Pagina 1/16

Instruction

Manual

Español pág. 9

English p. 1

Português pág. 17

Français p. 25

LAN Scout™ Jr.

VDV526-052

• EaSY to rEaD

LcD ScrEEN

• Data caBLE tEStING

• DEtEctS SHortS,

opENS, rEVErSaLS,

MISWIrES, aND

SpLIt paIrS

• toNE GENErator

• auto poWEr-off

ENGLISH



LAN Scout™ Jr.





The Klein Tools LAN Scout™ Jr. is a portable data cable tester. It tests and

troubleshoots RJ45 terminated cables and provides built-in tone generation

for cable tracing.

  4.6" x 2.3" x 1.1" (11.7 x 5.8 x 2.8 cm)

  4.0 oz. (115 grams) with battery and remote

  0°C to 50°C / 32°F to 122°F

  -20°C to 60°C / -4°F to 140°F

  10% to 90%, non-condensing

  between any two connectors pins without damage:

 66V DC or 55V AC

 : 6V alkaline batteries - 4 x LR44

 3.5 years

 80 hours

  Shielded or Unshielded; Cat-7, Cat-6x, Cat-5E, Cat-5,

Cat-4, Cat-3

  0 to 1000 feet (305 meters)

 :

1.5 feet (0.5 meters)



To ensure safe operation and service of the tester, follow these instructions.

Failure to observe these warnings can result in severe injury or death.

• The LAN Scout™ Jr. is designed for use on unenergized cabling

systems. Connecting the LAN Scout™ Jr. to live AC power may damage

it and pose a safety hazard for the user.

• Poorly terminated RJ plugs have the potential to damage the jack on

the LAN Scout™ Jr. Visually inspect a RJ plug before inserting it into

the tester. The contacts should always be recessed into the plastic

housing of the plug. Plugging 6-position plugs into the 8-position jack

on the tester has the potential to damage the outer-most contacts of

the jack unless the plug is specically designed for

that purpose.



The LAN Scout™ Jr. has a single button to both start a test and select other

functions and options. Presses of less than about 1 second (short press) and

more than 1 second (long press) are recognized differently.

 With the LAN Scout™ Jr. off, each short

press of the button causes a cable test to be executed and the results

displayed for 20 seconds before powering off. “TEST” is displayed

while testing is being performed. If another short press occurs before

the 20 second time out another test and 20 second time out begin.

If the button is pressed and held until “LOOP” is displayed and then

released, tests are run continuously and the display updated. The LAN

Scout™ Jr. will turn off automatically if there is no test result change

for 5 minutes. A long press of the button will cause the LAN Scout™

Jr. to exit cable test loop mode and enter mode selection as discussed

below.

 Starting with the LAN Scout™ Jr. off, a

long press of the button will cause the LAN Scout™ Jr. to enter mode

selection. In mode selection the LAN Scout™ Jr. cycles through cable

test and tone generator modes. The mode displayed when the button

is released will begin execution. From powered off, the modes in order

are:

  Cable test that loops continuously until it times out or

is exited by a long press that reenters mode selection. Used to

troubleshoot intermittent problems.

  The next four modes

are all tone generator modes with different sounds. The “Hi Lo”

tones are made up of two frequencies with different timings. “Hi”

and ”Lo” are single frequency. Once in a tone mode, short presses

change the pins carrying tone. The pins with tone are displayed. In

a tone mode, the Jr. will turn off automatically 30 minutes after the

last button press or by exiting to mode select with a long press.

  When the button is released with “OFF” displayed, the Jr. will

power off. Once in one of the above modes, OFF is the rst mode

offered upon exiting to mode select. To select a different mode

other than OFF, continue to hold the button down and the next

mode in rotation will be displayed next.

  The cable test mode is the single cable test mode with 20

second timeout that a short press from powered off executes.



Product specificaties

Merk:	Klein Tools
Categorie:	Kabels voor pc's en randapparatuur
Model:	LAN Scout Jr. VDV526-052
Kleur van het product:	Black, Yellow
Ingebouwd display:	Ja
Gewicht:	110 g
Breedte:	58.3 mm
Diepte:	241.3 mm
Hoogte:	117.1 mm
Aan/uitschakelaar:	Ja
Ondersteund aantal accu's/batterijen:	4
Gebruiksvriendelijk:	Ja
Soort kabel:	CAT3, CAT5/5e, CAT6/6A
Operating voltage:	6 V
Batterijen inbegrepen:	Ja
Type product:	Tester voor kabels met getwiste aderparen
Batterijtechnologie:	Alkaline
Type batterij:	LR44
Testtype:	Continuïteitstest
Ondersteunde aansluitingen:	RJ-45
