USB-C® Triple-Monitor
10Gbps Mini Dock
Compatible with USB4® devices
JCD397
English
Français
■
Features
● Advanced USB-C® E-Mark chip integrates USB4®, Thunderbolt™ 3 and Thunderbolt™ 4 compatibility
● Three SuperSpeed USB™ 10Gbps downstream ports (1 USB-C® and 2 Type-A) to connect peripherals
● Charge and power connected laptop and peripherals with 100W Power Delivery
●
SD™ & microSD™ 4.0 memory card reader/writer for media storage and transfer
● Easily add a wired network connectivity with the Gigabit Ethernet port
● Plug-and-play, no driver installation required
● Supports dual 4K 60Hz or triple 4K 30Hz (2 HDMI™ and 1 DisplayPort™) on compatible USB-C® laptops with
DisplayPort™ 1.4 alt mode with MST support*
■
System Requirements
● Available USB-C® port that supports DisplayPort™ alternate mode and USB™ Power Delivery 2.0 or 3.0.
Please refer to the manufacturer of your computer for more information about your device
● The host device must support Multi-Stream Transport (MST) for multi-monitor configuration
●
The host device must support DisplayPort™ 1.4 to achieve 4K resolution at 60 Hz
■
Notes
● A host laptop without MST support can only connect to one additional monitor
● The MST protocol is not currently supported by macOS® or Chrome OS™.
The display output is limited to mirror mode when connected.
● A 4K-capable display is required for obtaining the 3840 x 2160 resolution
● If connected to a USB™ 2.0 host port, or if using a USB™ 2.0 host cable, performance may be limited
● The mini dock can connect to a USB-C® port that doesn’t support Power Delivery, but it will not pass power
through the connected device
● If you are using high-powered USB™ devices, attach a USB-C® power adapter to the power delivery port to
ensure maximum performance. To avoid disruption, do not remove the power adapter while copying files.
● We advise no more than one (1) bus-powered/portable external hard disk drive to be connected to the
adapter at a time
■
Características
● El chip avanzado USB-C® E-Mark integra compatibilidad con USB4®, Thunderbolt™ 3 y Thunderbolt™ 4
● Tres puertos SuperSpeed con puertos descendinetes USB™ 10Gbps
(1 USB-C® y 2 Type-A) para conectar periféricos
● Carga y alimenta el portátil y los periféricos conectados con 100W Power Delivery
● Lector / grabador de tarjetas de memoria SD™ y microSD™ 4.0 para almacenamiento y transferencia de medios
● Agregue fácilmente una conectividad de red por cable con el puerto Gigabit Ethernet
● Plug-and-play, no requiere instalación de controlador
● Admite 4K doble a 60 Hz o 4K triple a 30 Hz (2 HDMI™ y 1 DisplayPort™) en equipos portátiles USB-C®
compatibles con modo alternativo DisplayPort™ 1.4 con compatibilidad con MST*
■
Requisitos del sistema
● Puerto USB-C® disponible que admite el modo alternativo DisplayPort™ y USB™ Power Delivery 2.0 o 3.0
Consulte al fabricante de su computadora para obtener más información sobre su dispositivo
● El dispositivo host debe ser compatible con DisplayPort™ 1.4 para lograr una resolución de 4K a 60 Hz
● El dispositivo host debe admitir Multi-Stream Transport (MST) para la configuración de varios monitores
■
Notas
● Un equipo portátil host sin compatibilidad con MST solo se puede conectar a un monitor adicional
● Actualmente, macOS® o Chrome OS no admiten el protocolo MST. La salida de la pantalla está limitada al
modo reflejado cuando está conectada.
● Se requiere una pantalla compatible con 4K para obtener la resolución de 3840 x 2160
● Si se conecta a un puerto host USB™ 2.0, o si se utiliza un cable host USB™ 2.0, el rendimiento puede ser
limitado
● El adaptador se puede conectar a un puerto USB-C® que no es compatible con Power Delivery, pero no pasará
energía a través del dispositivo conectado
● Si está utilizando dispositivos USB ™ de alta potencia, conecte un adaptador de corriente USB-C® al puerto de
suministro de energía para garantizar el máximo rendimiento. Para evitar interrupciones, no retire el adaptador
de corriente mientras se copian los archivos.
● Aconsejamos que no se conecte al adaptador más de un (1) disco duro externo alimentado por bus o portátil a
la vez
Nederlands
Español
■
Caractéristiques
● La puce USB-C® E-Mark avancée intègre la compatibilité USB4®,
Thunderbolt™ 3 et Thunderbolt™ 4
● Trois ports USB™ SuperSpeed™ 10 Gbps en aval (1 USB-C® et 2 Type-A) pour connecter vos périphériques
● Chargez et alimentez l’ordinateur portable et les périphériques connectés avec 100W Power Delivery
● Lecteur de carte mémoire SD™ & microSD™ 4.0 pour le stockage et le transfert de médias
● Ajoutez facilement une connectivité réseau filaire avec le port Gigabit Ethernet
● Plug-and-play, aucune installation de pilote requise
● Prend en charge deux 4K 60Hz ou triple 4K 30Hz (2 HDMI™ et 1 DisplayPort™) sur les ordinateurs portables
compatibles USB-C® avec mode alt DisplayPort™ 1.4 avec prise en charge MST *
■
Configuration Recommandée
● Port USB-C® disponible qui prend en charge mode alternatif DisplayPort™ et USB™ Power Delivery 2.0 ou
3.0. Veuillez contacter le fabricant de votre ordinateur pour plus d’informations sur votre appareil
● Le périphérique hôte doit prendre en charge le transport multi-flux (MST) pour la configuration multi-moni-
teurs
● Le périphérique hôte doit prendre en charge DisplayPort™ 1.4 pour atteindre une résolution de 4K à 60 Hz
■
A Noter
● Un ordinateur portable hôte sans la prise en charge de MST ne peut se connecter qu’à un moniteur
supplémentaire
● Le protocole MST n’est actuellement pas pris en charge par macOS® ou Chrome OS™. La sortie d’affichage
est limitée au mode miroir lorsqu’elle est connectée.
● Un écran compatible 4K est nécessaire pour obtenir la résolution 3840 x 2160
● Si vous êtes connecté à un port hôte USB™ 2.0 ou si vous utilisez un câble hôte USB™ 2.0, les performances
peuvent être limitées
● La mini station d’accueil peut se connecter à un port USB-C® qui ne prend pas en charge Power Delivery,
mais elle ne transmettra pas d’alimentation par l’appareil connecté
● Si vous utilisez des périphériques USB™ haute puissance, connectez un adaptateur secteur USB-C® au port
d'alimentation pour garantir des performances optimales. Pour éviter toute interruption, ne retirez pas
l'adaptateur secteur pendant la copie des fichiers.
