APPROVED:
DRAWN:
PART NUMBER
SCALE:
SHEETOF
REVISION
DRAWING TYPE:SIZE: A
BY:ECN NO.
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved.
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
C
R
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
(775) 359-4712 FAX (775) 359-7424
E-MAIL: HAWS@HAWSCO.COM
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
JL
05/09/16
3
0510000133.D
7601.15
15 GAL EYEWASH
1:1
11
FV
10/24/16
5050
VWC
INSTALLATION
5142
2016
CC
NOTES:
1. TO COMPLY WITH ANSI Z358.1-2014 FOR EMERGENCY EYEWASH OR EYEWASH:
- UNIT SHALL BE INSTALLED IN ACCORDANCE WITH MANUFACTURER'S INSTRUCTIONS AND ACCEPTABLE PLUMBING PRACTICES.
- EYE/FACE WASH SHALL BE POSITIONED SUCH THAT STREAMS ARE 15.3 CM (6 IN.) MINIMUM FROM WALL OR NEAREST
OBSTRUCTION.
2 EYEWASH HEAD ASSEMBLY MUST BE PARALLEL TO WALL OR OBSTRUCTION TO MEET CRITERIA STATED IN ACCORDANCE TO NOTE 1.
*3. DIMENSIONS MAY VARY BY ±1/2" [12.7mm].
4.
PRESSURIZE TO 100 PSI. REFILL IF PRESSURE < 95 PSI.
43-11/16"
311 mm
12-1/4"
1110 mm
PUSH
FLAG
AIR VALVE
*
WALL
2
1/2" NPT (FEMALE)
CONNECTION FOR
OPTIONAL EYE/FACE
& BODY HOSE UNIT
FILL WATER
TO THIS MARK
PRESSURE
GAUGE
PRESSURE
RELIEF VALVE
COVER PLATE
