Pagina 1/8
JBL Tower X Marine 10" Speaker
JBL Tower X Marine 10" Speaker Installation Guide
Guide d’installation de l’enceinte marine 10" JBL Tower X
Guía de instalación del altavoz JBL Tower X Marine 10"
ES
FR
EN
EN
JBL Tower X Marine 10" Speaker
THANK YOU FOR YOUR PURCHASE . . .
Your JBL product has been designed to provide you with the performance and ease of operation you would expect from
JBL.
ABOUT THE MANUAL
This manual describes general installation guidelines. However, please note that proper installation of marine audio
components requires qualified experience. If you do not have the knowledge and tools to successfully perform this
installation, we strongly recommend consulting an authorized JBL dealer about your installation options. Keep all
instructions and sales receipts for reference.
WHAT’S IN THE BOX
2X
2X
1X
1X
4X
2X
2X
2X
4X
4X
4X 4X
2X
1X
2X
2X
EN
DIMENSIONS
15-5/16" (388.9mm)
16-11/16" (424mm)
12" (305mm)
12-1/8" (307.5mm)
MOUNTING
Mounting the speaker
1. Place the clamp around the horizontal bar of the tower.
2. Use the included M8 bolts to secure the clamp; insert the bolts from the top and turn clockwise with the included hex
key to tighten. For a secure fit, use the included rubber mats between the clamp and the bar.
3. Slide the speaker onto the clamp from below.
4. Secure the speaker onto the clamp using the included M6 bolt; insert the bolt into the hole inside the wiring channel at
the base of the mounting sleeve. Turn clockwise with the included hex key to tighten.
NOTE: Be sure to align the bottom of the clamp with the hole through which speaker and LED wires pass into the wake
tower bar. Feed any remaining wire into the bar to prevent pinching.
2
1
3
4
Swiveling the speaker
Loosen the mounting bolt. Swivel speaker to the desired angle (up to 360°). Tighten the bolt to secure in place.
