Operating instructions (supplement)
System description
Deactivation of UA without interaction in IO-Link
systems with suitable devices
11601028 / 0107 / 2024
GB
System description
2
Contents
1 Preliminary note ............................................................. 3
1.1 Purpose of the document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2 Symbols used.......................................................... 3
1.3 Warnings.............................................................. 3
1.4 Change history......................................................... 3
2 Safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 Required background knowledge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 Intended use................................................................ 5
4 System description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4.1 Isolation .............................................................. 6
4.2 Actuators.............................................................. 7
4.3 Supported devices (ALxxxx) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.4 Safety relay............................................................ 8
4.5 Star point connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.6 Voltage supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5 Certification................................................................. 10
System description
3
1 Preliminary note
1.1 Purpose of the document
This document describes a concept for a system for deactivating the supply voltage of an actuator
without interaction using a safety relay and suitable devices of the ifm device families AL1xxx (IO-Link
master) and AL2xxx (IO-Link input / output module).
1.2 Symbols used
Requirement
Instructions
Reaction, result
[...] Designation of keys, buttons or indications
Cross-reference
Important note
Non-compliance may result in malfunction or interference.
Information
Supplementary note
1.3 Warnings
Warnings indicate the possibility of personal injury and damage to property. This enables safe product
handling. Warnings are graded as follows:
WARNING
Warning of serious personal injury
wIf the warning is not observed, fatal and serious injuries are possible.
CAUTION
Warning of minor to moderate personal injury
wIf the warning is not observed, minor to moderate injuries are possible.
ATTENTION
Warning of damage to property
wIf the warning is not observed, damage to property is possible.
1.4 Change history
Issue Subject Date
00 New creation of the document 04 / 2024
01 Added: supported devices AL2236, AL4302, AL4303, AL4322, AL4323 07 / 2024
