Kramer TP-583R Handleiding

Kramer AV extender TP-583R

Bekijk gratis de handleiding van Kramer TP-583R (15 pagina’s), behorend tot de categorie AV extender. Deze gids werd als nuttig beoordeeld door 38 mensen en kreeg gemiddeld 5.0 sterren uit 19.5 reviews. Heb je een vraag over Kramer TP-583R of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/15

P/N: 2900-301246 Rev 1 www.KramerAV.com

USER MANUAL

MODELS:

TP-583Txr, TP-583T

HDMI Line Transmitter

TP-583Rxr, TP-583R

HDMI Line Receiver

Kramer Electronics Ltd.

TP TP TP TP-583Txr, -583Rxr, -583T, -583R Contents –

Contents

Introduction 1

Getting Started 1

Overview 2

Typical Applications 3

Dening TP-583Txr and TP- 4583T

Dening TP-583Rxr and TP-583R 5

Mounting TP-583Txr 6

Connecting the extenders 7

Connecting to an Extender via RS- 8232

Wiring HDBT RJ-45 Connectors 8

Controlling TP-583Txr 9

Technical Specications 10

TP-583Txr and TP-583Rxr 10

TP-583T and TP-583R 11

Kramer Electronics Ltd.

TP TP TP TP-583Txr, -583Rxr, -583T, -583R Introduction –

Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world

of unique, creative, and aordable solutions to the vast range of problems that confront the

video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we

have redesigned and upgraded most of our line, making the best even better!

Getting Started

We recommend that you:

• Unpack the equipment carefully and save the original box and packaging materials for

possible future shipment.

• Review the contents of this user manual.

Go to www.kramerav.com/downloads/TP-583Txr to check for up-to-date user manuals,

application programs, and to check if rmware upgrades are available (where appropriate).

Achieving the Best Performance

• Use only good quality connection cables (we recommend Kramer high-performance,

high-resolution cables) to avoid interference, deterioration in signal quality due to poor

matching, and elevated noise levels (often associated with low quality cables).

• Do not secure the cables in tight bundles or roll the slack into tight coils.

• Avoid interference fro neighboring electrical appliances that may adversely inuence m

signal quality.

• Position your Kramer extender away from moisture, excessive sunlight and dust.

Safety Instructions

Caution:

• This equipment is to be used only inside a building. It may only be connected to other

equipment that is installed inside a building.

• There are no operator serviceable parts inside the unit.

Warning:

• Use only the power cord that is supplied with the unit.

• To ensure continuous risk protection, replace fuses only according to the rating

specied on the product label which located on the bottom of the unit.

Product specificaties

Merk:	Kramer
Categorie:	AV extender
Model:	TP-583R
Kleur van het product:	Zwart
Gewicht:	300 g
Breedte:	120 mm
Diepte:	71.5 mm
Hoogte:	24.4 mm
Gewicht verpakking:	700 g
Breedte verpakking:	157 mm
Diepte verpakking:	120 mm
Hoogte verpakking:	87 mm
Soort:	AV-receiver
LED-indicatoren:	Ja
Stroom:	2 A
Connectiviteitstechnologie:	Bedraad
Ondersteunde video-modi:	1080p, 2160p
Maximum resolutie:	4096 x 2160 Pixels
Certificering:	CE, UL, WEEE
Aansluiting voor netstroomadapter:	Ja
Materiaal:	Aluminium
Ondersteunde grafische resoluties:	3840 x 2160,4096 x 2160
Duurzaamheidscertificaten:	RoHS
Temperatuur bij opslag:	-40 - 70 °C
Bandbreedte:	18 Gbit/s
Aantal HDMI-uitgangen:	1
RJ-45 invoer ports:	1
Operating voltage:	12 V
Maximaal bereik:	70 m
Bedrijfstemperatuur (T-T):	0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V):	10 - 90 procent
Stroomverbuik (ontvanger) (max):	680 mA
