Pagina 1/3
SPECIFICATION:
MODEL NO. : IDX-2530CM
RATED VOLTAGE : 230Va.c. 60Hz
POWER CONSUMPTION : 25 Watts 00
BOX DIMENSION : 363x425x100mm
UNIT DIMENSION : 320x390x75mm
GROSS WEIGHT : 3.61kgs
UNIT WEIGHT : 3.23kgs
IMPORTANT SAFEGUARD:
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions carefully.
2. Do not use the Induction Cooker on any metal table.
3. Do not use the Induction Cooker next to devices, which react sensitively to
magnet (e.g. radios, TV, cassette recorders, etc.).
4. Keep curtains, furniture, ammable materials, etc. away from the Induction
Cooker and from the convenience outlet where the Induction Cooker is plugged.
5. Before using the Induction Cooker, check if the voltage indicated corresponds
with the convenience outlet (230Va.c.)
6. Do not use any appliance with a damaged cord or plug. If the cord is damaged it
should be replaced with the same type and size or bring the Induction Cooker to
the nearest Authorized Service Center.
7. Do not use the two-way socket with another appliance.
8. Do not place the unit near gas stove, an electric burner, in heated oven or near
any hot surface.
9. Do not touch the Induction Cooker and the power plug with wet hands.
10. Do not block the ventilation slots of the Induction Cooker. Keep a minimum
distance of 10cm to 20cm away from the wall or from other items.
11. The Induction Cooker’s surface is made of glass, if damaged, unplug
immediately.
12. Do not insert objects like wires or tools into the ventilation slots, this may cause
electric shocks.
13. Do not allow the cord to touch the hot surface of the unit.
14. The Induction Cooker does not heat up during cooking, but the heat from the
cookware can be transferred to in the Induction Cooker. Do not touch the hot
surface of the glass.
15. Scientific tests have proven that Induction Cookers are safe to use. However,
persons with a pacemaker should keep a minimum distance of 60cm from the
unit while using.
16. Do not place any metal kitchen utensils, pan lids, knives or other metal objects
on the cooker. These may heat up when the Induction Cooker is turned on.
17. Do not place any magnetic objects on the glass surface while the Induction
Cooker is in use.
18. To protect against electric shock, do not immerse the Induction Cooker in water.
19. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliances by person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
20. This induction cooker is intended for tabletop use only.
21. Do not use the Induction Cooker for other than intended use.
22. Not intended for outdoor use.
23. For household use only, not intended for any business purposes.
1
24. Save this instruction for future references.
25. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal
cutout, this appliance must not be supplied through an external switching device,
such as timer, or connected to a circuit that is regularly switched on and off by
the utility.
DESCRIPTION OF PARTS:
OPERATING PRINCIPLE:
Induction Cooker applies the heating principle of the magnetic eld inducing the whorl electric
current. It utilizes the magnetic eld produced by the current passing the loop when the
magnetic force line passes the bottom of the stainless-steel cookware. It produces numberless
whorl electric current that will heat up the stainless-steel cookware rapidly. This process is
extremely efcient and minimizes the use of electricity.
The Imarex Induction Cooker automatically detects if the cookware is induction-ready.
SUITABLE COOKWARES:
Magnetized stainless steel and cast iron
Acceptable pot diameter is 12cm-30cm
NOTE: FOR OPTIMAL PERFORMANCE AND EFFICIENCY, USE POTS THAT ARE WITHIN
THE SIZE OF THE CIRCULAR PRINT ON THE INDUCTION PLATE.
UNSUITABLE COOKWARES:
Non-magnetized stainless steel, aluminum, plastic, glass and Porcelain.
CAUTION:
Do not leave an empty cookware with the Induction Cooker ON
When STIR-FRYING with little oil in the pot, don’t overheat the oil, otherwise it will
kindle easily
When FRYING, the volume of the oil in the pot should be not less than 0.9 liter since
little oil might burn easily
2
CONTROL PANEL:
HOW TO USE
1. Connect to Power - Plug the unit into a convenient power outlet. A beep
will sound, and the display will ash "- - - -", indicating the unit is powered
on.