● Nous conseillons de ne pas connecter plus d'un (1) disque dur externe portable/alimenté par bus à
l'adaptateur à la fois
■
Features
● Avancerat USB-C® E-Mark-chip som integrerar USB4®, Thunderbolt™ 3 och Thunderbolt™ 4-kompatibi-
litet
● Tre SuperSpeed USB™ 10 Gbps-portar nedströms (1 USB-C® och 2 Type-A) för anslutning av kringutrust-
ning
● Ladda och strömförsörj anslutna bärbara datorer och kringutrustning med 100 W Power Delivery
● SD™ och microSD™ 4.0-minneskortläsare/skrivare för lagring och överföring av media
● Lägg enkelt till en trådbunden nätverksanslutning med Gigabit Ethernet-porten
● Plug-and-play, ingen installation behövs
● Stöder dubbla 4K 60Hz eller tredubbla 4K 30Hz (2 HDMI™ och 1 DisplayPort™) på kompatibla bärbara
USB-C®-datorer med DisplayPort™ 1.4 Alt Mode med MST-stöd*
■
System Requirements
● Tillgänglig USB-C®-port med stöd för DisplayPort™ alternativt läge och USB™ Power Delivery 2.0 eller 3.0.
Se tillverkaren av din dator för mer information om din enhet
● Värdenheten måste p1-ha stöd för MST (Multi-Stream Transport) för konfiguration med flera bildskärmar
● Värdenheten måste p1-ha stöd för DisplayPort™ 1.4 för att uppnå 4K-upplösning vid 60 Hz
■
Notes
● En bärbar dator utan MST-stöd kan endast ansluta till en extra bildskärm
● MST-protokollet stöds för närvarande inte av macOS® eller Chrome OS™. Displayutgången är begränsad
till speglat läge när den är ansluten.
● En skärm med 4K-kapacitet krävs för att få 3840 x 2160 upplösning
● Om du är ansluten till en USB™ 2.0-värdport eller om du använder en USB™ 2.0-värdkabel kan prestandan
vara begränsad
● Minidockan kan anslutas till en USB-C®-port som inte stöder Power Delivery men den kommer inte att
strömförsörja den anslutna enheten.
● Om du använder USB™-enheter med hög effekt ska du ansluta en USB-C®-strömadapter till strömförsör-
jningsporten för att få maximal prestanda. Ta inte bort nätadaptern när du kopierar filer för att undvika
störningar.
● Vi rekommenderar att inte mer än en (1) bussdriven/portabel extern hårddisk ansluts till adaptern åt
gången
Português
Svenska
■
Eigenschaften
● Fortschrittlicher USB-C® E-Mark Chip integriert USB4®, Thunderbolt™ 3 und
Thunderbolt™ 4 Kompatibilität
● Drei SuperSpeed USB™ 10Gbps Downstream-Anschlüsse (1 USB-C® und 2 Typ-A) zum Anschluss von
Peripheriegeräten
● Laden und Stromversorgung von angeschlossenen Laptops und Peripheriegeräten mit
100 W Power Delivery
● SD™ & microSD™ 4.0 Speicherkartenleser/-schreiber für die Speicherung und Übertragung von Medien
● Einfaches Hinzufügen einer kabelgebundenen Netzwerkkonnektivität mit dem Gigabit-Ethernet-Anschluss
● Plug-and-Play, keine Treiberinstallation erforderlich
● Unterstützt Dual 4K 60Hz oder Triple 4K 30Hz (2 HDMI™ und 1 DisplayPort™) auf kompatiblen USB-C® Laptops
mit DisplayPort™ 1.4 alt Modus mit MST Unterstützung*
■
Systemanforderungen
● Verfügbarer USB-C®-Anschluss, der den DisplayPort™-Alternativmodus und
USB™ Power Delivery 2.0 oder 3.0 unterstützt. Weitere Informationen zu Ihrem Gerät erhalten Sie vom
Hersteller Ihres Computers.
● Das Host-Gerät muss Multi-Stream-Transport (MST) für die Konfiguration mehrerer Monitore unterstützen.
● Das Host-Gerät muss DisplayPort™ 1.4 unterstützen, um eine 4K-Auflösung bei 60 Hz zu erreichen.
■
Hinweise
● Ein Host-Laptop ohne MST-Unterstützung kann nur einen zusätzlichen Monitor verbinden
● Das MST-Protokoll wird derzeit nicht von macOS® oder Chrome OS unterstützt. Die Bildschirmausgabe ist
auf den gespiegelten Modus beschränkt, wenn eine Verbindung besteht.
● Ein 4K-fähiger Bildschirm ist erforderlich, um die Auflösung von 3840 x 2160 zu erhalten.
● Bei Anschluss an einen USB™ 2.0-Hostanschluss oder bei Verwendung eines USB™ 2.0-Hostkabels kann die
Leistung eingeschränkt sein
● Das Mini-Dock kann an einen USB-C®-Anschluss angeschlossen werden, der Power Delivery nicht
unterstützt, leitet aber keinen Strom an das angeschlossene Gerät weiter.
● Wenn Sie USB™-Geräte mit hoher Leistung verwenden, schließen Sie einen USB-C®-Stromadapter an den
Power Delivery-Anschluss an, um maximale Leistung zu gewährleisten. Entfernen Sie den Stromadapter nicht,
während Sie Dateien kopieren, um Unterbrechungen zu vermeiden.
● Wir empfehlen, nicht mehr als ein (1) busgespeistes/portables externes
Festplattenlaufwerk gleichzeitig mit dem Adapter zu verbinden.
■
Features
● A marca eletrónica de chip USB-C® avançada incorpora a compatibilidade com USB4®, Thunderbolt™ 3 e
Thunderbolt™ 4
● Três portas de receção SuperSpeed USB™ de 10 Gbps (1 USB-C® e 2 Tipo A) para ligar periféricos
● Carregue e alimente o computador portátil e os periféricos ligados com fornecimento de energia de 100 W
● Leitor/gravador de cartões de memória SD™ e microSD™ 4.0 para armazenamento e transferência de ficheiros
multimédia
● Adicione facilmente uma ligação de rede com fios com a porta Ethernet Gigabit
● Plug-and-play, sem necessidade de instalação de controlador
● Suporta 4K 60 Hz duplo ou 4K 30 Hz triplo (2 HDMI™ e 1 DisplayPort™) em computadores portáteis USB-C®
compatíveis com o modo DisplayPort™ 1.4 alt com suporte para MST*
■
System Requirements
● Porta USB-C® disponível que suporta o modo DisplayPort™ alternativo e USB™ Power Delivery 2.0 ou 3.0.
