MICROWAVE HOOD COMBINATION

INSTALLATION INSTRUCTIONS

This product is suitable for use above electric or gas cooking products up to and including 36" (91.4 cm) wide. See the “Installation

Requirements” section for further notes.

These installation instructions cover different models. The appearance of your particular model may differ slightly from the illustration

in these installation instructions.

Table of Contents

MICROWAVE HOOD COMBINATION SAFETY

W11496338A

MICROWAVE HOOD COMBINATION SAFETY ............................1

INSTALLATION REQUIREMENTS .................................................2

Tools and Parts ............................................................................2

Separate cardboard template ......................................................2

Location Requirements ................................................................2

Product Dimensions .....................................................................3

Electrical Requirements ...............................................................3

INSTALLATION INSTRUCTIONS ...................................................4

Remove Mounting Plate ...............................................................4

Rotate Blower Motor ....................................................................4

Locate Wall Stud(s) ......................................................................7

Mark Rear Wall .............................................................................7

Drill Holes in Rear Wall .................................................................8

Attach Mounting Plate to Wall .....................................................8

Prepare Upper Cabinet ................................................................9

Install Damper Assembly

(for wall venting only) ..................................................................10

Install the Microwave Oven ........................................................10

Complete Installation .................................................................11

VENTING DESIGN SPECIFICATIONS ........................................12

ASSISTANCE ................................................................................14

Replacement Parts .....................................................................14

Accessories ................................................................................14
