19" High-bright Teleprompter LED
Widescreen Monitor w/ Tally
Quick Start Guide
19” SDI Monitor Compatible with Ikan Teleprompters
What’s Included
1 x SDI Widescreen Teleprompter Monitor w/ Built-in Tally Light
1 x Power Adapter with Cable
www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com because we’re toofilmmakers
www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com because we’re toofilmmakers
Monitor Ports
3G-SDI – Serial Digital Interface Connection
VGA – Video Graphics Array DE15 Connection
HDMI – High-Definition Multimedia Interface Input Connection
Power Port – 12-24v Input
HDMI – Switch HDMI input
VGA – Switch to VGA input
SDI – Switch to 3G-SDI input
Flip – Toggle image flip
(Can be set to horizontal, vertical, or both via menu)
Up Arrow – Toggle up to adjust setting
Menu – Access to monitor settings
Down Arrow – Toggle down to adjust setting
Monitor Menu Settings
Video Config
Contrast (White Level)
Brightness (Black Level)
Tint (Chroma Hue)
Chroma (Chroma Saturation)
Sharpness (Detail)
RGB Setup – Manually configure RGB
Return
System Config
Menu Duration – Set duration of how long menu stays
on screen
Video Ratio – Set screen aspect ratio 16:9 or 4:3 (4:3 is
native resolution, 16:9 will create black bars)
Flip-H – Assign toggle button to flip image horizontally
Flip-V – Assign toggle button to flip image vertically
Reset – Factory reset
Return
PC Setup (Only available for VGA)
H-Position – Adjust horizontal position
V-Position – Adjust vertical position
Auto – Monitor automatically adjust position
Return
Exit
H
D
M
I
How to set-up FLIP button feature:
1. Press MENU button
2. Navigate to SYSTEM CONFIG.
3. Navigate to FLIP-V or FLIP-H
4. Change FLIP-V and/or FLIP-H to “ON”
5. Exit MENU
6. The FLIP button should now be activated and can be
pressed to mirror the image Horizontally or Vertically
7. When FLIP-H is ON, the image will flip Horizontally
8. When FLIP-V is ON, the image will flip Vertically
9. If both are ON, the FLIP button will toggle both
Horizontal and Vertical flip
Supported Video Signals
SDI
720x480i @ 59.94, 60 Hz
720x576i @ 50 Hz
1280x720p @ 50, 60 Hz
1920x1080i @ 50, 59.94, 60 Hz
1920x1080psf @ 24, 25, 29.97, 30 Hz
1920x1080p @ 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 Hz
HDMI
720x480i & 720x480p @ 59.94, 60 Hz
720x576i & 720x576p @ 50 Hz
1280x720p @ 50, 59.94, 60 Hz
1920x1080i @ 50, 59.94, 60 Hz
1920x1080psf @ 24, 25, 29.97, 30 Hz
1920x1080p @ 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 Hz
Specifications
M19W
19" High-bright Teleprompter LED Widescreen Monitor w/ Tally
Aspect Ratio
16:9
Brightness 1000 cd/m2
Diagonal 18.5 in.
Input Signal 3G-SDI, VGA, HDMI
Input Voltage DC 12v / 5A
Power Consumption 36W
Product Weight 5.73 lbs.
Product Dimensions 18.3" x 12.3 x 1.2""
Native Resolution 1920 x 1080
Shipping Weight 8 lbs
Shipping Dimensions 16.25” x 14.25” x 2”
Viewing Angle 178° (H) / 178° (V)
Build Material
UPC
Tally Interface
Aluminum Chassis
847983034499
RJ45
www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com because we’re toofilmmakers
