LaCie 5big Thunderbolt 2 User Manual 1

LACIE 5BIG THUNDERBOLT 2 USER MANUAL

Click to access an here up-to-date online version

of this document. You will find the most recent content as well as expandable illustrations, easier

navigation, and search capability.

LaCie 5big Thunderbolt 2 User Manual 2

INTRODUCTION

WHAT IS IN THIS MANUAL

Welcome to the User Manual for the LaCie 5big Thunderbolt™1) 2. The LaCie 5big

is a desktop direct-attached storage, or DAS. Connect it to a computer that

supports Thunderbolt 2 technology for transfer rates that reach up to 20Gb/s!

LaCie has constructed the 5big Thunderbolt 2 to handle bandwidth-intensive

content such as raw 4K and 3D graphics so that professional editors,

photographers, and graphic artists get the highest performing storage for their

most challenging projects.

Use this manual to guide you through the process of connecting your LaCie storage. For questions on

installation, consult the page.Getting Help

BOX CONTENTS

LaCie 5big Thunderbolt 2

■

External power supply

■

Thunderbolt cable

■

Drawer key

■

Cable lock clip

■

Quick Install Guide

■

Note on the power supply: The included power supply is meant for use with the LaCie 5big Thunderbolt 2.

It is not compatible with other models of the LaCie 5big enclosure. Further, the LaCie 5big Thunderbolt 2

cannot use power supplies shipped with other models of the LaCie 5big enclosure.

Important info: Save your packaging. In the event that the product should need to be repaired or serviced,

it must be returned in its original packaging.

LaCie 5big Thunderbolt 2 User Manual 3

MINIMUM SYSTEM REQUIREMENTS

Client types

Mac OS X 10.9 and later

■

A computer that supports Thunderbolt 2 technology or first generation Thunderbolt technology. To take

■

advantage of the higher performance offered by Thunderbolt 2 technology, your computer must have a

Thunderbolt 2 technology port (see ).LaCie 5big Thunderbolt 2: Advanced Storage Technology

Important info:

Your LaCie product's performance can be affected by such external forces as type of cable, hardware,

distance, and setup.

For optimal performance: use the cables provided with your device or, cables supported by LaCie; make

certain to follow the installation instructions provided in the Quick Install Guide and this user manual.

Product specificaties

Merk:	LaCie
Categorie:	Disk array
Model:	5big Thunderbolt 2
Kleur van het product:	Wit
Gewicht:	7600 g
Breedte:	173 mm
Diepte:	196 mm
Hoogte:	220 mm
Geluidsniveau:	29 dB
LED-indicatoren:	Ja
Meegeleverde kabels:	Thunderbolt
Bevestigingsmogelijkheid voor kabelslot:	Ja
Kabelslot sleuf type:	Kensington
Meegeleverde software:	Intego® Backup Manager Pro\r\nLaCie Private-Public (protect data with AES 256-bit encryption)\r\nLaCie RAID Manager (administration console)
Aantal ventilatoren:	1 ventilator(en)
Ondersteunt Mac-besturingssysteem:	Mac OS X 10.9 Mavericks
Type behuizing:	Desktop
Opslagdrives geïnstalleerd:	Ja
Geïnstalleerde opslag-drive:	HDD
Capaciteit opslag-drive:	4000 GB
Totale geïnstalleerde opslagcapaciteit:	20 TB
Maximaal ondersteunde opslagcapaciteit:	30 TB
Aantal storage drives geïnstalleerd:	5
HDD rotatiesnelheid:	7200 RPM
Minimale opslag schijfruimte:	600 MB
Soorten RAID:	0, 1,5, 6,10, JBOD
Overdrachtssnelheid:	20 Gbit/s
Aantal storage drives ondersteund:	5
AC-ingangsspanning:	100-240 V
AC-ingangsfrequentie:	50 - 60 Hz
Stroomverbruik (typisch):	150 W
Hot-swap drive bays:	Ja
Thunderbolt technologie:	Ja
Ondersteunde types opslag-drives:	HDD
Host-poorten:	2
Thunderbolt-versie:	1