Consulte o fabricante do seu computador para obter mais informações sobre o seu dispositivo.
● O dispositivo anfitrião suporta Transporte Multifluxo (MST) para configuração com vários monitores
● O dispositivo anfitrião deve suportar DisplayPort™ 1.4 para alcançar resolução 4K a 60 Hz
■
Notes
● Um computador portátil sem suporte para MST pode ligar-se apenas e um monitor adicional
● O protocolo MST não é atualmente suportado pelo sistema macOS® ou Chrome OS™. Quando ligado, a
saída de monitor está limitada ao modo espelhado.
● Para obter a resolução de 3840 x 2160, é necessário m monitor com capacidade 4K
● O desempenho pode ser limitado se estiver ligado a uma porta anfitrião USB™ 2.0 ou se utilizar um cabo
anfitrião USB™ 2.0
● A estação de ancoragem mini pode ligar a uma porta USB-C® que não suporta a função Power Delivery,
mas não permite o fornecimento de energia através do dispositivo ligado.
● Se utilizar dispositivos USB™ de alta potência, ligue o transformador USB-C® à porta de fornecimento de
energia para garantir o máximo desempenho. Para evitar perturbações, não desligue o adaptador de
corrente durante a cópia de ficheiros.
● Aconselhamos que não utilize mais do que um (1) disco rígido externo portátil/alimentado por
barramento ligado ao adaptador de cada vez
Deutsch
Italiano
DK: Startvejledning
NO: Hurtiginstallasjonsveiledning
FI: Pika-asennusopas
HU: Gyors telepítési útmutató
RU : Руководство по быстрой установке
クイックインストールガイド
日本語 :
繁中文 : 快速安裝手冊
简中文 : 快速安装手册
Guide D'installation Rapide
F
R
:
Kurzanleitung Für Installation
D
E
:
Quick Installation Guide
E
N
:
Guía De Instalación Rápida
E
S
:
IT :
Guida rapida all'installazione
NL : Beknopte installatiehandleiding
PT : Guia de instalação rápida
SE : Snabbinstallationsguide
DisplayPort™ 4K @ 30Hz HDMI™ 4K @ 30Hz HDMI™ 4K @ 30Hz
■
Kenmerken
● Geavanceerde USB-C® E-Mark-chip integreert compatibiliteit met USB4®, Thunderbolt™ 3 en Thunderbolt™ 4
● Drie SuperSpeed USB™ 10 Gbps downstream-poorten (1 USB-C® en 2 Type-A) om randapparatuur aan te
sluiten
● Laad en voed aangesloten laptops en randapparatuur met 100 W Power Delivery
● SD™ & microSD™ 4.0 geheugenkaartlezer/-schrijver voor opslag en overdracht van media
● Voeg eenvoudig een bekabelde netwerkverbinding toe met de Gigabit Ethernet-poort
● Plug-and-play, geen driverinstallatie vereist
● Ondersteunt dual 4K 60Hz of triple 4K 30Hz (2 HDMI™ en 1 DisplayPort™) op compatibele USB-C® laptops
met DisplayPort™ 1.4 alt-modus met MST-ondersteuning*
■
Systeem Vereisten
● Beschikbare USB-C®-poort die DisplayPort™ alternatieve modus en USB™ Power Delivery 2.0 of 3.0
ondersteunt. Raadpleeg de fabrikant van uw computer voor meer informatie over uw apparaat
● Het hostapparaat moet Multi-Stream Transport (MST) ondersteunen voor configuratie met meerdere monitoren
● Het hostapparaat moet DisplayPort™ 1.4 ondersteunen om een 4K-resolutie bij 60 Hz te bereiken
■
Opmerkingen
● Een host laptop zonder MST-ondersteuning kan maar op één extra monitor worden aangesloten
● Het MST-protocol wordt momenteel niet ondersteund door macOS® of Chrome OS™.
De weergave-uitvoer is beperkt tot de gespiegelde modus wanneer deze is aangesloten.
● Een voor 4K geschikt beeldscherm is vereist voor het verkrijgen van de resolutie van 3840 x 2160
● Bij aansluiting op een USB™ 2.0 host-poort of bij gebruik van een USB™ 2.0 hostkabel kunnen de prestaties
beperkt zijn
● Het minidock kan worden aangesloten op een USB-C®-poort die geen Power Delivery ondersteunt, maar zal
geen stroom door het aangesloten apparaat sturen
● Als u krachtige USB™-apparaten gebruikt, sluit dan een USB-C®-voedingsadapter aan op de voedingspoort
om maximale prestaties te garanderen. Verwijder de voedingsadapter niet tijdens het kopiëren van
bestanden om onderbrekingen te voorkomen.
● We raden aan om niet meer dan één (1) busgevoed/draagbare externe harde schijf tegelijk op de adapter
aan te sluiten
■
Caratteristiche
● Il chip avanzato USB-C® E-Mark integra la compatibilità con USB4®, Thunderbolt™ 3 e Thunderbolt™ 4
● Tre porte SuperSpeed USB™ 10 Gbps downstream (1 USB-C® e 2 tipo A) per collegare periferiche
● Ricarica e alimenta laptop e periferiche collegati con Power Delivery da 100 W
● Lettore/scrittore di schede di memoria SD™ e microSD™ 4.0 per l'archiviazione e il trasferimento di
contenuti multimediali
● Aggiunge facilmente una connettività di rete cablata con la porta Gigabit Ethernet
● Plug-and-play, nessuna installazione di driver
● Supporta doppio 4K 60Hz o triplo 4K 30Hz (2 HDMI™ e 1 DisplayPort™) su laptop USB-C® compatibili con
Modalità Alt DisplayPort™ 1.4 con supporto MST*
■
System Requirements
● Porta USB-C® disponibile con supporto DisplayPort™ Alternate Mode e USB™ Power Delivery 2.0 o 3.0.
Consultare il produttore del computer per ulteriori informazioni sul dispositivo
● Il dispositivo host deve supportare Multi-Stream Transport (MST) per la configurazione multi-monitor
● Il dispositivo host deve supportare DisplayPort™ 1.4 per ottenere una risoluzione 4K a 60 Hz
■
Notes
● Un laptop host senza supporto MST può connettersi solo a un monitor aggiuntivo
● Il protocollo MST non è attualmente supportato da macOS® o Chrome OS™. L'uscita del display è limitata
alla modalità Mirror quando è collegata.
