Pagina 1/4
1
ERECTION INSTRUCTIONS
FOR SHERPA 2, 3 & 4
BEFORE USE
PLEASE TAKE TIME TO READ AND UNDERSTAND THE ERECTION INSTRUCTIONS. FAILURE
TO ERECT THE TENT IN ACCORDANCE WITH THE INSTRUCTIONS MAY RESULT IN
DAMAGE TO BOTH FABRIC AND POLE SYSTEMS. SUCH DAMAGE CANNOT BE COVERED BY
THE WARRANTY.
WARNING!!
DO NOT PUSH TENT PEGS IN BY HAND, ALL TENT PEGS SHOULD BE DRIVEN HOME USING A
WOODEN OR RUBBER FACED MALLET OR SIMILAR TOOL.
TO ENSURE MAXIMUM POSSIBLE WATERPROOFING THE MAIN FLY SHEET SEAMS HAVE BEEN
TAPED. SHOULD THE TAPE BE DAMAGED AND PEEL AWAY YOU CAN EFFECT A REPAIR BY
USING SEAM SEALER AROUND THE PROBLEM AREA.
WE ALSO RECOMMEND THAT SEEM SEALER IS APPLIED TO UNTAPED SEEMS TO PREVENT
LEAKAGE.
IT IS IMPORTANT THAT YOU DO NOT ALLOW SEAM SEALER TO CONTAMINATE THE TEETH OF
ANY ZIPS AS THIS WILL PREVENT THE ZIP FROM FUNCTIONING CORRECTLY.
IF YOU DO USE SEAM SEALER IT IS BEST APPLIED WHEN THE TENT IS DRY. PICK A DRY WARM
DAY TO CARRY OUT ANY SEALING AND PLEASE ALLOW 48 HOURS FOR THE SEALANT TO
CURE PRIOR TO RE-PACKAGING THE TENT.
FAILURE TO ALLOW THE SEALANT TO DRY FULLY PRIOR TO PACKING THE TENT UP WILL
STICK THE FABRIC TOGETHER POSSIBLY CAUSING IRREPARABLE DAMAGE.
DURING USE
TENTS CONTAINING A HIGH PROPORTION OF SYNTHETIC MATERIALS ARE SOMETIMES
AFFECTED BY CONDENSATION, THIS SHOULD NOT BE CONFUSED WITH LEAKAGE AND CAN
USUALLY BE CURED BY ENSURING THAT ADEQUATE VENTILATION IS AVAILABLE BY
LEAVING DOORWAYS SLIGHTLY UNZIPPED WHEREVER POSSIBLE.
DO NOT PITCH UNDER TREES, MAKE USE OF NATURAL WIND BREAKS LIKE HEDGES OR
WALLS, FACE THE TENT DOOR AWAY FROM THE PREVAILING WIND. USE TWO HANDS WHEN
OPENING AND CLOSING ZIPS, THIS WILL HELP PREVENT PREMATURE ZIP FAILURE.
READ AND UNDERSTAND THE FIRE PRECAUTIONS INFORMATION ATTACHED TO THE INSIDE
OF THE TENT.
CARE OF YOUR TENT WARNING!!
TENT FABRICS CAN BE WEAKENED BY PROLONGED EXPOSURE TO SUNLIGHT, UNDER
NORMAL HOLIDAY USE YOUR TENT WILL GIVE YOU LONG SERVICE BUT ERECTION FOR
EXTENDED PERIODS IN STRONG SUNLIGHT WILL CAUSE DETERIORATION.
IF YOU ARE LIKELY TO USE YOUR TENT FOR PROLONGED PERIODS IT WOULD BE WISE TO USE
A SITE WHICH IS A SHADED AS POSSIBLE.
TENTS ARE BEST STORED OPENED OUT, IF THIS IS NOT POSSIBLE AIR FULLY AND ENSURE IT IS
TOTALLY DRY BEFORE PACKING IT AWAY AT THE END OF YOUR HOLIDAY.
STORE YOUR TENT IN A WELL VENTILATED DRY PLACE. LOOK AFTER YOUR TENT AND IT
WILL LOOK AFTER YOU.
HAVE ANY DAMAGE TO YOUR TENT REPAIRED AT FIRST OPPORTUNITY.
FAILURES IN FIBERGLASS POLES NORMALLY OCCUR THROUGH INCORRECT USE, MAKE SURE
THE POLE SECTIONS ARE FULLY INSERTED INTO THEIR ADJOINING FERULES AND DO NOT
OVER STRESS THE POLE BEYOND IT’S DESIGNED CURVE. ZIPS SHOULD BE TREATED WITH
CARE TO PREVENT PREMATURE FAILURE AND THE TENT SHOULD BE KEPT CLEAN AND DRY
AFTER USE.
