Pagina 1/12
PS6R
Slim DIN-Rail Switching Power Supplies
Reduced size and high efficiency cuts operating costs.
(13/11/08)
Highly efficient, low loss, high-power and space-saving
switching power supplies.
80
82
84
86
88
90
92
94
96
50 100150 200 250 300
PS6R-J24
Competitor B
Competitor A
Captive spring-up screws will not
be lost. Ring or fork terminals
can be connected quickly and
easily.
Terminals cannot be touched
(IP20 construction), preventing
electric shocks.
Note: The LEDs go on when the input voltage drops.
LED indicators make maintenance easy.
DC-DC Converter Unit Expansion Terminal Unit
Required space comparison (480W model)
Using terminal blocks
Conventional
Switching Power
Supplies
Using DC-DC
Converter
unit
Reduced Wiring Fingersafe
Highly efficient saving energy
and cost, improving
productivity!
∗
When the input is 230V AC.
In addition to a single output, an additional 10W output
can be provided.
Two terminals for wiring can be added, reduces wiring
and installation space.
Operation without derating from
0 to 60ºC.
Wide operating temperature range:
–10 to +70C.
Energy-saving
Space-saving
Highly Reliable
93% Efficiency
∗
The slimmest switching power
supplies in their class
(37mm-wide, 120W model)
Output voltages can be added or branched easily.
Less wiring reduces overall cost.
LED Indicator
100
90
80
70
60
50
40
30
20
10
0
010203040506070-10
Operates without
derating from 0 to 60C
Input Voltage (V AC)
Operating Temperature (C)
Output Current (%)
Efficiency (%)
480W Efficiency Comparison
Conventional model
(50mm-wide)
106mm
192.5mm
Space-saving
Operates from –10 to 70C
Captive spring-up screws
First in the industry
∗
Status
Normal
Overload or Input
Voltage Low (Note)
Output
Short-circuit
Output
OFF
DC ON (green LED)
DC Low (amber LED)
Approx.
20mm
26%
less
Using expansion terminal unit
rg
∗
g
y
∗
PS6R
37
mm wide
IDEC, a creater of optimum HMI (Human Machine Interface) environment, has newly develped
a high-power, space-saving PS6R switching power supply family. Only 37mm in width and
complying with international standards. Multiple output voltages can be added easily.
Easy Maintenance
Reduces labor and improves safety
Convenient − Easily Expandable!
Wide operating
temperature range
enables stable
continuous operation.
SEMI, ANSI, and maritime standards
pending.
2
(13/11/08)