● È necessario un display compatibile 4K per ottenere la risoluzione 3840 x 2160
● Se collegato a una porta host USB™ 2.0 o se si utilizza un cavo host USB™ 2.0,
le prestazioni potrebbero essere limitate
● Il mini dock può connettersi a una porta USB-C® che non supporta Power Delivery, p1-ma non passa
l'alimentazione attraverso il dispositivo connesso.
● Se si utilizzano dispositivi USB™ ad alta potenza, collegare l'adattatore di alimentazione USB® alla porta di
alimentazione per garantire prestazioni massime. Non rimuovere l'alimentatore durante la copia dei file
per evitare interruzioni.
● Si consiglia di non collegare più di un (1) disco rigido esterno portatile/
alimentato tramite bus all'adattatore per volta
■
Dual or Triple 4K Display Support
Windows®
Supports dual 4K 60Hz or triple 4K 30Hz on compatible USB-C® laptops
with DisplayPort™ 1.4 alt mode and Multi-Stream Transport (MST)
Windows®
(MST)
Host(A) +B Host(A)+B+C
Host(A)+B+C+D
2-Lane
HBR2
(DP™ 1.2)
3840 x 2160 @ 30
1920 x 1080 @ 60 +
1920 x 1080 @ 60
1920 x 1080 @ 60 +
1920 x 1080 @ 60 + Cannot
display (DP™ or HDMI™)
2-Lane
HBR3
(DP™ 1.4)
3840 x 2160 @ 60
or
1920 x 1080 @ 240
3840 x 2160 @ 60 +
3840 x 2160 @ 30
3840 x 2160 @ 60 +
3840 x 2160 @ 60
*Only for DSC host
3840 x 2160 @ 30 +
3840 x 2160 @ 30 +
3840 x 2160 @ 30
macOS®
Host(A) +B Host(A)+B+B
Host(A)+B+B+B
2-Lane
HBR2
(DP™ 1.2)
3840 x 2160 @ 30 3840 x 2160 @ 30 * 2 3840 x 2160 @ 30 * 3
2-Lane
HBR3
(DP™ 1.4)
3840 x 2160 @ 60
or
1920 x 1080@120
3840 x 2160 @ 60 * 2 3840 x 2160 @ 60 * 3
* The MST protocol is not currently supported by macOS® or Chrome OS™.
* macOS® only supports SST, which means all connected monitors will show
the same content.
* DSC = VESA® Display Stream Compression (DSC) Standard.
Only available on NVIDIA® GeForce® RTX 20 Series and AMD™
Radeon™ RX 6000 Series GPUs or above
* Recommended Graphics Cards: Intel® HD Graphics 620、Intel'® HD Graphics
520 or above
USB4®, USB-C, and USB are trademarks of USB Implementers Forum, Inc., its aliates or its respective owners, registered or used in many jurisdictions
worldwide. HDMI is a trademark of HDMI Licensing Administrator, Inc., its aliates or its respective owners, registered or used in many jurisdictions
worldwide. SD and microSD are trademarks of SD-3, LLC, its aliates or its respective owners, registered or used in many jurisdictions worldwide. Intel and
Thunderbolt are trademarks of Intel Corporation, its aliates or its respective owners, registered or used in many jurisdictions worldwide. Windows is a
trademark of Microsoft Corp., its aliates or its respective owners, registered or used in many jurisdictions worldwide. VESA, DisplayPort, and DP are
trademarks of Video Electronics Standards Association, its aliates or its respective owners, registered or used in many jurisdictions worldwide. macOS is
a trademark of Apple Inc., its aliates or its respective owners, registered or used in many jurisdictions worldwide. Chrome OS is a trademark of Google
LLC, its aliates or its respective owners, registered or used in many jurisdictions worldwide. NVIDIA and GeForce are trademarks of NVIDIA Corporation,
its aliates or its respective owners, registered or used in many jurisdictions worldwide. AMD and Radeon are trademarks of Advanced Micro Devices, Inc.,
its aliates or its respective owners, registered or used in many jurisdictions worldwide. Other trademarks and trade names may be used in this document
to refer to either the entities claiming the marks and/or names or their products and are the property of their respective owners. All company, product and
service names used are for identication purposes only. Use of these names, logos, and brands does not imply endorsement. We disclaim any interest in
the marks of others.
STOP!
If you have any problems with this product please contact our technical
support team before returning it to the store.
202204-V2
TECHNICAL SUPPORT
Customer Service :
888-988-0488
Technical Support :
888-689-4088
Email :
service@j5create.com
SOPORTE TÉCNICO
Número gratuito: +1-888-988-0488
Horario de atención:
Lun-Vier. 10:00 a.m – 6:00 U.S.A-E.S.T
Email: service@j5create.com
TECHNISCHER SUPPORT
Kostenloser Anruf bei: +1-888-988-0488
Sprechstunden:
Mon.-Frei. 10.00 – 18.00 U.S.A-E.S.T
E-mail: service@j5create.com
SUPPORT TECHNIQUE
Numéro gratuit : +1-888-988-0488
Heures d’ouverture :
Lun.-Ven. 10:00 a.m – 06:00 U.S.A-E.S.T
Email : service@j5create.com
TECHNIKAI SEGÍTSÉG
Vevőszolgálat (angol nyelven): 888-988-0488
Technikai támogatás (angol nyelven): 888-689-4088
E-mail: service@j5create.com
テクニカルサポート
お客様相談センター:03-5540-9010
電子メール：j5support@solnet.co.jp
テクニカルサポートやその他のご相談は下記
の時間にくださいますようお願い申し上げます
営業時間：平日：9:30˜11:30/13:30˜17:30
技術支援資訊
美國客服專線：+1-888-988-0488
台灣客服專線：+886-2-2269-5533#19
客服時間：星期一至星期五
9:30 AM-6:00PM (台灣時間)
Email信箱：service.tw@j5create.com
TECHNICKÁ PODPORA
Zákaznická linka: 888-988-0488
Technická podpora: 888-689-4088
E-mail: service@j5create.com
Kaijet Technology International B.V.