2. Enter Standby Mode - Press the "ON/OFF" button. A beep will sound, and
the display will show "ON", placing the unit in standby mode.
3. Place Cookware - Center induction-ready cookware on the induction plate
for accurate heating.
4. Adjust Power Setting - Press the "Function" button once. The display will
show 00, the default power level ( 00W). 16 16 Use the “+” and “–” buttons
to adjust the power between 200W and 2500W.
5. Adjust Temperature Setting - Press the "Function" button twice. The
display will show 240°C, the default temperature. Use the “+” and “–”
buttons to adjust the temperature from 60°C to 240°C.
Note: It is recommended to use power mode for boiling and temperature
mode for frying.
6. Set Timer (Optional) - After selecting your desired function, press the
"Timer" button. The display will show "0:00", and the timer indicator will
light up. Set a time between 1 minute (0:01) and 4 hours (4:00).
7. Activate Child Lock - Press the "Lock" button to lock all settings. The lock
indicator will light up. While locked, the induction cooker will not respond to
any key presses.
8. To unlock, press and hold the "Lock" button for 3 to 5 seconds.
9. Turn O After Use - Press the "ON/OFF" button to return the unit to sleep
mode. Make sure the unit fan stops completely before unplugging the unit.
10. Unplug the Unit - Always unplug the cooker from the power outlet after use
for safety.
CLEANING AND MAINTENANCE
1. Allow the unit to cool completely before cleaning.
2. Ensure the cooker is turned o and unplugged.
3. Use a suitable mild detergent to remove any dirt or residue.
4. Wipe the surface with a clean, damp cloth after cleaning.
5. Do not immerse the unit in water or any other liquid.
6. Always clean the cooking plate and pan before each use to prevent buildup
and discoloration from burnt residue.
7. Clean the air vent and intake using a vacuum or cotton swab. If oily dirt is
present, use a soft toothbrush with a small amount of detergent.
Never use water or liquid to clean internal components.
8. Avoid caustic or harsh cleaning agents, which can chemically damage the
unit.
3
9. Do not use benzene, paint thinner, abrasive brushes, or polishing powders
as these may damage the surface of the cooker.
TROUBLESHOOTING:
PROBLEM
POSSIBLE CAUSE
RECOMMENDATION
No Power
Indicator
Power cord not properly
plugged
Ensure the power cord is securely
connected to the outlet
Automatically
switched o
Overload Protection
No operation for more
than 2 hours
Unplug the unit, wait for about 2 minutes,
then plug it back in
Contact the nearest Imarflex Service Center
E0
Incompatible cookware
Cookware diameter less
than 12cm (bottom)
Cookware not centered
on the cooking plate
Use induction-ready cookware made of
pure stainless steel
Ensure the pot has at least a 12 cm base
Place the pot in the center of the cooking
plate
E1/E2
Voltage is too low or too
high
Unplug the unit, wait 2 minutes, then
reconnect to power
E3
Sensor malfunction (open
or short circuit)
Contact the nearest Imarex Service Center
E4
Top Plate Sensor Open
Circuit or without connect
Contact the nearest Imarflex Service Center
E5
Cooking plate
temperature exceeds
280°C
IGBT Sensor Overheat
or Short Circuit or Fan
without connect
Allow the unit to cool for a few minutes
If issue persists, contact the nearest
Imarflex Service Center
E6
IGBT Sensor Open
Circuit
If problem continues, contact the nearest
Imarflex Service Center
REMINDER: Please do not forget to register your product warranty
through the warranty registration website at https://imarex.ph
Distributed by:
Topgadget Distributions, Inc.
2120 A.linao St., Malate, Manila
Made in China
4
