Pagina 1/16
Installation Guide
Stainless Steel Trough Sinks
Mproduct numbers are for Mexico (i.e. K-12345 )M
Los números de productos seguidos de
Mcorresponden a México (Ej.
K-12345 )M
Français, page “Français-1”
Español, página“ Español-1”
K-3179 K-3187
K-3188 K-3189
1022023-2-B
Thank You For Choosing Kohler Company
We appreciate your commitment to Kohler quality. Please take a few
minutes to review this manual before you start installation. If you
encounter any installation or performance problems, please don’t
hesitate to contact us. Our phone numbers and website are listed on
the back cover. Thanks again for choosing Kohler Company.
Tools and Materials
Before You Begin
Refer to the Homeowners Guide to determine all necessary
components for your installation.
The Kohler K-5806 or K-5807 Kit is appropriate for use with this
undercounter installation.
Observe all local plumbing and building codes.
Inspect the drain and supply tubing. Replace if necessary.
For multiple sink installations, a minimum distance of 2-3/16″
(5.6 cm) is required between the sinks. Any required support
should be determined by the countertop supplier.
All information in these instructions is based on the latest product
information available at the time of publication. Kohler Co.
reserves the right to make changes at any time without notice.
Pencil and
Marker
Measuring
Tape
Drill
Putty Knife
Scissors
Keyhole/Compass
or Saber Saw
Safety
Glasses
Sealant
1022023-2-B 2 Kohler Co.
1. Preparation
NOTE: You may require different, more specialized tools to install
this sink to countertop materials other than wood or wood
composites.
NOTE: For multiple bowl installations of single basin sinks, a
minimum distance of 2-3/16 (5.6 cm) is required between bowls.″
Any required support should be determined by the countertop
supplier.
Cut along the inside of the template line where indicated for the
countertop opening.
Position the template on the countertop. Check for adequate
clearance between the sink, faucet, backsplash and cabinet.
Trace around the template on the countertop with a pencil.
Centerlines are provided to help align the opening.
Locate the faucet hole centerlines on the countertop. Faucet
centerline clearance from the top of the cut-out must be 2-3/8 (6″
cm) minimum.
2-3/8" (6 cm)
Min.
Cutting Line
Faucet Centerline
Template
Kohler Co. 3 1022023-2-B
