Pagina 1/23

USER MANUAL

ETX series

Version 2.0

ENGLISH | DEUTSCH | FRANÇAIS | NEDERLANDS | ESPAÑOL

TABLE OF CONTENTS

LANGUAGES

ETX-SERIES – USER MANUAL – ENGLISH

GB ENGLISH 2

DE GERMAN DEUTSCH 30

FR FRENCH FRANÇAIS 58

NL DUTCH NEDERLANDS 86

ES SPANISH ESPAÑOL 114

1. Important Information ...................................................................................................... 3

1.1. Use ..............................................................................................................................................3

1.2. Exemptions ..................................................................................................................................3

2. Safety Instructions ............................................................................................................. 4

2.1. Safety Precautions ........................................................................................................................4

2.2. Moving and Carrying Notice .........................................................................................................5

2.3. Installation ...................................................................................................................................5

2.4. Wall Mount Safety Notice .............................................................................................................6

2.5. Recommended Use ......................................................................................................................7

2.6. Cleaning ......................................................................................................................................8

3. Package Contents ............................................................................................................. 9

3.1. Unpacking ....................................................................................................................................9

3.2. Included Accessories .....................................................................................................................9

4. Installation ........................................................................................................................ 9

4.1. Environment State ........................................................................................................................ 9

4.2. General overview of the screen...................................................................................................10

4.3. In- and output connector table ...................................................................................................12

4.4. Remote Control ..........................................................................................................................12

5. Operating the screen ...................................................................................................... 13

5.1. Turning the display on and off .................................................................................................... 14

5.2. Quick launch menu ....................................................................................................................14

5.3. Float menu .................................................................................................................................15

5.4. Settings menu ............................................................................................................................ 15

5.5. Updating the screen ...................................................................................................................18

5.6. Enabling / Disabling Android ......................................................................................................18

6. Touch Operation ............................................................................................................. 18

7. Speciﬁcations .................................................................................................................. 19

8. Supported Timings .......................................................................................................... 21

9. Serial Commands ............................................................................................................ 21

9.1. Serial Communications ...............................................................................................................21

9.2. RS-232 Connection and Port Conﬁguration ................................................................................21

9.3. RS232 Interface ..........................................................................................................................22

10. Troubleshooting ............................................................................................................ 24

11. Compliance .................................................................................................................. 24

12. Appendix ...................................................................................................................... 25

12.1. Dimensions ..............................................................................................................................25

13. Accessories ................................................................................................................... 29

13.1. EasyFix Video Conferencing Unit ..............................................................................................29

13.2. EasyFix Proximity Sensor ...........................................................................................................29

WARNING:

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

ALSO, DO NOT USE THIS UNIT‘S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTABLE OR

OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED.

REFRAIN FROM OPENING THE E-SCREENS HOUSING AS THERE ARE HIGH VOLTAGE COMPONENTS

INSIDE.

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED

FROM WALL SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT

THE POWER CORD FROM THE AC OUTLET. DO NOT REMOVE COVER (OR BACK). NO USER

SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE

IMPORTANT INFORMATION

1. IMPORTANT INFORMATION

1.1. USE 1.2. EXEMPTIONS

• Transport the product upright with proper

packaging. Avoid placing the product face up or

down. Handle with care!

• Do not send a static (non-moving) image to the

e-screen, it may cause image ‘burn-in’ or image

retention.

• “Burn in” and/or image retention is not covered

under warranty.

• Make sure to change the image on the e-screen

periodically. It is recommended to turn off the

e-screen for at least 6 hours after 16 hours of

usage in a 24 hour period to help avoid image

retention.

• This product isn’t warranted for any damage

caused by natural disaster (such as earthquake,

thunder, etc.), ﬁre, acts by third parties,

accidents, owner’s intentional misuse and fault,

or use in other improper conditions.

• This product isn’t warranted for incidental

damages (such as proﬁt loss or interruption in

business, modiﬁcation or erasure of record data,

etc.) caused by use or inability to use of this

product.

• This product isn’t warranted for any damage

caused by inappropriate operation, or from not

following the user manual.

• This product isn’t warranted for any damage

caused by misuse or malfunction through

simultaneous use of this product and the

connected equipment or software.

• This product isn’t warranted for any damage

caused by neglect of the installation

instructions.

• This product isn’t warranted for any damage

caused by improper installation.

• This product isn’t warranted for any damage

caused by disassembly, modiﬁcation or repair by

non-authorized service centers or people.

