Overview And Uses

HDDA-1

HDTV

Wideband Analog

Distribution

Amplifier

Phone: 503-575-1951

Email: s[email protected]

INDAY

1818 NE 140th

Portland, Oregon 97230

For Customer Service:

The HDDA-1 is a very wideband analog Distribu-

tion Amplifier (DA) capable of buffering and split-

ting any nominal 1 to 2 Volt (peak to peak) signal

that terminates into 75 ohms. This includes any of

the following.

-H

DTV Analog RGB/YPbPr signals

.

-Sta

ndard Def. Analog RGB/YPbPr/Betacam

-Co

mponent DVD, Progressive or Interlac

ed.

-C

omposite Video (NTSC)

-SPDIF

Digital Audio (PCM/AC3

/DTS)

Figure 1 - Connectors

Figure 2 - Component Video Distribution

The HDDA-1 can be configured in a number of

ways. Here are the most common.

♦A

1-In to 4-Out HDTV Receiver or Progress

ive

Scan

DVD Splitter. Figure

2

♦

A 1

-In to 10 out Composite Distribution Amp to

feed a stack of Dubbing VCR’s. Figure

3

♦

Three

separate 1-In to 4-Out DA’s. Figure

4.

♦

Hom

e Theater. One input distributes the Com-

posite (NTSC) video to the Displays and anot

her

in

put distributes the Digital Audio to the Audio

equipment. Figure

5

Th

e unit is supplied with the proper 12VDC Power

Supply (center pin positive +).

Configurations

Figure 3 - Composite Video Distribution 1X10
