Operating instructions
Electronic pressure sensor
for industrial applications
PV77xx
80257500 / 01 03 / 2020
UK
2
1 Preliminary note
Symbols used
►Instructions
→Cross-reference
Important note
Non-compliance may result in malfunction or interference.
Information
Supplementary note.
2 Safety instructions
• The device described is a subcomponent for integration into a system.
- The manufacturer of the system is responsible for the safety of the system.
- The system manufacturer undertakes to perform a risk assessment and to
create a documentation in accordance with legal and normative requirements
Contents
1 Preliminary note 2 ...................................................................................................
2 Safety instructions 2 ...............................................................................................
3 Functions and features 3 .......................................................................................
3.1 Applications ...................................................................................................3
3.2 Use in hydraulic systems 4 ...............................................................................
4 Function ...............................................................................................................4
4.1 Communication, parameter setting, evaluation 4 .............................................
4.2 Switching function 4 ..........................................................................................
4.3 IO-Link ...........................................................................................................5
5 Installation............................................................................................................6
6 Electrical connection 6 ............................................................................................
7 Parameter setting 7 ................................................................................................
7.1 Parameter setting via PC 7 ...............................................................................
7.2 Parameter setting via the memory plug 8 .........................................................
7.3 List of the parameters 8 ....................................................................................
8 Factory setting 9 .....................................................................................................
3
UK
to be provided to the operator and user of the system. This documentation
must contain all necessary information and safety instructions for the operator,
the user and, if applicable, for any service personnel authorised by the
manufacturer of the system.
• Read this document before setting up the product and keep it during the entire
service life.
• The product must be suitable for the corresponding applications and
environmental conditions without any restrictions.
• Only use the product for its intended purpose (→ Functions and features).
• Only use the product for permissible media (→ Technical data).
• If the operating instructions or the technical data are not adhered to, personal
injury and/or damage to property may occur.
• The manufacturer assumes no liability or warranty for any consequences
caused by tampering with the product or incorrect use by the operator.
• Installation, electrical connection, set-up, operation and maintenance of the unit
must be carried out by qualified personnel authorised by the machine operator.
• Protect units and cables against damage.
3 Functions and features
The device monitors the system pressure of machines and installations.
3.1 Applications
• Type of pressure: relative pressure
Order number Measuring range Pressure rating Bursting pressure
Pressure sensors with R¼ external thread
MPa MPa MPa
PV7700 0...40 100 170
PV7701 0...25 62.5 120
PV7702 0...10 25 100
PV7703 -0.1...2.5 6.5 60
PV7704 -0.1...1 2.5 30
The units are vacuum resistant.
