Model 9201E
Tempered Water Blending System
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material or poor
workmanship for a period of one year from date of shipment. HAWS liability under this
warranty shall be discharged by furnishing without charge F.O.B. HAWS Factory any
goods, or part thereof, which shall appear to the Company upon inspection to be of
defective material or not of first class workmanship, provided that claim is made in writing to
Haws within a reasonable period after receipt of the product. Where claims for defects are
made, the defective part or parts shall be delivered to the Company, prepaid, for inspection.
HAWS will not be liable for the cost of repairs, alterations or replacements, or for any
expense connected therewith made by the owner or his agents, except upon written
authority from HAWS, Sparks, Nevada. HAWS will not be liable for any damages caused by
defective materials or poor workmanship, except for replacements, as provided above.
Buyer agrees that Haws has made no other warranties either expressed or implied in
addition to those above stated, except that of title with respect to any of the products or
equipment sold hereunder and that HAWS shall not be liable for general, special, or
consequential damages claimed to arise under the contract of sale.
The emergency equipment manufactured by HAWS is warranted to function if installation
and maintenance instructions provided are adhered to. The units also must be used for the
purpose for which they were intended. This product is intended to supplement first-aid
treatment. Due to widely varying conditions, Haws cannot guarantee that the use of this
emergency equipment will prevent serious injury or the aggravation of existing or prior
injuries.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED, PROVIDED
OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL, OR REQUIRE REPLACEMENT PARTS, PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297
INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS
04/19 Model 9201E Page 2 of 7
Valve operating principle:
The Haws Corporation 9201E Emergency Valve thermostatically mixes hot and cold water to provide a
safe fluid supply for emergency showers and eyewash equipment. Additionally, to ensure a fail-safe water
supply for emergency shower and eyewash stations, a series of cold water by-pass valves open in the
event of hot water pressure loss.
Valve features:
- Paraffin filled thermostat with industry leading response time.
- Tempered water: Temperature is factory set to 85°F (29°C).
- Tempered water: High temperature limit is factory set to 90°F (32°C).
- Cold water by-pass valves open if hot water fails.
- Actively suspends hot water flow when cold water supply is lost to protect against scalding.
- Cold water by-pass valves are closed during normal operation, regardless of flow rate.
Valve sizing:
The flow capacity table shown below contains discharge flow rates @ 85°F (29°C) outlet temperature with
the valve tested under the conditions described by ASSE 1071.
Flow Capacity
Model No.
Min flow
Pressure drop across valve
Cold water
5 PSI
10 PSI
20 PSI
30 PSI
40 PSI
45 PSI
By-pass @ 30 PSI
9201E
1.0* GPM
13
GPM
18
GPM
25
GPM
31
GPM
36
GPM
38
GPM
20
GPM
* Denotes minimum flow rate without re-circulation.
Valve specifications:
- Maximum operating pressure: 125 PSI
- Minimum / Maximum hot water temperature: 120°F / 180°F (49°C - 82°C).
- Tempered water temperature adjustment range: 60°F – 90°F (15°C - 32°C)
- Compliance/Listings: ASSE 1071 and applicable sections of CSA B125.3.
IMPORTANT
To ensure the proper operation of the 9201E valve it is essential to:
- Properly size the valve for each application.
- Keep the outlet temperature set between 60°F and 90°F (15°C - 32°C).
- Haws recommends a weekly testing and recording of the outlet water temperature.
Failure to comply with installation and/or maintenance instructions could result in
valve failure.
