3-7/8"
98mm
5-1/8"
129mm
3-3/16"
80mm
4-3/4"
120mm
2-1/4"
57mm
9/16"
29mm
1-3/4"
44mm
REFERENCE
5032i
5032cf
5032gr
Designed and engineered in the USA.Conception et design aux É.U.A.
Avalid serial number is required for warranty coverage.Un numéro de série valable est exigé pour la couverture de la garantie.
Features,specifications and appearance are subject to change without notice.
Les dispositifs,les caractéristiques et l’aspect sont sujets au changement sans communication préalable.
Harman International, Consumer Division,8500 Balboa Boulevard, Northridge, CA 91329 USA
www.infinitysystems.com
©2009 Harman International Industries,Incorporated.All rights reserved.Tous droits réservés.s Part No.REF5032OM1/09
Infinity is a trademark of Harman International Industries,Incorporated,registered in the United States and/or other countries.
Infinity est une marque commerciale de Harman International Industries,Incorporated,déposée aux États-Unis et/ou dans d’autres pays.
Declaration of Conformity
We,Harman Consumer Group,Inc.
2,routede Tours
72500 Château du Loir
France
declare in own responsibility that the products described in this owner’s
manual are in compliance with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Klaus Lebherz
Harman Consumer Group,Inc.
Château du Loir,France 1/09
5032i5032cf
BL (T-m)3.253.25
DCR (ohms)2.302.30
Mms (g)10.2210.22
Sd (sq cm)103.9103.9
Cms (μm/N)521521
Vas (l)7.897.89
Fs (Hz)69.069.0
Qes0.960.96
Qms6.946.94
Qt0.850.85
SPECIFICATIONS
5032i5032cf5032gr
Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way2-Wayfor 5-1/4" (130mm)
NOGRILLE
Impedance:2 Ohms2 Ohms
Power Handling,RMS:45W45W
Power Handling,Peak:135W135W
Frequency Response:67Hz – 21kHz67Hz – 21kHz
Sensitivity (2.83V,1m):92dB92dB
Grilles are included with the “i”version;they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at
www.infinitysystems.com.
SPECIFICATIONS
5032i5032cf5032gr
Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way2-Wayfor 5-1/4" (130mm)
NOGRILLE
Impedance:2 Ohms2 Ohms
Power Handling,RMS:45W45W
Power Handling,Peak:135W135W
Frequency Response:67Hz – 21kHz67Hz – 21kHz
Sensitivity (2.83V,1m):92dB92dB
Grilles are included with the “i”version;they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i5032cf5032gr
Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way2-Wayfor 5-1/4" (130mm)
NOGRILLE
Impedance:2 Ohms2 Ohms
Power Handling,RMS:45W45W
Power Handling,Peak:135W135W
Frequency Response:67Hz – 21kHz67Hz – 21kHz
Sensitivity (2.83V,1m):92dB92dB
Grilles are included with the “i”version;they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i5032cf5032gr
Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way2-Wayfor 5-1/4" (130mm)
NOGRILLE
Impedance:2 Ohms2 Ohms
Power Handling,RMS:45W45W
Power Handling,Peak:135W135W
Frequency Response:67Hz – 21kHz67Hz – 21kHz
Sensitivity (2.83V,1m):92dB92dB
Grilles are included with the “i”version;they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i5032cf5032gr
Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way2-Wayfor 5-1/4" (130mm)
NOGRILLE
Impedance:2 Ohms2 Ohms
Power Handling,RMS:45W45W
Power Handling,Peak:135W135W
Frequency Response:67Hz – 21kHz67Hz – 21kHz
Sensitivity (2.83V,1m):92dB92dB
Grilles are included with the “i”version;they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i5032cf5032gr
Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way2-Wayfor 5-1/4" (130mm)
NOGRILLE
Impedance:2 Ohms2 Ohms
Power Handling,RMS:45W45W
Power Handling,Peak:135W135W
Frequency Response:67Hz – 21kHz67Hz – 21kHz
Sensitivity (2.83V,1m):92dB92dB
Grilles are included with the “i”version;they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Y
our local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i5032cf5032gr
Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way2-Wayfor 5-1/4" (130mm)
NOGRILLE
Impedance:2 Ohms2 Ohms
Power Handling,RMS:45W45W
Power Handling,Peak:135W135W
Frequency Response:67Hz – 21kHz67Hz – 21kHz
Sensitivity (2.83V,1m):92dB92dB
Grilles are included with the “i”version;they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit
us at www.infinitysystems.com.