ETX-SERIES – USER MANUAL – ENGLISH

Product specificaties

Merk:	Legamaster
Categorie:	Monitor
Model:	ETX-8620-PLUS
Kleur van het product:	Zwart
Gewicht verpakking:	75000 g
Breedte verpakking:	288 mm
Diepte verpakking:	2110 mm
Hoogte verpakking:	1300 mm
Ondersteunde mobiele besturingssystemen:	Y, Android
Bluetooth:	Ja
Beeldschermdiagonaal:	86 "
Resolutie:	3840 x 2160 Pixels
Touchscreen:	Ja
Oorspronkelijke beeldverhouding:	16:9
Wi-Fi-standaarden:	Wi-Fi 5 (802.11ac)
Bluetooth-versie:	5.0
Grafische adapter:	Mali G51 MP4
Inclusief besturingssysteem:	Android
Ondersteuning voor plaatsing:	Horizontaal
Ethernet LAN:	Ja
Ondersteunde video-modi:	480p, 768p, 720p, 1024p, 1080i, 1080p, 2160i, 2160p
Kijkhoek, horizontaal:	178 °
Kijkhoek, verticaal:	178 °
Beeldscherm vorm:	Flat
Typische contrastverhouding:	1200:1
Touch technologie:	Multi-touch
Helderheid:	400 cd/m²
Land van herkomst:	China
Douane productcode (TARIC):	85285210
LED backlight:	Ja
Aantal USB 2.0-poorten:	1
VGA (D-Sub)poort(en):	1
Aantal HDMI-poorten:	4
PC audio ingang:	Ja
DVI-poort:	Nee
Aantal Ethernet LAN (RJ-45)-poorten:	2
Ingebouwde luidsprekers:	Ja
Gemiddeld vermogen:	45 W
Stroomverbruik (in standby):	0.5 W
Vermogensverbruik (max):	225 W
Aantal luidsprekers:	3
Beeldscherm, aantal kleuren:	1.073 biljoen kleuren
RS-232C:	Ja
HD type:	4K Ultra HD
Ingebouwde microfoon:	Nee
Intern geheugen:	4 MB
Processor architectuur:	ARM Cortex-A73 + ARM Cortex-A53
Audio-uitgang:	1
Intern geheugentype:	DDR4
Operating systeem versie:	8
HDMI:	Ja
Display technologie:	LCD
Responstijd:	8 ms
Pixel pitch:	0.4935 x 0.4935 mm
VESA-montage:	Ja
Paneelmontage-interface:	800 x 600 mm
Beeldverhouding:	16:9
Contrast ratio (dynamisch):	5000:1
Ingebouwde camera:	Nee
Diepte ( zonder voet ):	89 mm
Hoogte (zonder voet ):	1140 mm
Breedte ( zonder voet ):	1960 mm
Gewicht (zonder voet):	64000 g
Plug and play:	Nee
On Screen Display (OSD)-talen:	ENG, DEU, DUT, FRE
Aantal DisplayPorts:	1
Energieverbruik (HDR) per 1000 uur:	225 kWu
Energie-efficiëntieklasse (HDR):	D
AMD FreeSync:	Nee
NVIDIA G-SYNC:	Nee
Type processor:	Ja
On Screen Display (OSD):	Ja
Backlight type:	Direct LED
Soort voeding:	AC
Temperatuur bij opslag:	-20 - 60 °C
Soort paneel:	TFT/IPS
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:	3
Grootte beeld (diagonaal):	2180 mm
Luchtvochtigheid bij opslag:	35 - 85 procent
Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C:	1
Ondersteunt Linux:	Ja
Grootte beeld (horizontaal):	1900 mm
Grootte beeld (verticaal):	1070 mm
Ophangsysteem voor aan de muur:	Ja
Hoeveelheid simultane aanraakpunten:	32
Touchscreen technologie:	Infrarood
Hardheid oppervlak:	Mhos 7
OPS-modulesleuf:	Ja
USB Touch port:	Ja
Wifi:	Ja
AC-ingangsspanning:	100 - 240 V
AC-ingangsfrequentie:	50 - 60 Hz
Stroomverbruik (typisch):	360 W
Bedrijfstemperatuur (T-T):	0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V):	20 - 85 procent
Energie-efficiëntieschaal:	A tot G
Breedte rand:	20 mm
Glas dikheid:	3 mm
Aantal USB Touch-poorten:	3
Europees Productregister voor Energielabeling (EPREL) code:	558241
