Dimensions / Capacity
Interior Storage Capacity (CF)
Overall Width x Depth
Depth with door open
Height
Adjustable Shelves
Shelf Dimensions (W x D)
Floor Shelf Dimensions (W x D)
Crated Shipping Weight
Crated Width x Depth x Height
Features
• Large glass door are energy efficient low E multi pane
glass
• Spring assisted self-closing door with stay open
feature
• (3) epoxy coated wire shelves are standard
• Stackable (three units high) to conserve warehouse
floor space
• Refrigerant flow is controlled with a capillary tube
• 2 inch leveling legs standard
• Three years parts and labor warranty
• Five year compressor warranty
• 8 ft. cord and plug
• Exterior finish available in silver, white, and black
Capacity:
20 oz. bottles: 102
12 oz. bottles: 217
Container Qty: 144
Electrical / Refrigeration
Voltage
HACR Breaker
Electrical Connection
(NEMA)
Voltage Range
Ambient Temp. Range
Control Setpoint Range
Amperage
Energy Consumption
(kWh/day) @ASHRAE
Approx. Nominal Compres. BTU/HR (HP)
Refrigerant
Options
Hoshizaki reserves the right to change specifications without notice.
RM-7-HC
04/01/24
Item # 13408
RM-7-HC
Glass Door Merchandiser with Swing Door
618 Hwy, 74 S., Peachtree City, GA 30269 | TEL 800-438-6087 | FAX 800-345-1325 | www.hoshizakiamerica.com
© HOSHIZAKI AMERICA, INC.
Curved vertical corners with silver/
black/white aluminum exterior provide
enhanced product display
Energy efficient vertical LED interior
lights illuminate products on display
Forced-air evaporator for quick
temperature pull-down
Valid in United States, Canada, Puerto
Rico and U.S. Territories. Contact
factory for warranty in other countries.
Warranty
3 Year - parts and Labor on
entire machine.
5 Year - Parts on Compressor
W x D x H
21” x 25.25” x 39”
7 ft
3
21” x 25.25”
44.88”
39”
2 adjustable, 1 floor shelf
17.75” x 20.75”
18” x 9.25”
180 lbs.
28” x 24.5” x 44”
115/60/1
15.0 Amps
5-15P
104-126
60° to 86°F
32° to 39°F
3.2
1.38
582 (1/8HP)
R290
RM-7-HC
RM-7-HC
One Section
One Section
ANSI / NSF 7
Floor Epoxy Shelf (HS-5344)
Epoxy Shelf (HS-5343)
Item #:
Project:
Qty:
AIA#:
If GFCI is required, a GFCI breaker MUST be used in lieu of GFCI receptacle
RM-7-HC RM-7-HC-BLK RM-7-HC-WHT
SIDE VIEW
FRONT VIEW
PLAN VIEW
618 Hwy, 74 S., Peachtree City, GA 30269 | TEL 800-438-6087 | FAX 800-345-1325 | www.hoshizakiamerica.com
© HOSHIZAKI AMERICA, INC.
HEADER DIMS
Graphic Requirements:
• 360 dpi resolution. Scale 1=1
• Colors for CMYK process
• Image with 1/4” of excess by side
• Graphics must be saved in photoshop (with layers)
- (or your sign company file type requirements)
• Include a full color print out
Material Requirements:
• 3M exterior grade UV resistant vinyl adhesive
Note: Texts and important parts of the image should be within the visible area.
The visible area is illustrated by dotted lines when it applies.
RM-7-HC LIGHTED
SIGN DIMENSIONS
(Visible Area)
RM-7-HC
04/01/24
Item # 13408
RM-7-HC
Glass Door Merchandiser with Swing Door
47.88” [1216.2]