SPECIFICATIONS
5032i5032cf5032gr
Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way2-Wayfor 5-1/4" (130mm)
NOGRILLE
Impedance:2 Ohms2 Ohms
Power Handling,RMS:45W45W
Power Handling,Peak:135W135W
Frequency Response:67Hz – 21kHz67Hz – 21kHz
Sensitivity (2.83V,1m):92dB92dB
Grilles are included with the “i”version;they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i5032cf5032gr
Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way2-Wayfor 5-1/4" (130mm)
NOGRILLE
Impedance:2 Ohms2 Ohms
Power Handling,RMS:45W45W
Power Handling,Peak:135W135W
Frequency Response:67Hz – 21kHz67Hz – 21kHz
Sensitivity (2.83V,1m):92dB92dB
Grilles are included with the “i”version;they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i5032cf5032gr
Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way2-Wayfor 5-1/4" (130mm)
NOGRILLE
Impedance:2 Ohms2 Ohms
Power Handling,RMS:45W45W
Power Handling,Peak:135W135W
Frequency Response:67Hz – 21kHz67Hz – 21kHz
Sensitivity (2.83V,1m):92dB92dB
Grilles are included with the “i”version;they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i5032cf5032gr
Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way2-Wayfor 5-1/4" (130mm)
NOGRILLE
Impedance:2 Ohms2 Ohms
Power Handling,RMS:45W45W
Power Handling,Peak:135W135W
Frequency Response:67Hz – 21kHz67Hz – 21kHz
Sensitivity (2.83V,1m):92dB92dB
Grilles are included with the “i”version;they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i5032cf5032gr
Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way2-Wayfor 5-1/4" (130mm)
NOGRILLE
Impedance:2 Ohms2 Ohms
Power Handling,RMS:45W45W
Power Handling,Peak:135W135W
Frequency Response:67Hz – 21kHz67Hz – 21kHz
Sensitivity (2.83V,1m):92dB92dB
Grilles are included with the “i”version;they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your
local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i5032cf5032gr
Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way2-Wayfor 5-1/4" (130mm)
NOGRILLE
Impedance:2 Ohms2 Ohms
Power Handling,RMS:45W45W
Power Handling,Peak:135W135W
Frequency Response:67Hz – 21kHz67Hz – 21kHz
Sensitivity (2.83V,1m):92dB92dB
Grilles are included with the “i”version;they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us
at www.infinitysystems.com.
SPECIFICATIONS
5032i5032cf5032gr
Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way2-Wayfor 5-1/4" (130mm)
NOGRILLE
Impedance:2 Ohms2 Ohms
Power Handling,RMS:45W45W
Power Handling,Peak:135W135W
Frequency Response:67Hz – 21kHz67Hz – 21kHz
Sensitivity (2.83V,1m):92dB92dB
Grilles are included with the “i”version;they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
Product specificaties
| Merk: | Infinity |
| Categorie: | Autospeaker |
| Model: | Reference 5032I |
Heb je hulp nodig?
Als je hulp nodig hebt met Infinity Reference 5032I stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Autospeaker Infinity
Infinity Reference 6032CF Handleiding Infinity Reference 6402CF Handleiding Infinity Kappa 462.9CFP Handleiding Infinity Kappa 42.7I Handleiding Infinity Reference 5012I Handleiding Infinity Reference 4032CF Handleiding Infinity Reference 552I Handleiding Infinity Reference 6822CF Handleiding
Alle Infinity Autospeaker handleidingen
Populair in Autospeaker
Infinity Reference 9632i Handleiding Infinity Kappa 57.1cs Handleiding Infinity Kappa 462.1CF Handleiding
Handleiding Autospeaker
Nieuwste handleidingen voor Autospeaker
Hertz SPL SV 200L Handleiding Hertz SPL Show SV 165 NEO Handleiding AudioControl Epic Pro EPICPRO6S Handleiding AudioControl Epic Pro EPICPRO8X Handleiding AudioControl Epic Pro EPICPRO6X Handleiding Rockville RXM68 Handleiding Rockville RM108PRO Handleiding Rockville RT5 Handleiding Rockville RV68.2C Handleiding Rockville RV65.2C Handleiding
