INSTALLATIONINSTRUCTIONS
PREPARETHEWINDOW
3/4(or1/)
Screws
(7)
2
LockFrame
(2)
SashLock
(1)
MountingHardware
Windowsash
sealfoam
(1)
PREPAREAIRCONDITIONER
C:Aligntheholeinthetoprailwiththoseinthetop
oftheunitasshowninFig.B
D:Securethetoprailtotheunitwiththe3/8Screws
asshowninFig.C.
Forsafetyreasons,allfour(4)screwsMUST
besecurelyfastened.
NOTE:
INSTALLTHEACCORDIONPANELS
NOTE:ToprailandSlidingPanelsateachsideare
offsettoprovidetheproperpitchtotherearof(5/16).
Thisisnecessaryforpropercondensedwater
utilizationanddrainage.IfyouarenotusingtheSide
Panelsforanyreason,thispitchtotherearmustbe
maintained.
A.Placeunitonfloor,abenchor
atable.HoldtheAccordion
Panelinonehandandgently
pullbackthecentertofreethe
openend.SeeFig.1
Fig.1
Lowersashmustopensufficientlytoallowaclear
verticalopeningof13inches(330mm).Sidelouvers
andtherearoftheACmusthaveclearairspaceto
allowenoughairflowthroughthecondenser,forheat
removal.Therearoftheunitmustbeoutdoors,not
insideabuildingorgarage.
A:Removetheairconditionerfromthecartonand
placeonaflatsurface.
B:Removetoprailfromtherearofthepackaging
materialasshowninFig.A.
Packaging
Fig.
A
TopRail
Fig.B
Fig.C
TopRailHardware
3/8Screws
(4)
TopRail
(1)
or
TopRailHardware
3/8Screws
(4)
TopRail
(1)
or
