1007287-2-A

2001 Kohler Co.

  

  



FLEUR



LITE



VITREOUS CHINA

REVERSE TRAP TOILET

BEFORE YOU BEGIN

HOW TO USE THESE INSTRUCTIONS

Please read these instructions carefully to familiarize yourself with

the required tools, materials, and installation sequences. Follow the

sections that pertain to your particular installation. This will help you

avoid costly mistakes.In addition to proper installation, read all

operating and safety instructions.

All information in these instructions is based upon the latest product

information available at the time of publication. Kohler Co. reserves

the right to make changes in product characteristics, packaging, or

availability at any time without notice.

These instructions contain important care, cleaning, and warranty

information – please leave instructions for the consumer.

ORDERING INFORMATION

Fleur



Lite



ToiletK-3447. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Bowl K-4267(M)

Tank K-4606

When specified:

3/8” supplyK-7637. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Floor bolts (pair)21401. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

NOTES

The K-3447 has a 12” (30.5cm) roughing-in dimension.

Ensure that the new toilet has the correct roughing-in

dimension. See Fig. #1.

Seat post holes on 5-1/2” (14cm) centers.

Water depth from rim is 6-7/8” (17.5cm).

2” (5cm) passageway.

Be very careful while working with vitreous china

products. Vitreous china can break or chip if the bolts

and nuts are overtightened, or if carelessly handled.

Carefully inspect the new fixture for any sign of damage.

Observe all local plumbing and building codes.

Shut off the water supply.

For new construction, refer to the dimensions in Fig. #1

and Fig. #4 for locating the supply shut-off valve.

Fixture dimensions are nominal and conform to

tolerances established by ANSI Standards (A112.19.2).

Provide adequate trip lever clearance if shelving or other

structures are to be installed above the toilet tank. See

Fig. #1.

TOOLS AND MATERIALS REQUIRED

10” adjustable wrench

1/2” open end wrench

12” pipe wrench

Metal file (file cut)

Tape measure

Tubing cutter

Level

Hacksaw

Putty knife

Screwdriver

Toilet gasket (wax seal)

Toilet T-bolts (2), 5/16” diameter

Toilet setting compound (optional)

Toilet supply shut-off valve, 3/8” recommended

NOTICE:If the existing toilet does not have a supply shut-off

valve below the tank, install one before installing the new toilet.
