33210 Rev. R http://www.transition.com/ Page 1 of 17

E-100BTX-FX-05

User Guide

Stand-Alone Media Converter

• Fast Ethernet

• Copper to Fiber

• 100Base-TX to 100Base-FX

• Extended Temperature

Contents

Introduction.................................................................................................................................................... 1

Standard Temperature Models .................................................................................................................2

Extended Temperature Models ................................................................................................................3

Installation .....................................................................................................................................................4

4-Position DIP Switch ...............................................................................................................................4

AutoCross Jumpers ..................................................................................................................................5

Installing the Fiber Cable ..........................................................................................................................6

Installing the Copper Cable ...................................................................................................................... 6

Powering the media converter ..................................................................................................................7

Operation....................................................................................................................................................... 8

Status LEDs ..............................................................................................................................................8

Auto-Negotiation .......................................................................................................................................8

Pause Control ...........................................................................................................................................8

Link Pass-Through ....................................................................................................................................8

Far-End Fault ............................................................................................................................................9

Optic and Cable Specifications ...............................................................................................................10

Cable Specifications ...............................................................................................................................10

Contact Us................................................................................................................................................... 15

Compliance Information ..............................................................................................................................16

Declaration of Conformity .......................................................................................................................16

Record of Revisions ....................................................................................................................................17

Introduction

Transition Networks E-100BTX-FX-05 Fast Ethernet media converters connect 100Base-TX shielded or

unshielded twisted-pair copper cable to 100Base-FX fiber-optic cable. The E-100BTX-FX-05 series media

converters include both Standard temperature models and Extended temperature models.

Standard Temperature Models: media converters that can be used in a standard temperature

environment from 0°C to 50°C (32°F to 122°F)

Extended Temperature Models: media converters with the “HT” extension in the part number can be

used in an extended temperature environment from -25°C to 65°C (-13°F to 149°F).
