WARNING:This product contains small items that could be a choking
hazard if swallowed. Keep out of the reach of children.
CAUTION: Make sure that all parts are undamaged. If any parts are missing or
damaged, contact customer service. Never use damaged parts!
FEATURES
• Complete hardware kit for mounting a new TV to an existing wall mount
• Supports TVs up to 90 in. (diagonal measurement) or up to 125 lbs. when
installed in accordance with the TV and wall mount instructions
Note: Does NOT include hardware for mounting a TV mount to the wall or new
mounting brackets for the back of the TV.
QUICK SETUP GUIDE
Wall-Mount
Replacement
Hardware Kit
NS-HTBOLT1
V1 ENGLISH 21-1115
22 mm
(qty. 4)
2.5 mm
(qty. 8)
M6 × 12 mmM6 × 20 mmM6 × 35 mm
M8 × 35 mmM8 × 16 mm
M8 × 20 mm
M8 × 25 mm
M8 × 30 mm
M8 × 40 mm
M8 × 45 mm
M8 × 50 mm
M4 × 12 mmM4 × 35 mm
M4 / M5
(qty. 8)
M6 / M8
(qty. 8)
TV screws (qty. 4 each)
M4
M5
M6
M8
SpacersWashers
M5 × 12 mmM5 × 35 mm
6907-302054
Use spacers if:
• There are gaps between the
mounting bracket and the TV
back
• The mounting bracket blocks
one or more jacks
• The TV mounting holes are inset
ONE-YEAR LIMITED
WARRANTY
Visit www.insigniaproducts.com
for details.
CONTACT INSIGNIA:
For customer service, call 877-467-4289
(U.S. and Canada)
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its aliated
companies
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richeld, MN 55423 U.S.A.
©2022 Best Buy. All rights reserved.
