3-7/8"

98mm

5-1/8"

129mm

3-3/16"

80mm

4-3/4"

120mm

2-1/4"

57mm

9/16"

29mm

1-3/4"

44mm

REFERENCE

5032i

5032cf

5032gr

Designed and engineered in the USA.Conception et design aux É.U.A.

Avalid serial number is required for warranty coverage.Un numéro de série valable est exigé pour la couverture de la garantie.

Features,specifications and appearance are subject to change without notice.

Les dispositifs,les caractéristiques et l’aspect sont sujets au changement sans communication préalable.

Harman International, Consumer Division,8500 Balboa Boulevard, Northridge, CA 91329 USA

www.infinitysystems.com

Infinity is a trademark of Harman International Industries,Incorporated,registered in the United States and/or other countries.

Infinity est une marque commerciale de Harman International Industries,Incorporated,déposée aux États-Unis et/ou dans d’autres pays.

Declaration of Conformity

We,Harman Consumer Group,Inc.

2,routede Tours

72500 Château du Loir

France

declare in own responsibility that the products described in this owner’s

manual are in compliance with technical standards:

EN 61000-6-3:2001

EN 61000-6-1:2001

Klaus Lebherz

Harman Consumer Group,Inc.

Château du Loir,France 1/09

5032i5032cf

BL (T-m)3.253.25

DCR (ohms)2.302.30

Mms (g)10.2210.22

Sd (sq cm)103.9103.9

Cms (μm/N)521521

Vas (l)7.897.89

Fs (Hz)69.069.0

Qes0.960.96

Qms6.946.94

Qt0.850.85

SPECIFICATIONS

5032i5032cf5032gr

Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way2-Wayfor 5-1/4" (130mm)

NOGRILLE

Impedance:2 Ohms2 Ohms

Power Handling,RMS:45W45W

Power Handling,Peak:135W135W

Frequency Response:67Hz – 21kHz67Hz – 21kHz

Sensitivity (2.83V,1m):92dB92dB

Grilles are included with the “i”version;they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product,please visit us at

www.infinitysystems.com.

SPECIFICATIONS

5032i5032cf5032gr

Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way2-Wayfor 5-1/4" (130mm)

NOGRILLE

Impedance:2 Ohms2 Ohms

Power Handling,RMS:45W45W

Power Handling,Peak:135W135W

Frequency Response:67Hz – 21kHz67Hz – 21kHz

Sensitivity (2.83V,1m):92dB92dB

Grilles are included with the “i”version;they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product,please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i5032cf5032gr

Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way2-Wayfor 5-1/4" (130mm)

NOGRILLE

Impedance:2 Ohms2 Ohms

Power Handling,RMS:45W45W

Power Handling,Peak:135W135W

Frequency Response:67Hz – 21kHz67Hz – 21kHz

Sensitivity (2.83V,1m):92dB92dB

Grilles are included with the “i”version;they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product,please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i5032cf5032gr

Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way2-Wayfor 5-1/4" (130mm)

NOGRILLE

Impedance:2 Ohms2 Ohms

Power Handling,RMS:45W45W

Power Handling,Peak:135W135W

Frequency Response:67Hz – 21kHz67Hz – 21kHz

Sensitivity (2.83V,1m):92dB92dB

Grilles are included with the “i”version;they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product,please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i5032cf5032gr

Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way2-Wayfor 5-1/4" (130mm)

NOGRILLE

Impedance:2 Ohms2 Ohms

Power Handling,RMS:45W45W

Power Handling,Peak:135W135W

Frequency Response:67Hz – 21kHz67Hz – 21kHz

Sensitivity (2.83V,1m):92dB92dB

Grilles are included with the “i”version;they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product,please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i5032cf5032gr

Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way2-Wayfor 5-1/4" (130mm)

NOGRILLE

Impedance:2 Ohms2 Ohms

Power Handling,RMS:45W45W

Power Handling,Peak:135W135W

Frequency Response:67Hz – 21kHz67Hz – 21kHz

Sensitivity (2.83V,1m):92dB92dB

Grilles are included with the “i”version;they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Y

our local Infinity car audio retailer can help you determine the length

of your warranty.To register your product,please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i5032cf5032gr

Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way2-Wayfor 5-1/4" (130mm)

NOGRILLE

Impedance:2 Ohms2 Ohms

Power Handling,RMS:45W45W

Power Handling,Peak:135W135W

Frequency Response:67Hz – 21kHz67Hz – 21kHz

Sensitivity (2.83V,1m):92dB92dB

Grilles are included with the “i”version;they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product,please visit

us at www.infinitysystems.com.