2
INSURANCE
WE HIGHLY RECOMMEND THAT YOUR TENT BE INSURED AGAINST THEFT AND STORM OR
ACCIDENTAL DAMAGE. STORM OR ACCIDENTAL DAMAGE IS NOT COVERED BY THE
WARRANTY.
CHECK YOUR EQUIPMENT BEFORE GOING AWAY WITH YOUR TENT. ENSURE THAT YOU ARE
FAMILIAR WITH THE PITCHING OF THE TENT AND THAT ALL PARTS ARE PRESENT.
YOU SHOULD FAMILIARIZE YOURSELF WITH THE TENT, INCLUDING ANY LIMITATIONS THAT
IT MAY HAVE FOR YOUR PARTICULAR USE.
DOME TENTS ARE PORTABLE STRUCTURES WHICH UNDER MOST CIRCUMSTANCES WILL
PROVIDE COMFORTABLE SHELTER AGAINST THE ELEMENTS. THERE ARE HOWEVER
EXTREMES OF WEATHER FOR WHICH ALLOWANCES SHOULD BE MADE.
DO NOT BLAME THE TENT !
ERECTING YOUR TENT
1: REMOVE THE CONTENTS OF THE CARRY BAG AND IDENTIFY ALL THE COMPONENT PARTS.
• INNER TENT
• FLYSHEET
• POLE BAG AND CONTENTS
• PEG BAG AND CONTENTS
2: SELECT A SITE THAT IS CLEAR OF ANY SHARP OBJECTS, STICKS AND STONES E.T.C
3: IN THE POLE BAG, SHOULD BE
1/ THREE EQUAL LENGTHS OF SHOCKCORDED FIBERGLASS POLES.
2/ 2 X CANOPY POLES ( ONCE ASSEMBLED THESE WILL HAVE A SPIKE AT ONE END AND A
BASE BUNG ON THE OTHER )
ASSEMBLE ALL THREE SHOCKCORDED POLES.
4: UNFOLD THE FLYSHEET AND SPREAD OUT ON THE FLOOR SO YOU ARE ABLE TO SEE THE
THREE SLEEVE SECTIONS OF THE ROOF.
TAKING ONE SHOCKCORDED FIBERGLASS POLE, THREAD THE POLE THROUGH A SLEEVE
SECTION, SO THERE IS AN EQUAL LENGTH OF POLE PROTRUDING FROM EITHER SIDE OF THE
SLEEVE.
ONCE THE POLE IS THREADED INTO PLACE CHOOSE ONE END OF THE POLE AND ENGAGE THE
END FERRULE INTO THE WEBBING RETAINING FIXTURE OR EYELET. THIS WILL BE LOCATED
AT THE BASE OF THE FLYSHEET, NEAR TO THE SEAM RUNNING DOWN FROM THE SLEEVE IN
WHICH THE POLE IS LOCATED. EACH POLE RETAINING FIXTURE WILL HAVE A METAL RING
WITH ONE OR MORE RETAINING PINS ATTACHED TO IT ( DEPENDANT UPON MODEL ).
THE RETAINING PIN IS DESIGNED TO SLIDE UP INSIDE THE POLE ENDS THUS SECURING THE
POLE INTO PLACE.
FROM THE OPPOSITE END OF THE SAME POLE CAREFULLY PUSH THE REMAINING POLE
THROUGH THE SLEEVES SO IT ASSUMES A SEMI-CIRCULAR SHAPE. WHEN THE END FERRULE
IS LEVEL TO THE WEBBING RETAINING FIXTURE ON THIS SIDE, ENGAGE IT INTO PLACE AS
BEFORE.
ENSURE CARE IS TAKEN DURING THIS PROCEDURE, NOT TO ALLOW THE ENDS OF THE
SHOCKCORDED POLES TO DAMAGE SLEEVES OR FLYSHEET MATERIAL.
RUNNING DOWN THE SEAM, FROM THE SLEEVE, ON EACH SIDE OF THE TENT YOU WILL
NOTICE THREE FLYSHEET TO MAIN POLE WEBBING CLIPS. ALL THESE, SHOULD SIMPLY BE
CLIPPED TO THE MAIN SHOCKCORDED POLES ALLOWING THE FLYSHEET TO TAKE FULL
SHAPE. PLEASE NOTE THAT THESE ARE NOT INTENDED AS GUY POINT FIXINGS
5: TAKING THE SECOND AND THIRD POLES SEPARATELY, REPEAT POINT 4. IT IS BEST TO
START AT ONE END OF THE FLYSHEET I.E. BY THE FRONT DOOR AND WORK TOWARDS THE
BACK OF THE TENT.
3
DURING BOTH POINTS 4 & 5 ENSURE THAT THE POLE JOINING FERRULES DO NOT CATCH ON THE
INSIDE OR EDGE OF THE MATERIAL SLEEVES. SHOULD THIS HAPPEN CAREFULLY FREE THE
SLEEVE BEFORE CONTINUING. FAILURE TO FREE THE SLEEVE MAY CAUSE THE MATERIAL TO
TEAR AND OR STITCHED SEAMS TO BURST
6: THE FLYSHEET SHOULD NOW BE READY FOR PEGGING.