Telefoonnummer: +31-(0)6-2880 2882
Adres: Zomerdoorn 20,
Rotterdam, Netherlands 3068MZ
E-mail: service@j5create.com
■
Ominaisuudet
● Kehittynyt USB-C® E-Mark -siru integroi USB4®-, Thunderbolt™ 3 - ja Thunderbolt™ 4 -yhteensopivuud-
en
● Kolme SuperSpeed USB™ 10 Gbps -alavirtaporttia (1 USB-C® ja 2 Type-A:ta) oheislaitteiden liittämiseen
● Lataus ja virransyöttö liitetylle kannettavalle ja oheislaitteille 100 W:n virransyötöllä
● SD™- ja microSD™ 4.0 -muistikortinlukija/kirjoitin median tallennukseen ja siirtoon
● Helposti lisättävissä oleva langallinen verkkoyhteys Gigabit Ethernet -portilla
● Plug-and-play, ohjaimien asennusta ei tarvita
● Tuki kaksois-4K 60 Hz:lle tai kolmois-4K 30 Hz:lle (2 HDMI™ ja 1 DisplayPort™) yhteensopivissa
USB-C®-kannettavissa, joissa on DisplayPort™ 1.4 alt -tila- ja MST-tuki*
■
Järjestelmävaatimukset
● Käytettävissä oleva USB-C® -portti, jossa tuki DisplayPort™ alt -tilalle ja USB™-virransyöttö 2.0 tai 3.0.
Kysy tietokoneesi valmistajalta lisätietoja laitteestasi
● Isäntälaitteen on tuettava Multi-Stream Transport (MST) -ominaisuutta usean monitorin määrityksiä varten
● Isäntälaitteen on tuettava DisplayPort™ 1.4:ää 4K-resoluution saavuttamiseksi 60 Hz:llä
■
Huomautuksia
● Isäntäkannettavan ilman MST-tukea voi liitää ainoastaan yhteen lisämonitoriin
● MST-protokolla ei tällä hetkellä ole tuettu macOS®- tai Chrome OS™-käyttöjärjestelmissä.
Näyttölähtö on liitettynä rajoitettu peilaustilaan.
● Vaaditaan 4K:n näyttö 3840 x 2160 -resoluution saavuttamiseksi.
● Liitettynä USB™ 2.0 -isäntäporttiin tai käytettäessä USB™ 2.0 -isäntäkaapelia, suorituskyky voi olla rajoitettu
● Minitelakan voi liittää USB-C®-porttiin, joka ei tue virransyöttöä, mutta se ei syötä virtaa liitettyyn
laitteeseen
● Jos käytät suuritehoisia USB™-laitteita, kiinnitä USB-C®-verkkolaite virransyöttöporttiin varmistaaksesi
maksimaalisen suorituskyvyn. Välttääksesi häiriön, älä irrota verkkolaitetta tiedostoja kopioitaessa.
● On suositeltavaa, ettei useampaa kuin yhtä (1) väyläkäyttöistä/kannettavaa kiintolevyasemaa liitetä
sovittimeen kerrallaan
■
Funksjoner
● Avansert USB-C® E-Mark-brikke kommer med kompatibilitet for USB4®, Thunderbolt™ 3 og
Thunderbolt™ 4
● Tre SuperSpeed USB™ 10 Gbps-nedstrømsporter (1 USB-C® og 2 Type-A) for å koble til eksterne enheter
● Lad og gi strøm til tilkoblet bærbar PC og periferiutstyr med 100 W Power Delivery
● SD™- og microSD™ 4.0-minnekortleser/-skriver for medielagring og overføring
● Legg enkelt til en kablet nettverkstilkobling med Gigabit Ethernet-porten
● Plug-and-play – ikke nødvendig å installere driver
● Støtter dobbel 4K 60 Hz eller trippel 4K 30 Hz (2 HDMI™ og 1 DisplayPort™) på kompatible bærbare
datamaskiner med USB-C® og støtte for DisplayPort™ 1.4 Alt-modus med MST*
■
Systemkrav
● Tilgjengelig USB-C®-port som støtter DisplayPort™ Alt-modus og USB™ Power Delivery 2.0 eller 3.0.
Se produsenten til datamaskinen for mer informasjon om enheten
● Vertsenheten må støtte multistrømtransport (MST) for å konfigureres med flere skjermer
● Vertsenheten må støtte DisplayPort™ 1.4 for å oppnå 4K-oppløsning ved 60 Hz
■
Merknader
● En bærbar datamaskin uten støtte for MST kan bare kobles til én ekstra skjerm
● MST-protokollen støttes for øyeblikket ikke på macOS® eller Chrome OS™.
Skjermutgangen er begrenset til speilingsmodus når den er tilkoblet.
● En 4K-kompatibel skjerm kreves for å oppnå 3840 x 2160 oppløsning
● Hvis det kobles til en USB™ 2.0-vertsport, eller det brukes en USB™ 2.0-vertskabel, kan ytelsen bli
begrenset
● Mini-dokkingen kan kobles til en USB-C®-port som ikke støtter Power Delivery, men den vil da ikke sende
strøm gjennom den tilkoblede enheten
● Hvis du bruker USB™-enheter som trenger mye strøm, må du koble en USB-C®-strømadapter til
strømforsyningsporten for å sikre maksimal ytelse. For å unngå avbrudd må du ikke fjerne strømadapteren
mens du kopierer filer.
● Vi anbefaler at ikke mer enn én (1) bussdrevet/bærbar ekstern harddisk kobles til adapteren om gangen
■
Funktioner
● Avanceret USB-C® E-mærket chip, der gør enheden kompatibel med USB4®, Thunderbolt™ 3 og
Thunderbolt™ 4
● Tre SuperSpeed USB™ 10 Gbps downstream-porte (1 USB-C® og 2 Type-A) til tilslutning af eksterne
enheder
● Oplad og strømforsyn en tilsluttet bærbar computer og eksternt udstyr med 100 W
● Kortlæser- og skriver til SD™ og microSD™ 4.0-hukommelseskort til, at gemme og overføre medie
● Tilføj nemt en kabelforbundet netværksforbindelse med Gigabit Ethernet-porten
● Plug-and-Play. Der skal ikke installeres nogen drivere.
● Understøtter dobbelt 4K 60Hz eller tredobbelt 4K 30Hz (2 HDMI™ og 1 DisplayPort™) på kompatible
USB-C® bærbare computere med DisplayPort™ 1.4 Alt-funktion med understøttelse af MST*
■
Systemkrav
● Tilgængelig USB-C®-port, der understøtter DisplayPort™ Alt-funktionen og USB™ strømforsyning (PD)
2.0 eller 3.0.
Du kan finde yderligere oplysninger i brugsvejledningen til din computer
● Værtsenheden skal understøtte MST (Multi-Stream Transport) for, at bruge flere skærme
● Værtsenheden skal understøtte DisplayPort™ 1.4 for, at opnå en opløsning på 4K med 60 Hz
■
Bemærkninger
● En værtscomputer, der ikke understøtter MST, kan kun oprette forbindelse til én ekstra skærm
● Det er i øjeblikket ikke muligt, at bruge MST-protokollen i macOS® eller Chrome OS™.
