

right eyepiece.

The binoculars are now adjusted to your eyesight. Note the diopter adjustment for further reference.

Interpupillary distance adjustment

Look through the binoculars’ eyepieces with both eyes. To adjust the interpupillary distance, keep varying the angle between the binoculars’

parts (relative to its central axis) until the image merges into a single circle. Remember the setting for future use.

Levenhuk Nelson 8x30 Levenhuk Nelson 7x50
