Key Features:

䉴

Stylish, contemporary appearance

enhances any decór.

䉴

Clear sound from an 8 inch dual-

cone full-range driver.

䉴

Very high sensitivity of 97 dB for

maximum sound levels using

minimum amplifier power.

䉴

6W transformer for use on

70V/100V distributed speaker lines

䉴

Installs to in-ceiling backboxes

having 4mounting points on an

11-¼" (286 mm) diameter mounting

circle.

䉴

For use with MTC-81BB8 backcan

and MTC-81TB8 tile bridge

Overview:

The 8138 is an 8" ceiling speaker

designed for use with a pre-install in-

ceiling backcan, resulting in high-

fidelity performance at a cost-

effective price point. The 8138 is

ideal for a wide variety of

commercial sound applications from

restaurant and retail to professional

offices and reception areas.

The built-in 6 Watt transformer

allows use on 70V or 100V

distributed speaker lines. High

sensitivity of 97 dB delivers

maximum sound levels using minimal

amplifier power, allowing the use of

smaller power amplifiers compared to

when using lower sensitivity drivers.

The driver features a 25 mm (1 in)

voicecoil with Kapton coil former for

reliability. The treated cloth surround

provides deeper bass response

compared with typical paper-roll

surrounds, for fuller sound quality.

The 8138 fits the MTC-81BB8

backcan and MTC-81TB8 tile bridge,

or can be used with most in-ceiling

backcan/tile bridge systems designed

with four mounting points on a 286

mm (11¼in) diameter mounting

circle.

With its contemporary grill design,

the 8138 provides a stylish upscale

look that fits into many decórs. The

8138 brings style and performance to

basic commercial sound systems.

Specifications:

Component:200 mm (8 in) Full-Range, Dual-cone

Frequency Range (-10 dB):95 Hz – 18 kHz

Coverage (2 kHz):90°conical

Sensitivity (2.83V@ 1m):97 dB (1 kHz - 8 kHz)

Driver Power Capacity:40W (160W peak), 2 hrs

25W (100W peak), 100 hrs

70V/100V Transformer Taps:6W, 3W, 1.5W, (0.75W at 70V only)

Color Codes:

Black = Common

Orange = 6W at 70V

Brown = 3W at 70V; 6W at 100V

Blue = 1.5W at 70V; 3W at 100V

White = 0.75W at 70V; 1.5W at 100V

Termination:Bare Wire

Magnet:10 ounces (283 g)

Safety Agency:Suitable for use in air handling spaces per UL1480,

UL2043, NFPA90 & NFPA 70 when installed with UL listed

backcan such as JBL MTC-81BB8. S7232/UL/cUL Listed,

Signaling Speaker. Transformer UL registered per UL1876.

In accordance with IEC60849/EN60849.

Installation:Full assembly consists of 8138 speaker plus MTC-81BB8

backbox and MTC-81TB8 tile bridge.

Four screw holes at industry standard 286 mm (11¼in)

mounting circle.

Dimensions (Diameter x Depth):327 mm (12.9") diameter baffle x 84 mm (3.3") depth

from back of baffle. Overall depth, 99 mm (3.9")

Mounting Points:4 points on 286 mm (11.25 in) dia. mounting circle

Ceiling Cutout Dimension:300 mm (11.75") with tile bridge and backbox.

228 mm (9.0") diameter as stand alone.

Net Weight:1.4 kg (3.0 lb)

Included Accessories:Integral grille, 4 pcs M4 x 40 mm tapping screws

Optional Accessories:MTC-81BB8 backcan

MTC-81TB8 tile bridge

8" (200 mm) Full-Range

In-Ceiling Loudspeaker for

Use with Pre-Install Backcans

Professional Series

8138