Skærmudgangen er begrænset til spejl-funktionen, når den er tilsluttet.
● Du skal bruge en 4K-kompatibel skærm for, at få en opløsning på 3840 x 2160
● Hvis produktet tilsluttes en USB™ 2.0-port, eller hvis du bruger et USB™ 2.0-kabel, kan det begrænse
produktets ydeevne
● Minidocken kan sluttes til en USB-C®-port, der ikke understøtter strømforsyning, men i så fald
strømforsyner den ikke den tilsluttede enhed
● Hvis du bruger en USB™-enhed med høj effekt, skal du tilslutte USB-C®-strømadapteren til
strømforsyningsporten for, at sikre den bedste ydeevne.
For at undgå forstyrrelser, må strømadapteren ikke afbrydes under kopiering af filerne.
● Vi anbefaler, at der ikke sluttes mere end én (1) busdrev/bærbar ekstern harddisk til adapteren ad gangen
■
Jellemzők
● A fejlett USB-C® E-Mark chip integrálja az USB4®, Thunderbolt™ 3 és Thunderbolt™ 4 kompatibilitást
● Három SuperSpeed USB™ 10 Gbps downstream aljzat (1 USB-C® és 2 Type-A) perifériák csatlakoztatásához
● Töltés és tápellátás a csatlakoztatott laptophoz és perifériákhoz a 100 W-os Power Delivery funkcióval
● SD™ és microSD™ 4.0 memóriakártya-olvasó/-író a média tárolásához és átviteléhez
● Könnyen hozzáadhat vezetékes hálózati kapcsolatot a Gigabit Ethernet-aljzat segítségével
● Plug-and-Play, ezért nincs szükség illesztőprogram telepítésére
● Dupla 4K 60 Hz vagy tripla 4K 30 Hz (2 HDMI™ és 1 DisplayPort™) támogatása kompatibilis USB-C®
laptopokon DisplayPort™ 1.4 alt móddal és MST támogatással*
■
Rendszerkövetelmények
● Szabad USB-C®-aljzat, amely támogatja a DisplayPort™ alternatív üzemmódot és az USB™ Power Delivery
2.0 vagy 3.0 szabványt.
A készülékre vonatkozó további információkért forduljon a számítógép gyártójához
● A többmonitoros konfigurációhoz a gazdaeszköznek támogatnia kell a Multi-Stream Transport (MST)
szolgáltatást
● A 60 Hz-es 4K felbontás eléréséhez a gazdaeszköznek támogatnia kell a DisplayPort™ 1.4 szabványt
■
Megjegyzések
● Az MST-támogatás nélküli gazda laptophoz csak egy további monitorhoz csatlakozhat
● Az MST protokollt jelenleg nem támogatja a macOS® vagy a Chrome OS™.
A kijelző kimenete tükrözés üzemmódra korlátozódik, p2-ha csatlakoztatva van.
● A 3840 x 2160 felbontás eléréséhez 4K-képes megjelenítő szükséges
● USB™ 2.0 host aljzathoz csatlakoztatás vagy USB™ 2.0 host kábel használata esetén a teljesítmény
korlátozott lehet
● A Mini dokkoló csatlakoztatható olyan USB-C® aljzathoz, amely nem támogatja a Power Delivery
szolgáltatást, de a csatlakoztatott eszközre nem fog áramot továbbítani
● Ha nagy teljesítményű USB™-eszközt használ, a maximális teljesítmény biztosítása érdekében csatlakoztassa
az USB-C® tápfeszültség-adaptert a tápfeszültség-aljzathoz. A fájlok zavartalan másolása érdekében ne
húzza ki a tápfeszültség-adaptert a fájlok másolása közben.
● Azt javasoljuk, hogy egyszerre legfeljebb egy (1) buszról táplált/hordozható külső merevlemezes meghajtót
csatlakoztasson az adapterhez
■
Технические особенности
● Встроенный USB-C® E-Mark чипсет для совместимости с USB4®, Thunderbolt™ 3 и Thunderbolt™ 4
● 3 USB™ (1 USB-C® и 2 Type-A) с поддержкой скорости передачи данных до
10 Гбит/с для подключения периферийных устройств
● Power Delivery с поддержкой зарядки мощностью до 100 Вт для зарядки ноутбука и периферийных
устройств
● SD™ / microSD™ 4.0 кардридер для хранения и передачи данных
● Простое подключение к проводному интернету через Ethernet порт
● Plug-and-play, установка драйвера не требуется
● Поддержка двух внешних мониторов с разрешением 4K@60 Гц или трёх с разрешением 4K@30 Гц
(2 HDMI™ и 1 DisplayPort™) на совместимых USB-C® ноутбуках, поддерживающих DisplayPort™ 1.4
Alt Mode и MST
■
Системные требования
● Доступный USB-C® порт с поддержкой DisplayPort™ Alt Mode и USB™ Power Delivery 2.0 или 3.0.
Пожалуйста, обратитесь к производителю вашего компьютера за дополнительной информацией о
вашем устройстве
● Для подключения нескольких внешних мониторов на источнике видео сигнала требуется
поддержка Multi-Stream Transport (MST)
● Для получения разрешения 4K@60 Гц на источнике видео сигнала требуется
поддержка DisplayPort™ v1.4
■
Примечания
● К ноутбуку без поддержки MST можно подключить только один вшений монитор
● В настоящее время протокол MST не полностью поддерживается на macOS® и Chrome OS™.
