DS-KAD706Y-S(P)

1

3

2

123

45

1

45

6

3

2

6

4

Two-WireVideo&AudioDistributor

4

1

2

3

1

2

NetworkNetwork

DS-KAD706Y-SDS-KAD706Y

DoorStation

UD29994B

ModelManufacturer

KPL-060M-IIChannelWellTechnologyCo.,Ltd

ThedetailforthepoweradaptercontainedintheDS-

KAD706Y-SPpackageisasfollows:

MAX

MAX

MAX

MAXMAX

6W

6W

6W

6W6W

24VDC

24VDC

24VDC

24VDC24VDC

24VDC

PowerInput

24VDC

PowerInput

24AWG(0.2mm²,9

Ω/100m)

20AWG(0.5mm²,3.5

Ω/100m)

18AWG(0.8mm²,2.5

Ω/100m)

All

DS-KAD706Y-DS-KAD706Y-STransmission

Distance≤60m

Transmission

Distance≤60m

Transmission

Distance≤60m

DS-KAD706Y-DS-KAD706YTransmission

Distance≤60m

Transmission

Distance≤60m

Transmission

Distance≤60m

DS-KAD706Y-DS-KD8003Y-IME2Transmission

Distance≤35m

Transmission

Distance≤35m

Transmission

Distance≤35m

Transmission

Distance≤35m

Transmission

Distance≤35m

Transmission

Distance≤60m

Transmission

Distance≤60m

DS-KAD706Y-DS-KH6320Y-WTE2Transmission

Distance≤35m

Transmission

Distance≤60m

Transmission

Distance≤60m

TwistedPairParallellines

RoutingPath

DiagramReferences

Appearance

PowerIndicator

NetworkInterfaceNetworkIndicator

TerminalsResetButton

PowerInput

Wiring

Wirethedeviceswithpowersupplycablesaspictureshown.

DistributorshouldbeconnectedtoanyterminalofCH1toCH6ofthedevicewithtwo-wirecables.

Caution:Makesurealltherelatedequipmentispower-offduringtheinstallation.

Installation

Beforeyoubegin:

●Makesurethedeviceinthepackageisingoodcondition.

●Makesurealltherelatedequipmentispower-offduringtheinstallation.

●Checktheproductspecificationfortheinstallationenvironment.

WallMounting

1.FixtheDINrailontothewall.

Note:YouarerequiredtoutilizeamatchedDINrail.

2.Presstheredclipupward,andlockittotheDINrail.

TipsforCablesandInstallation

CablesandWiring

●Whentherearemultiplecoresinoneparallelline,onlyonepairofclosedcoresareallowedto

transmitsignal.Itisnotallowedtousemultiplepairofcoresinonecabletotransmitsignal.

●Whenusingparallellines,itissuggestedtousethosewithshieldinglayer.Ifdualcoreor

multiplecoreparallellineswithoutshieldinglayerarerouted,stabilityofsignaltransmission

canbeeffected.Youneedtorunatestbeforeinstallation.

●Impedanceofcableshouldnotbeoversuggestedvalue,ordistributorcannottransmit

enoughpowertoindoorstationordoorstation.

●Strongelectricityandweakelectricitycannotbewiredinthesameroute,theyneedtobewired

separatelyandthedistanceshouldbemorethan0.5meter.

●Allthecablesusedneedtofollowtherestrictioninthefollowingtable.

DeviceInstallation

●Installationenvironment(temperature,moistureetc.)needstofollowrequirementsin

specificationorpoweroutputcanbeeffected.

●PowersupplymustbecertifiedbyHikvision.

Note:

Theindoorstationanddoorstationarenotcontainedin

thepackage.

Note:Thepowersourceshouldbequalifiedandmeetlimitedpower

sourceorPS2requirementsaccordingtoIEC60950-1orIEC62368-1standard.
