Pagina 1/29

English _3

!OVERVIEW

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean the contaminated area on the product surface with a soft, dry cloth or a damp cloth.

(Do not use a detergent or cosmetic products that contain alcohol, solvents or surfactants or oil constituents

as they may deform or cause damage to the product.)

7. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including

ampliﬁers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades

with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide

blade or the third prong are provided for your safety. If the provided plug does not ﬁt into your outlet, consult

an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and

the point where they exit from the apparatus.

11. Only use attachments/ accessories speciﬁed by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table speciﬁed by the manufacturer,

or sold with the apparatus. When a cart is used, use caution when moving the cart/

apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lighting storms or when unused for long periods of time.

14. Refer all servicing to qualiﬁed service personnel. Servicing is required when the apparatus

has been damaged in any way, such as power-supply cord or plug is damaged, liquid has

been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,

does not operate normally, or has been dropped.

15. This product is intended to be supplied by a UL Listed Power Supply Unit marked “Class 2” or “LPS” and

rated from PoE(55V), 1.17A.

16. This product is intended to be supplied by isolation power.

17. If you use excessive force when installing the product, the camera may be damaged and malfunction.

If you forcibly install the product using non-compliant tools, the product may be damaged.

18. Do not install the product in a place where chemical substances or oil mist exists or may be generated. As

edible oils such as soybean oil may damage or warp the product, do not install the product in the kitchen or

near the kitchen table.

This may cause damage to the product.

19. When installing the product, be careful not to allow the surface of the product to be stained with chemical

substance.

Some chemical solvents such as cleaner or adhesives may cause serious damage to the product’s surface.

20. If you install/disassemble the product in a manner that has not been recommended, the production functions/

performance may not be guaranteed.

Install the product by referring to “Installation & connection” in the user manual.

21. Installing or using the product in water can cause serious damage to the product.

22. This device has been veriﬁed using STP cable. The use of appropriate GND grounding and STP cable

is recommended to effectively protect your product and property from transient voltage, thunderstroke,

communication interruption.

23. The operating temperature of the product is -40°C to +50°C (-40°F ~ +122°F).

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT

TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH THE

VENTILATION GRILLS OR OTHER OPENNINGS ON THE EQUIPMENT.

Apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids,

such as vases, shall be placed on the apparatus.

To prevent injury, this apparatus must be securely attached to the Wall/ceiling in accordance

with the installation instructions.

Pan/Tilt/Zoom motors and slip ring are warrantied for one year under continuous

operation. (PTZ Camera)

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.

DO NOT REMOVE COVER (OR BACK).

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

EXPLANATION OF GRAPHICAL SYMBOLS

The lightning flash with arrowhead symbol, within an equilateral triangle, is

intended to alert the user to the presence of “dangerous voltage” within the

product’s enclosure that may be of sufficient magnitude to constitute a risk of

electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to

the presence of important operating and maintenance (servicing) instructions in

the literature accompanying the product.

overview

Product specificaties

Merk:	Hanwha
Categorie:	Bewakingscamera
Model:	PNM-C34404RQPZ
Kleur van het product:	Black, White
Gewicht:	7900 g
Hoogte:	301.9 mm
Soort:	IP-beveiligingscamera
Materiaal behuizing:	Aluminium
Internationale veiligheidscode (IP):	IP66
Maximale capaciteit van de geheugenkaart:	1024 GB
Vormfactor:	Dome
Ondersteuning voor plaatsing:	Binnen & buiten
Connectiviteitstechnologie:	Bedraad
Ethernet LAN:	Ja
Montagewijze:	Plafond
Maximum resolutie:	3840 x 2160 Pixels
Totaal aantal megapixels:	2 MP
Videocompressieformaten:	H.264, H.265, M-JPEG
Diameter:	379.8 mm
Type stroombron:	Power over Ethernet (PoE)
Minimale belichting:	0.01 Lux
Aantal cameras:	1
Geïntegreerde geheugenkaartlezer:	Ja
Compatibele geheugenkaarten:	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Nachtvisie:	Ja
LED-type:	IR
Brandpuntbereik:	3.3 - 5.7 mm
Vermogensverbruik (max):	64 W
Omvang optische sensor:	1/2.8 "
Type beeldsensor:	CMOS
Witbalans:	ATW, AWC, Indoor, Manual, Outdoor
Type camerasluiter:	Elektronisch
Ondersteunde grafische resoluties:	640 x 360,640 x 480 (VGA),720 x 480,720 x 576,800 x 448,800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 960,1920 x 1080 (HD 1080),3840 x 2160
Temperatuur bij opslag:	-50 - 60 °C
Maximaal 30 frames per seconde:	20 fps
Ondersteunde netwerkprotocollen:	IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP(TCP, UDP Unicast), MQTT
Luchtvochtigheid bij opslag:	0 - 95 procent
Ethernet interface type:	Gigabit Ethernet
Ondersteunde talen:	CZE, DEU, DUT, ENG, ESP, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, TUR
IK code:	IK10
PTZ control:	Ja
Draaihoek:	90 °
Pan bereik:	0 - 360 °
Dag/nacht modus:	Ja
Maximum aperture number:	1.9
Videostreaming:	Ja
Nachtkijker afstand:	20 m
Achtergrondverlichting compensatie:	Ja
Aantal effectieve pixels (H x V):	3840 x 2160 Pixels
Wide Dynamic Range (WDR):	Ja
Stroomverbruik (typisch):	45 W
Bedrijfstemperatuur (T-T):	-40 - 50 °C
Relatieve vochtigheid in bedrijf (V-V):	0 - 95 procent
Bereik kantelhoek:	9 - 65 °
Privézone maskeren:	Ja
Spiegel:	Ja
Draaien & spiegelen:	Ja
Dynamisch bereik:	120 dB