SPECIFICATIONS

5032i5032cf5032gr

Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way2-Wayfor 5-1/4" (130mm)

NOGRILLE

Impedance:2 Ohms2 Ohms

Power Handling,RMS:45W45W

Power Handling,Peak:135W135W

Frequency Response:67Hz – 21kHz67Hz – 21kHz

Sensitivity (2.83V,1m):92dB92dB

Grilles are included with the “i”version;they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product,please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i5032cf5032gr

Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way2-Wayfor 5-1/4" (130mm)

NOGRILLE

Impedance:2 Ohms2 Ohms

Power Handling,RMS:45W45W

Power Handling,Peak:135W135W

Frequency Response:67Hz – 21kHz67Hz – 21kHz

Sensitivity (2.83V,1m):92dB92dB

Grilles are included with the “i”version;they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product,please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i5032cf5032gr

Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way2-Wayfor 5-1/4" (130mm)

NOGRILLE

Impedance:2 Ohms2 Ohms

Power Handling,RMS:45W45W

Power Handling,Peak:135W135W

Frequency Response:67Hz – 21kHz67Hz – 21kHz

Sensitivity (2.83V,1m):92dB92dB

Grilles are included with the “i”version;they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product,please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i5032cf5032gr

Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way2-Wayfor 5-1/4" (130mm)

NOGRILLE

Impedance:2 Ohms2 Ohms

Power Handling,RMS:45W45W

Power Handling,Peak:135W135W

Frequency Response:67Hz – 21kHz67Hz – 21kHz

Sensitivity (2.83V,1m):92dB92dB

Grilles are included with the “i”version;they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product,please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i5032cf5032gr

Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way2-Wayfor 5-1/4" (130mm)

NOGRILLE

Impedance:2 Ohms2 Ohms

Power Handling,RMS:45W45W

Power Handling,Peak:135W135W

Frequency Response:67Hz – 21kHz67Hz – 21kHz

Sensitivity (2.83V,1m):92dB92dB

Grilles are included with the “i”version;they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your

local Infinity car audio retailer can help you determine the length

of your warranty.To register your product,please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i5032cf5032gr

Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way2-Wayfor 5-1/4" (130mm)

NOGRILLE

Impedance:2 Ohms2 Ohms

Power Handling,RMS:45W45W

Power Handling,Peak:135W135W

Frequency Response:67Hz – 21kHz67Hz – 21kHz

Sensitivity (2.83V,1m):92dB92dB

Grilles are included with the “i”version;they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product,please visit us

at www.infinitysystems.com.

SPECIFICATIONS

5032i5032cf5032gr

Type:5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way2-Wayfor 5-1/4" (130mm)

NOGRILLE

Impedance:2 Ohms2 Ohms

Power Handling,RMS:45W45W

Power Handling,Peak:135W135W

Frequency Response:67Hz – 21kHz67Hz – 21kHz

Sensitivity (2.83V,1m):92dB92dB

Grilles are included with the “i”version;they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product,please visit us at www.infinitysystems.com.

Beoordeel deze handleiding

Product specificaties

Merk:	Infinity
Categorie:	Autospeaker
Model:	Reference 5032CF

Heb je hulp nodig?

Als je hulp nodig hebt met Infinity Reference 5032CF stel dan hieronder een vraag en andere gebruikers zullen je antwoorden

Handleiding Autospeaker Infinity

Infinity Reference 6002I Handleiding Infinity Reference 5752CF Handleiding Infinity Reference 452I Handleiding Infinity Reference 4012I Handleiding Infinity Reference 4652CF Handleiding Infinity Reference 6432CFP Handleiding Infinity Reference 6432CF Handleiding Infinity Reference 6422CFP Handleiding

Alle Infinity Autospeaker handleidingen

Populair in Autospeaker

Infinity Reference 9632i Handleiding Infinity Kappa 57.1cs Handleiding Infinity Kappa 462.1CF Handleiding

Handleiding Autospeaker

Nieuwste handleidingen voor Autospeaker

Pioneer TS-500M Handleiding Alpine SPR-13C Handleiding Audiotec Fischer HELIX COMPOSE Ci3 C130.2-S3 Handleiding Pioneer TS-300D4 Handleiding Sony XS-GTX120LW Handleiding Rockville RM88PRO Handleiding Audison Voce AVK 6A P II Handleiding Audison Voce AVK 6 S II Handleiding Audison Voce AV 3.0 II Handleiding Audison Voce AVX 6.5 Handleiding