При подключении нескольких внешних мониторов изображение будет ограничено
повторяющимся режимом
● Для получения разрешения 3840 x 2160 требуется монитор с поддержкой 4K
● При подключении к USB™ 2.0 порту или при использовании USB™ 2.0 кабеля производительность
может быть ограничена
● Док-станция может быть подключена к USB-C® порту, не поддерживающим
Power Delivery, но в таком случае он не будет передавать питание на подключенное устройство
● При подключении USB™ устройств с высоким энергопотреблением, для
обеспечения максимальной производительности рекомендуется использование доп. USB-C® блока
питания. Чтобы обеспечить полное копирование файлов, не извлекайте USB-C® блок питания до
завершения копирования
● Не рекомендуется одновременно подключать более одного внешнего жесткого диска
■
產品特色
● 內建 USB-C® E-Mark 晶片, 相容於 USB4® ,Thunderbolt™ 3及Thunderbolt™ 4
● 提供三個支援10Gbps超高速資料傳輸的USB™埠
（1個 USB-C®，2個USB™ Type-A）
● 內建SD™/ microSD™ 讀卡機，支援SD™ 4.0 UHS-II 312MB/s
● 具備一個RJ-45有線網路接口
● 支援最高USB-C® PD 100W Pass-Through充電
● 隨插即用，不需安裝驅動程式
● 搭配支援DisplayPort™ 1.4 alt mode與MST的USB-Ｃ筆電使用時，可支援外接兩台4K 60Hz或三台4K
30Hz螢幕顯示（2 HDMI™ 與 1 DisplayPort™）
■
系統需求
● 必須具備支援 DisplayPort™ Alt Mode與Power Delivery充電功能的USB-C® 埠
● 如您需要瞭解您電腦的規格資訊，建議您可與電腦製造商諮詢
● 主機須支援DisplayPort™ 1.4 才能輸出 4K 60Hz 解析度
■
附註
● 如果連接的筆電不支援MST功能，將僅能外接一台螢幕
● macOS® 或Chrome OS™目前不支援MST功能，外接的螢幕將只能鏡像顯示
● 要獲得 3840 x 2160 解析度，需要具有 4K 功能的顯示螢幕
● 連接至USB™ 2.0 的接口或是線材時，功能可能會受到限制
● 本產品可以使用於不支援USB-C PD充電的筆電，但將無法對筆電進行充電
● 當外接高耗電裝置時，建議您將足夠的 USB-C® PD電源連接於本產品的電源輸入端,以避免外接裝置因
電源不足，造成運行穩定性不佳
● 進行資料傳輸時，請勿拔除電源供應器，以避免資料傳輸失敗或遺失
● 我們建議每次不要連接超過一個以上的行動硬碟於本產品
■
产品特点
● 内建 USB-C® E-Mark 芯片, 相容于 USB4® ,Thunderbolt™ 3及Thunderbolt™ 4
● 提供三个支持10Gbps超高速数据传输的USB™埠
（1个 USB-C®，2个USB™ Type-A）
● 内建SD™/ microSD™ 读卡机，支持SD™ 4.0 UHS-II 312MB/s
● 具备一个RJ-45有线网路接口
● 支持最高USB-C® PD 100W Pass-Through充电
● 随插即用，不需安装驱动程序
● 搭配支持DisplayPort™ 1.4 alt mode与MST的USB-Ｃ笔记本使用时，可支援外接两台4K 60Hz或三
台4K 30Hz屏幕显示（2 HDMI™ 与 1 DisplayPort™）
■
系统要求
● 必须具备支持 DisplayPort™ Alt Mode与Power Delivery充电功能的USB-C® 埠
● 如您需要了解您电脑的规格信息，建议您可与电脑制造商谘询
● 主机须支持DisplayPort™ 1.4 才能输出 4K 60Hz 分辨率
■
附注
● 如果连接的笔记本不支持MST功能，将仅能外接一台显示屏
● macOS® 或Chrome OS™目前不支持MST功能，外接的显示屏将只能镜像显示
● 要获得 3840 x 2160 分辨率，需要具有 4K 功能的显示屏
● 连接至USB™ 2.0 的接口或是线材时，功能可能会受到限制
● 本产品可以使用于不支持USB-C PD充电的笔记本，但将无法对笔记本进行充电
● 当外接高耗电装置时，建议您将足够的 USB-C® PD电源连接于本产品的电源输入端,以避免外接装置
因电源不足，造成运行稳定性不佳
● 进行数据传输时，请勿拔除电源供应器，以避免数据传输失败或遗失
● 我们建议每次不要连接超过一个以上的移动硬盘于本产品
LIMITED WARRANTY
j5create offers a limited 2-year warranty. User’s wear & tear damage is not included. The user shall call or
email j5create customer service with the defect information of the product and obtain a return authorization
number. Users are responsible for one-way return freight cost and we will take care of one-way freight back.
In order to obtain a return authorization number, users should have the following information handy when
calling or emailing the service team:
(i) a copy of the original purchase invoice to verify your warranty
(ii) a product serial number
(iii) a description of the problem
(iv) customer’s name, address, and telephone number
j5create does not warrant that the operation of the product will be uninterrupted or error-free. j5create is not
responsible for damage arising from failure to follow instructions relating to the product’s use. This warranty
does not apply to: (a) consumable parts, unless damage has occurred due to a defect in materials or
workmanship; (b) cosmetic damage, including but not limited to scratches, dents, and broken plastic on ports;
(c) damage caused by use with non-j5create products; (d) damage caused by natural disasters; (e) damage
caused by human misuse (lost, accident, abuse, misuse or other external causes); (f) damage caused by
operating the product outside the permitted or intended uses described by j5create; (g) damage caused by
service (including upgrades and expansions) performed by anyone who is not a representative of j5create or
a j5create Authorized Service Provider; (h) a product or part that has been modified to alter functionality or
capability without the written permission of j5create; or (i) if any j5create serial number on the product has
been removed or defaced. If such a situation occurs, j5create will calculate the cost of materials and repair for
your reference. This warranty is given by j5create in lieu of any other warranties expressed or implied.
LIMITATION OF WARRANTY
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY HAVE OTHER RIGHTS THAT VARY FROM
STATE TO STATE (OR BY COUNTRY OR PROVINCE). OTHER THAN AS PERMITTED BY LAW, J5CREATE DOES NOT
EXCLUDE, LIMIT OR SUSPEND OTHER RIGHTS YOU MAY HAVE, INCLUDING THOSE THAT MAY ARISE FROM
THE NONCONFORMITY OF A SALES CONTRACT. FOR A FULL UNDERSTANDING OF YOUR RIGHTS YOU
SHOULD CONSULT THE LAWS OF YOUR COUNTRY, PROVINCE OR STATE. TO THE EXTENT NOT PROHIBITED
BY LAW IN YOUR STATE, PROVINCE, JURISDICTION OR COUNTRY, THIS WARRANTY AND THE REMEDIES SET
FORTH ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, REMEDIES AND CONDITIONS, WHETHER
ORAL, WRITTEN, STATUTORY, EXPRESS OR IMPLIED.
J5CREATE'S RESPONSIBILITY FOR MALFUNCTIONS AND DEFECTS IN HARDWARE AND/OR SOFTWARE IS
LIMITED TO REPAIR OR REPLACEMENT AS SET FORTH IN THIS WARRANTY. J5CREATE’S LIABILITY DOES NOT
EXTEND BEYOND THE REMEDIES PROVIDED FOR IN THIS LIMITED WARRANTY, AND J5CREATE DOES NOT
ACCEPT LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, FOR THIRD-PARTY CLAIMS AGAINST
YOU FOR DAMAGES, FOR PRODUCTS NOT BEING AVAILABLE FOR USE, OR FOR LOST OR DAMAGED DATA OR
SOFTWARE. J5CREATE DOES NOT WARRANT THAT THE OPERATION OF ANY J5CREATE PRODUCT WILL BE
UNINTERRUPTED OR ERROR FREE.
