N-Switch UFO 4合1座充

产品说明书(PG-SL003)

1.本产品是一款适用于N-Switch/N-Switch lite主机、Pro手柄及Joy-Con手柄的充电座；

2. 本产品拥有4个插槽，可以任意搭配充电，N-Switch/N-Switch lite主机支持DC15V快充；

3.本产品配有TYPE-C母座接口，支持N-Switch原装适配器为产品提供电源输入；

4.产品精巧简洁，操作简单，实时显示设备充电状态；

产品特点

1.将N-Switch/N-Switch lite原装适配器接入产品，为产品提供电源输入；

2.产品通电后，充电指示灯绿色常亮；

3.将手柄或者N-Switch/N-Switch lite主机插入对应插槽进行充电，充电时对应指示灯

红色常亮，充满电绿色常亮；

※N-Switch/N-Switch lite主机支持DC15V快充，通过本产品给主机充电时，必须使用

N-Switch原装适配器供电！

产品使用说明:

1.输入电压/电流：

2.JoyCon手柄充电时间：约3小时；

3.Pro手柄充电时间：约4.5小时；

4.N-Switch主机充电时间：约2小时；

TYPE-C母座*1

充电指示灯(红/绿色)

主机充电插槽*1

JoyCon充电插槽*2

Pro手柄充电插槽*1

产品特性参数：

产品外观接口图示

1.请不要把本产品放在潮湿或高温地方存储；

2.不要敲击、摔打、棒打、刺穿、或试图去分解本产品，以免对产品造成不必要的损害；

3.非专业人员请勿拆卸本产品,否则不在售后保修服务内;

注意事项

产品清单

充电底座 x1说明书 x1

专利号：ZL201930429795.1

N-Switch UFO 4 in 1 Charger Dock

User Manual(PG-SL003)

1.This is a charger for N-Switch/N-Switch lite console, Pro & Joy-con controller;

2.With four charging docks ,can be charging any items optionally, support DC15V

fast charge for N-Switch/N-Switch lite console.

3.With TYPE-C female socket, support power input from original N-Switch adapter.

4.Delicate &compact, easy to operate, clearly indicate current charging status.

Product Features:

1.Connect the charger to the original N-Switch / N-Switch lite adapter to get power

input;

2.After power-on, the charging indicator will be always on in green.

3.When charging , the corresponding indicator will be red, after fully charged, the

light will be green.

※ The product support DC15V fast charge for N-Switch/N-Switch lite console, while

charging must make sure power input form the N-switch origional adapter !

Usage Instruction:

1.Input Voltage/Current:

2.Charging time for Joy-con: Approximately 3 hours

3.Charging time for Pro: Approximately 4.5 hours

4.Charging time for N-switch / N-Switch lite console:Approximately 2 hours

Product Illustration:

Functional Demonstration:

Patent No.ZL201930429795.1：

TYPE-C female socket *1

Charging indicator

(Red/ Green)

N-Switch/N-Switch lite

console charging slot*1

Joycon charging slot*2

Pro controller charging slot*1

Charging station x1User Manual x1

1. Please do not store this product in wet or high-temperature areas.

2. Don't knap, beat, drub, pierce, or try to decompose this product, to avoid

unnecessary damage to the product.

3. Non professional personnel should not disassemble the product, otherwise it will

not be covered in the after-sales warranty service.

Notes：

Accessories List:

5V 1.5A/15V 2.6A

5V 1.5A/15V 2.6A
