Wall-MountedBracket

UserManual

2

Specifications

3

Installation

1

1

1

11

Apperance

UD33305B

ProductWall-MountedBracket

ProductModelDS-KABV6113-A

Dimension(W×H×D)133.1mmx60.1mmx35.1mm

ApplicableProducts

DS-KV6113-PE1(C)，

DS-KV6113-WPE1(C)，

DS-KV6103-PE1(C)

ProtectiveShieldModelDS-KABV6113-RS

MountingPlate

InKV6103/6113Series

DoorStationProductPackage

WorkingTemperature-30to60℃℃

WorkingHumidity10%to90%

Whenfacingthedoorand

installingthedeviceontheleft,

theholesinthebracketand

protectiveshieldcovershouldbe

alignedwiththecorresponding

fourinstallationholes.

Whenfacingthedoorand

installingthedeviceontheright,

theholesinthebracketand

protectiveshieldcovershouldbe

alignedwiththecorresponding

fourinstallationholes.

FixingHoleBetween

bracketandprotective

shield

OutletHoleWhenDevice

isInstalledontheRight

Side

InstallationHolesfor

FixingBracketstotheWall

Reserved

OutletHoleWhenDevice

isInstalledontheLeft

Side

BeforeYouStart

a.Makesurethedeviceinthepackageisingoodconditionandallthe

assemblypartsareincluded.

b.Checktheproductspecificationfortheinstallationenvironment.

Installation(TakeInstallingontheleftsideforexample)

Alignthebracketwiththewall.Securethemountingbracketon

thewallwith4SC-KA3X20-NI-JMFscrews.

1

Aligntheprotectiveshield(DS-KABV6113-RS)andtheappliedmounting

platewiththebracket.Securetheprotectiveshieldandthemountingplate

onthebracketwith4SC-KM3X8-BNIscrews.

2

Installingontherightsideisthe

sameasinstallingontheleftside,

youcanrefertothefigureonthe

left.