J5CREATE’S LIABILITY IN ANY SITUATION WILL BE NO MORE THAN THE AMOUNT YOU PAID FOR THE
SPECIFIC PRODUCT THAT IS THE SUBJECT OF A CLAIM. THIS IS THE MAXIMUM AMOUNT FOR WHICH WE
ARE RESPONSIBLE.
EXCEPT FOR THE EXPRESS WARRANTIES CONTAINED IN THIS WARRANTY AND TO THE EXTENT NOT
PROHIBITED BY LAW, J5CREATE DISCLAIMS ALL OTHER WARRANTIES AND CONDITIONS, EXPRESS OR
IMPLIED, STATUTORY OR OTHERWISE, INCLUDING WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILI-
TY, MERCHANTABLE QUALITY AND FITNESS FOR A PARTICULAR PURPOSE AND WARRANTIES AND
CONDITIONS AGAINST HIDDEN OR LATENT DEFECTS. SOME STATES, PROVINCES, JURISDICTIONS OR
COUNTRIES DO NOT ALLOW DISCLAIMERS OF IMPLIED WARRANTIES AND CONDITIONS, SO THIS
DISCLAIMER MAY NOT APPLY TO YOU.
TO THE EXTENT SUCH WARRANTIES AND CONDITIONS CANNOT BE DISCLAIMED UNDER THE LAWS OF THE
UNITED STATES, CANADA (AND ITS PROVINCES) OR OTHERWISE, J5CREATE LIMITS THE DURATION AND
REMEDIES OF SUCH WARRANTIES AND CONDITIONS TO THE DURATION OF THIS EXPRESS LIMITED
WARRANTY AND, AT J5CREATE'S OPTION, REPAIR OR REPLACEMENT SERVICES. SOME STATES, PROVINCES,
JURISDICTIONS OR COUNTRIES MAY NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY OR
CONDITION MAY LAST, SO THE LIMITATION DESCRIBED ABOVE MAY NOT APPLY TO YOU.
NO WARRANTIES OR CONDITIONS, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THE LIMITED
WARRANTY PERIOD HAS EXPIRED. SOME STATES, PROVINCES, JURISDICTIONS OR COUNTRIES DO NOT
ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY OR CONDITION LASTS, SO THIS LIMITATION
MAY NOT APPLY TO YOU.
WARRANTY SUPPORT ONLY APPLIES WHEN THE COVERED PRODUCT IS LOCATED WITHIN THE COUNTRY IN
WHICH J5CREATE ORIGINALLY SOLD THE SYSTEM, AS REFLECTED IN J5CREATE'S RECORDS. IF YOU NEED
SUPPORT FOR THE PRODUCT OUTSIDE OF THE COUNTRY OF ORIGIN (FOR EXAMPLE, WHILE TRAVELING, OR
IF THE SYSTEM HAS BEEN RELOCATED TO A NEW COUNTRY), THEN J5CREATE MAY OFFER YOU OTHER
SUPPORT OPTIONS FOR AN ADDITIONAL CHARGE.
For more information please visit our website at http://www.j5create.com
Copyright© 2022 j5create. All rights reserved. All trade names are registered trademarks of their respective
owners. Features and specifications are subject to change without notice. Product may not be exactly as
shown in the diagrams.
4K60 Elite USB-C® 10 Гбит/с мини док-станция с
поддержкой трёх дисплеев (JCD397)
Dansk
Magyar
■ 特徴
● 最先端規格を搭載してUSB4®,Thunderbolt™3,Thunderbolt™4に互換性があります。
● USB™3.2Gen210Gbps超高速データ規格を搭載してます。
● USB-C®PowerDelivery最大100Wに対応して別売PD充電器を利用してパソコンに急速充電できます。
● カードリーダーはSD™4.0UHS-IIを搭載して最大312Mbpsデータ読み書き速度をサポートします。
● ギガビットイーサネット有線LANを拡張できます。
● プラグ＆プレイ、ドライバーインストール不要で接続すれば使用できます。
● HDMI™、DisplayPort™は最大4K60Hz表示解像度に対応しています。
● DisplayPort™AltModeに対応しているノートPCにMST機能でマルチディスプレイを増設可能です。最大ト
リプル4K30Hzマルチディスプレイを増設できます。
※ノートPCのGPU性能により拡張できるモニター台数と最大解像度が違います。
■ システム要 件
● Type-Cを備えるホスト側がDisplayPort™AltModeとPowerDeliveryに対応している必要があります。
● 上記規格に対応しているかについてはパソコンメーカーのサポートに確認してください。
● 4K60Hzの解像度にはディスプレイは4K60Hzに対応し、パソコンホスト側はDisplayPort™1.4に対応してい
る必要があります。
■ 注意事項
● MST機能はMacBook®を利用する場合にシステム制限により拡張モードで増設したディスプレイが同じ画面
になります。M1チップは1台しか拡張できません。ChromeOS™には対応していません。
● 本機はUSB™3.2規格ですので、ホスト側およびケーブルはUSB™2.0品を利用する場合に、パフォーマンス
が落ちるのでご注意ください。
● PowerDeliveryに非対応のノートPCにも利用可能ですが、PD充電ポートを経由してノートPCに充電するこ
とができません。
● SSDなど高消費量のデバイスを使用する場合に安定した動作を提供するためにPD充電器を本機に接続し
て使用してください。またデータ転送中に電源を切らないようにしてください。
● 複数の高消費量デバイスは同時に使用しないでください。
Norsk
Русский
Suomi
日本語
繁中 简中
Product specificaties
| Merk: | J5create |
| Categorie: | Cradle/docking station |
| Model: | JCD397 |
Heb je hulp nodig?
Als je hulp nodig hebt met J5create JCD397 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Cradle/docking station J5create
8 September 2025
8 September 2025
Handleiding Cradle/docking station
- LC-Power
- Vakoss
- Scott
- Insignia
- ACME
- Pioneer
- Alogic
- Billow
- Trevi
- DockCase
- Teac
- Logitech
- Twelve South
- Tivoli Audio
- Philips
Nieuwste handleidingen voor Cradle/docking station
8 September 2025
8 September 2025
1 September 2025
1 September 2025
1 September 2025
1 September 2025
1 September 2025
1 September 2025
1 September 2025
1 September 2025
