Pagina 1/16
USER MANUAL
1
#MPJ2748
27” X 48” Pallet Jack
5500 LB. WEIGHT CAPACITY
PLEASE READ ENTIRE MANUAL BEFORE USE 08/2024
USER MANUAL
2
Table of Contents
Product Specifications …………………………………………………………………………………………………… 3
Delivery Inspection .……………………………………………………………………………………………………….. 3
Operating Instructions ……………………………………………………………………………………………………. 3
Assembly Instructions ……………………………………………………………………………………………………. 4
Safety Procedures …………………………………………………………………………………………………………. 5
Daily Inspections ………………………………………………………………………………………………………….. 5
Maintenance ………………………………………………………………………………………………………………… 6
Warranty ………………………………………………………………………………………………………………………. 6
Troubleshooting …………………………………………………………………………………………………………….. 7
Parts Diagrams ……………………………………………………………………………………………………………… 8-15
USER MANUAL
3
Product Specifications
Weight Capacity (lb.)
5500 lbs.
Main Specifications
Fork Width (in.)
27”
Fork Length (in.)
48”
Fork Lowered
Height (in.)
3”
Steer Wheel Diameter (in.)
7
”
Load Wheel Diameter (in.)
3”
Item Weight (lb.)
1
5
5
lb.
Delivery Inspection
Each Harper Industrial Pallet is checked before shipment. In order to ensure that your Pallet Jack has not been
damaged in transit, check that your unit is free of any major damage or dents and is in working condition before
use. If damage is evident or your unit is not in working condition, contact your distributor immediately. Never use a
damaged Pallet Jack.
Operating Instructions
Read and understand prior to using the pallet jack.
To lift a load:
1. Lower forks to lowest position.
2. Insert forks under load or into pallet.
3. Place lever in UP position (bottom part of the handle slot).
4. Mover handles up and down until forks reach desired height.
To move a load:
1. Place lever in NEUTRAL position (center part of the handle slot).
2. Pull or push to desired location.
To lower a load:
1. Pull lever to DOWN position (upper part of the handle slot).
2. Full forks away from load.
NOTE: The neutral position disengages the pump from the lifting mechanism. This frees the handle, which makes
pulling loads easier. This preserves the hydraulic seals and the valve components for a longer service life.
