CR-901

CPU heat sink

hux nut

flat ring gasket

Open wrench

根据需要将螺杆装入INTER对应孔位内，

将隔套内螺母朝上拧紧固定。

Install threaded rod to the corresponding holes of INTEL bracket

as needed fixing it with nut facing up.

将INTER支架安装到散热组上，并用螺丝拧紧。

Place INTEL bracket on the cooler base, and then use bracket

screws to fix it.

将主板孔位对准散热器定位螺丝，反扣于散热组上。

装入绝缘垫片。

Install insulating washers.

Fix the coolers on the motherboard by fixing the hex nuts

with the wrench.

用开口板手拧紧六角螺母，将散热阻固定到主板上。

The board in place, the fan wire connector is

connected with the mainboard .

主板归位后，将风扇导线接头与主板连接。
