www.hager.com

Safety instructions

Electrical equipment must only be installed and assembled by a qualified

electrician in accordance with the relevant installation standards, regulations,

directives and safety and accident prevention directives of the country.

Failure to comply with these installation instructions may result in damage to

the device, fire or other hazards.

Function

The RJ45 outlets are used for data transmission in local area networks. The RJ11

outlets are designed for telephone and data applications. Each jack is equipped with a

dust protection slider.

Correct use

-For the flush-mounted installation in standard wall boxes

(recommended wall box depth ≥ 35 mm).

-Only suitable for use in indoor areas with no drip and no spray water.

Technical data

RJ45 outlets

Voltage proof (contact-to-contact): 1000 V DC or AC peak

Current rating: 0.75 A

Insulation resistance: ≧ 500 MΩ at 100 V DC

Signal contact resistance: ≦ 20 mΩ

Type of connection: IDC terminals

Design: according to IEC 60603-7

Colour code A and B: according to TIA/EIA 568-B.2

RJ45 Cat.5e modules

Transmission bandwidth: max. 100 MHz

Conductor Ø (solid): 0.51 ... 0.64 mm (AWG 24-22)

Cat.5e, unshielded (UTP): according to ISO/IEC 11801

RJ45 outlet Cat.5e / Cat.6 / Cat.6A

RJ11 outlet / RJ11 + RJ45 outlet

Hager Muse / Hager Inspire

Installation manual
