P/N: 2900-301659 Rev 4 www.kramerav.com

USER MANUAL

MODEL:

KDS-100EN / KDS-100DEC

4K AVoIP H.264 / H.265 Encoder / Decoder

Kramer Electronics Ltd.

KDS-100 Series – Contents


Contents
Contents  2
Introduction  3
1  Getting Started  3
2  Overview  4
3  Typical Applications  5
4  Controlling your KDS-100 device  5
Defining the KDS-100  6
1  Defining KDS-100EN  6
2  Defining KDS-100DEC  8
Mounting KDS-100  10
Connecting KDS-100  11
1  Connecting KDS-100EN to KDS-100DEC  11
2  Connecting RS-232  12
3  Connecting the Audio/Input Output  13
4  Installing the SFP transceiver (optical SM/MM or copper)  13
Operating and Controlling KDS-100 Devices  14
1  Using the Channel Selection Buttons  14
2  Operating via Ethernet  15
3  The streaming protocols and how to configure them  16
4  Configuring the Network Switch  19
5  Connecting KDS-100EN to a 3rd party decoder  20
KDS-100EN: Using the Embedded Web Pages  22
1  Dashboard: Set channel and audio, view input signal  23
2  Streaming: Multicast settings and time to live  25
3  Encoding: Method, protocol, scaling, bitrate and more  26
4  EDID: Set display metadata  29
5  Gateway: RS-232 settings  30
6  Device: General device, network and time settings  31
7  Security: Passwords, HTTPS and 802.1X  34
8  About: Web version and contact details  37
KDS-100DEC: Using the Embedded Web Pages  38
1  To Browse the KDS-100DEC Web Pages:  39
2  Dashboard: Set channel and audio, view input signal  39
3  AV Settings: Decoding, resolution and overlays  42
4  External Devices  44
5  EDID: Set display metadata  46
6  Gateway: RS-232 settings  47
7  Device Settings: General device, network and time settings  48
8  Security: Passwords, HTTPS and 802.1X  52
9  About: Web version and contact details  55
Upgrading Firmware  56
Technical Specifications  57
1 KDS-100EN Specifications  57
2 KDS-100DEC Specifications  58
Protocol 3000  59
1 Understanding Protocol 3000  59
2 Protocol 3000 Commands  60
3 Result and Error Codes  71
