Bedienungsanleitung

18

LedinoLED LIGHTING

the energy saving company

Spitzahornweg 1

14974 Ludwigsfelde/ Berlin

Germany

LedinoDeutschland GmbH

the energy saving company

Technical Data:

Ledino LED Floodlight „Riem“ 20 W + 50 W

220-240 V AC 50/60 Hz, 20/ 50 watts

warm white 3000 K, CRI > 80 Ra, SDCM < 6

PF=0.9, isolation class 1

lifetime 30000 h, 20000 switching cycles

operating temperature: -20 to 40 °C

120° beam angle, not dimmable

die-cast aluminium housing, plastic di󱐯usor (PC)

aluminium spike with oodlight holder

impact resistance IK 10 - 20 joules hammer

blow (5 kg from distance 40 cm)

3 m cable (3 x 1.0 mm²) with „Schuko“ plug

oodlight: IP65 - protected against jets of water

plug: IP44 - protected against splashing water

functional warranty 3 years*

11110203001022 „Riem 20“

20 watts, 1400 lumens, LED chip (85 lm/W)

1400 lm LED light corresponds to approx. 150 W halogen light

3 m cable, H: 425, B: 130, T: 46 mm, 0.795 kg

20 kWh/1000, energy class A+

11110503001022 „Riem 50“

50 watts, 3320 lumens, LED chip (80 lm/W)

3320 lm LED light corresponds to approx. 350 W halogen light

3 m cable, H: 495, B: 200, T: 46 mm, 1.195 kg

50 kWh/1000, energy class A+

LED-Strahler mit Erdspieß

11110203001022 Riem 20

11110503001022 Riem 50

Hohe Energieeinsparung • Energieklasse A+ • Lange Lebensdauer

Geringe Wärmeabstrahlung • 100 % Licht sofort • Quecksilberfrei

We hereby conrm that the products are in line with the regulations – and in particular

with the protection requirements – of the European Union’s directive on the harmoni-

sation of the legislation relating to electromagnetic compability (2014/30/EU), the low

voltage directive 2014/35/EU, the directive for Energy-related Products 2009/125/EG

and the RoHS directive 2011/65/EC.

Used units must not be disposed of with household waste!

If the unit is no longer operational, every consumer is required by law to dispose of used

devices separate from household waste, e. g. at a collection point run by the communal

authority borough. In this way, used devices can be recycled and waste materials disposed

of in an environmentally friendly manner.

For this reason, electrical equipment is labelled with the displayed symbol.

IP65/ IP44

*) The conditions of our functional warranty can be found on enclosed sheet and on the internet at

„http://ledino.com/garantiebestimmungen/“