POSITION THE FLYSHEET SO THAT THE DOOR IS FACING AWAY FROM THE PREVAILING WIND.
CLOSE ALL THE ZIPS ON THE FLYSHEET.
STARTING FROM EITHER END, PEG THE TWO END PEGGING LOOPS ON ONE END FIRST AND
THEN PEG THE SAME TWO POINTS ON THE OPPOSITE END OF THE TENT. THIS SHOULD NOW
ALLOW THE FLYSHEET TO ASSUME IT’S NATURAL SHAPE.
YOU MAY FIND IT NECESSARY TO ADJUST THE TWO END PEGGING POINTS IN ORDER TO GET
THE OVERALL LAY OF THE FLYSHEET FABRIC SMOOTH AND FREE FROM WRINKLES OR FOLDS
ONCE YOU ARE SATISFIED WITH THE OVERALL LAY OF THE FLYSHEET YOU CAN THEN AND
ONLY THEN PEG THE REMAINING PEGGING LOOPS INTO POSITION.
ATTACH ALL THE GUY ROPES TO ALL THE GUYING POINTS AND PEG SECURELY, AT A
SUITABLE DISTANCE FROM THE TENT. TRY NOT TO PEG TOO CLOSE TO THE TENT AS THIS
WILL NOT GIVE ADEQUATE SUPPORT AND MAY CAUSE THE FABRIC UNDER THE GUY POINT
ITSELF TO BECOME BAGGY OR LOOSE THUS ALLOWING INNER AND OUTER TO TOUCH.
THE FRONT AND REAR GUY POINTS SHOULD BE ADEQUATELY TENSIONED TO PREVENT THE
POOLING OF WATER ON THE INDIVIDUAL ROOF SECTIONS
THE PEGS PROVIDED WITH THIS TENT ARE STANDARD PEGS, SUITABLE FOR MOST TERRAIN’S.
HOWEVER THERE WILL BE OCCASIONS WHEN THE GROUND MAY BE FAR TOO HARD OR ROCKY
AND EQUALLY TOO BOGGY OR SANDY. IN THIS INSTANCE SPECIALIST PEGS CAN BE PURCHASED
THROUGH YOUR LOCAL RETAILER AND SHOULD BE USED
7: UNFOLD THE INNER TENT AND PLACE IT INSIDE THE FLYSHEET. ENSURE THAT THE
DOORWAY OF THE INNER TENT IS PLACED ON THE SAME SIDE AS THE DOORWAY OF THE
FLYSHEET.
IF “D” RINGS ARE PROVIDED ON THE INSIDE BASE OF THE MAIN POLE WEBBING STRAPS
SIMPLY CLIP THE INNER TO THEM WITH THE “DOG LEAD” TYPE CLIPS ON THE CORNERS OF
THE INNER TENT.
IF THE INNER TENT HAS PEGGING LOOPS SIMPLY PEG THE INNER TENT INTO POSITION.
AN ELASTIC TOGGLE AND RING SYSTEM SUSPEND THE INNER TENT, FROM THE INSIDE OF THE
FLYSHEET. THE ELASTIC LOOPS AND TOGGLES ARE FOUND ON THE INNER TENT WHILE THE
SUSPENSION LOOPS AND RINGS ARE FOUND ON THE FLYSHEET
THE ELASTIC LOOPS AND TOGGLES SHOULD SIMPLY BE FED THROUGH THE CORRESPONDING
LOOPS AND RINGS ON THE FLYSHEET.
OPEN THE DOOR OF THE INNER TENT AND KNEEL DOWN ON THE GROUNDSHEET. STARTING
AT THE BACK CONNECT ALL THE LOOPS AND RINGS ON THE REAR POLE SECTION. WORK
FORWARD UNTIL THE INNER IS COMPLETELY SUSPENDED.
YOUR TENT IS NOW READY FOR USE, ENJOY YOUR HOLIDAY.
A SET OF UPRIGHT CANOPY POLES ARE PROVIDED WHICH ALLOW THE FRONT AND OR SIDE
DOORS TO BE ERECTED AS A SUN CANOPY IF SO DESIRED.
AS WEATHER CONDITIONS CAN CHANGE BOTH DRAMATICALLY AND QUICKLY WE RECOMMEND
THAT YOU PITCH YOUR TENT READY TO ACCEPT ANY INCLEMENT WEATHER CONDITIONS. THE
FRONT AND OR SIDE CANOPY SHOULD NOT BE LEFT UP OVERNIGHT OR WHILST THE TENT IS
UNATTENDED. GUY LINES ARE ATTACHED TO YOUR TENT AND SHOULD BE USED AT ALL TIMES.
