HighlyAccurateThermographicCamera
Installation andConguration Guide
Temperature Measurement Range: 861133045F (C)
Working Temperature: 50951035F (C)
Accuracy: ±±0.9F (0.5C)
Resoluon: 384 ×288
1
Installation
Wall-MountedDeployment
2
Conguration
Recommended Installaon Parameters
Model
Distance
(between human
and
camera)
Height
Elevaon
Angle
DS
-2TD2636B-
13/P
8' 2"23'
(2.5 m7 m)
5' 7"8‘ 2"
(1.7 m
2.5 m)
≤20°
3
Advice
1. Select Body Thermometry as VCA Resource Type.
2. Go to Conguraon > Local interface, enable and save
the following sengs:
3. Go to Body Thermometry >Basic Setngs. Congure
and save the following setngs:
Emissivity: For human skin, this value is normally set as 0.98.
Distance: The actual distance between the camera and
human.
CheckEnable Face Detecon andDisplay Temperature.
Suggest uncheckUpload Captured Face Image Display Face and
Temperature Posion if its not required.
Set Alarm Temp. Pre-alarm Temp.and
Press Draw Area to adjust face detecon region.
Click Max. Pupil Distance Min. Pupil Distance and to draw
width lter frame. Max and Min distance refer to camera
detecon distance.
4. Congure Camera 01 (Opcal) Setngs.
Uncheck Enable Blackbody Correcon if no blackbody is used.
Check Enable ofBody Temperature Compensaon, and keep
parameters as default.
DS-2TD2636B
The environment caneasily inuence the performance of thermal camerasTherefore, thermal cameras are .
required to be used in a stable indoor environment without wind, and the ambient temperature should be
consistent.
Heres some advice:’
1.Set up a one-way screening zone, and ensure that thecamera can clearly see the face of the person whose
skin-surfacetemperature is beingmeasured.
2.Avoid backgrounds that are too crowdedor bright.
3.Turn the camera on minutes before taking skin-surfacetemperature measurementsbecause the camera 30 ,
needs to be stable.
4.If there is a large dierencebetween the indoor and outdoor temperaturesit is suggested to wait more than ,
ve minutesbeforemeasuringtheskin-surfacetemperature of someone whojust got in.
5.Follow the guidance of required temperature measurement distance and height.
5. Congure Camera 02 (Thermal) Setngs.
Product specificaties
| Merk: | Hikvision |
| Categorie: | Fotocamera |
| Model: | DS-2TD2636B-13/P |
| Gebruikershandleiding: | Ja |
| Stemcodecs: | G.711, G.722.1, G.726, MP2L2, PCM |
| Ondersteuning voor plaatsing: | Buiten |
| Connectiviteitstechnologie: | Bedraad |
| Ethernet LAN: | Ja |
| Videocompressieformaten: | H.264, H.265 |
| Minimale belichting: | 0.001 Lux |
| HTTPS-encryptie: | Ja |
| Aantal Ethernet LAN (RJ-45)-poorten: | 1 |
| Omvang optische sensor: | 1/2.7 " |
| Type beeldsensor: | CMOS |
| Camera sluitertijd: | 1/100 s |
| Webbrowser: | Ja |
| Ondersteunde netwerkprotocollen: | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE |
| IP-adresfilter: | Ja |
| Progressive scan: | Ja |
| Ethernet interface type: | Fast Ethernet |
| Videostreaming: | Ja |
| Aantal talen: | 32 |
